INSTRUCTION MANUAL VCC-4594

COLOR CCD CAMERA

About this manual

Before installing and using the camera, please read this manual

carefully. Be sure to keep it handy for later reference.

L53Z4/US GB 2001, 4, 2

Depending on the conditions of use, installation and environment,

please be sure to make the appropriate settings and adjustments. If

you need help with installation and/or settings, please consult your

dealer.

CONTENTS

INFORMATION TO USER ....................................................................... 2

PRECAUTIONS........................................................................................ 3

PARTS NAMES........................................................................................ 4

CONCERNING AUTO-IRIS LENSES......................................................... 6

FLANGE-BACK ADJUSTMENT................................................................ 7

MOUNTING THE LENS........................................................................... 8

CONNECTIONS.......................................................................................10

SETTINGS................................................................................................11

TROUBLESHOOTING..............................................................................16

SPECIFICATIONS.....................................................................................17

FEATURES

•The optical filter is switched automatically to color image or black

and white image according to the subject brightness.

•Built in interline transfer method 1/3" CCD, approx. 410,000

picture elements

•Low smear, anti blooming, low lag, no burning and no geometric

distortion using the CCD solid state image device.

•100% solid state components giving excellent immunity to shock

and vibration

•Not subject to interference from magnetic or electrostatic fields

•High sensitivity, minimum required illumination is 0.03 lux (F1.2)

B/W mode

•Horizontal resolution, more than 520 TV lines

•Power supply: 24 V AC operation

ACCESSORIES

•Lens iris plug (4 pin)..................................................................1 pc.

L53Z4/US GB 2001, 4, 2

English 1

INFORMATION TO USER

Safety Guard

THIS SYMBOL INDICATES THAT THERE ARE

IMPORTANT OPERATING AND MAINTENANCE

INSTRUCTIONS IN THE LITERATURE ACCOMPANYING

THIS UNIT

WARNING:

TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK , DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

This installation should be made by a qualified service person and

should conform to all local codes.

For the customers in Canada

This Class B digital apparatus complies with Canadian ICES 003.

Pour la clientèle canadienne

Cet appareil numerique de la Classe B est conforme a la norme

NMB 003 du Canada.

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of

the following measures:

–Reorient or relocate the receiving antenna.

–Increase the separation between the equipment and receiver.

–Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

–Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by Sanyo may

void the user’s authority to operate this camera.

L53Z4/US GB 2001, 4, 2

2 English

PRECAUTIONS

In case of problem

Do not use the camera if smoke or a strange odour comes from the

unit, or if it seems not to function correctly. Disconnect the power

cord immediately, and consult your dealer (or a Sanyo Authorized

Service Centre).

Do not open or modify

Do not open the cabinet, as it may be dangerous and cause damage

to the unit. For internal settings and repairs, consult your dealer (or a

Sanyo Authorized Service Centre).

Do not put objects inside the unit

Make sure that no metal objects or flammable substance get inside

the camera. If used with a foreign object inside, it could cause a fire,

short circuits or damages.

If water or a liquid gets inside the camera, disconnect the power cord

immediately, and consult your dealer (or a Sanyo Authorized Service

Centre). Be careful to protect the camera from rain, sea water, etc.

Be careful when handling the unit

To prevent damages, do not drop the camera or subject it to strong

shock or vibration.

Install away from electric or magnetic fields

If installed close to a TV, radio transmitter, magnet, electric motor,

transformer, audio speakers the magnetic field they generate will

distort the image.

Protect from humidity and dust

To prevent damages to the camera, do not install it where there is

greasy smoke or steam, where the dampness may get too high, or

where there is a lot of dust.

Protect from high temperatures

Do not install close to stoves, or other heat generating devices, such

as spotlights, etc., or where it could be subject to direct sunlight, as

that could cause deformation, discoloration or other damages.

Be careful when installing close to the ceiling, in a kitchen or boiler

room, as the temperature may raise to high levels.

Install where the temperature range will stay between –10˚C and

50˚C.

(no condensation)

Cleaning

•Dirt can be removed from the cabinet by wiping it with a soft

cloth. To remove stains, wipe with a soft cloth moistened with a

soft detergent solution and wrung dry, then wipe dry with dry soft

cloth.

•Do not use benzine, thinner or other chemical product on the

cabinet, as that may cause deformation and paint peeling. Before

using a chemical cloth, make sure to read all accompanying

instructions. Make sure that no plastic or rubber material comes in

contact with the cabinet for a long period of time, as that may

cause damage or paint peeling.

L53Z4/US GB 2001, 4, 2

English 3

PARTS NAMES

1Power indicator (POWER)

Comes on when the power to the camera is on.

2Video output connector (VIDEO OUT: BNC type)

Connect this connector to a device such as a VCR or monitor with a VIDEO IN connector.

3Manual color/black and white setting terminal (CONTROL)

•G (ground) terminal

•C (color) terminal

•B (black and white) terminal

4Line phase adjustment volume (LINE PHASE)

When using two cameras or more, the image on the monitor may roll vertically when switching sources. This

rolling can be minimized by turning this volume.

524 V AC input terminal (24 V AC, GND)

6Camera setup section (under the cover)

If due to installation conditions or environment the settings may need to be modified for best results (see

"SETTINGS").

To access the controls, loosen the cover fixing screw A, then remove the cover

7Lens iris output connector (LENS)

GCB

L53Z4/US GB 2001, 4, 2

4 English

PARTS NAMES

8Flange-back lock screw

9Lens mount cap

The cap is installed to protect the lens mount section.

Remove the lens mount cap before installing a lens (sold separately).

FFlange-back adjustment lever (See page 7)

GCamera installation bracket

The bracket can be fixed at the top or bottom of the camera. When fixing the bracket, be sure to use the

longer screws and install the shorter screws on the opposite side to seal the openings.

1Shorter screws: M3 x 4

2Longer screws: M3 x 6

3Camera mounting screw hole: 1/4"-20 UNC

CAUTION:

When installing the camera support, select a location that can support the total weight of the

camera and accessories

1232

L53Z4/US GB 2001, 4, 2

English 5

CONCERNING AUTO-IRIS LENSES

DC type auto-iris lens

A lens without amplifier circuit that operates only on a DC power source. In general, this type of lens is

referred to as DC type coil lens or DC type non amplifier lens.

(Set the A I LENS switch to the DC position.)

VIDEO type auto-iris lens

A lens with amplifier circuit that operates on video signal and DC power source. In general, this type of lens is

referred to as EE amplifier type lens.

ALC and LEVEL volume level controls are available on the lens for iris adjustments.

(Set the A I LENS switch to the VIDEO position.)

Compatible auto-iris lenses

1/3 inch Sanyo DC type lens VIDEO type lens

VCL CS8LY: Standard angle, f= 8 mm Standard angle, f= 9 mm

VCL CS4LY: Wide angle, f= 4 mm Telephoto angle, f= 12 mm

VCL CS2LY: Ultra wide angle, f= 2.8 mm More telephoto angle, f= 16 mm

If using a VIDEO type auto-iris lens

•Set the ALC and LEVEL controls on the lens to adjust the iris. Normally the ALC volume should be turned

all the way to Av (Average).

•Depending on the type of lens used, the lens may not perform properly. In such a case, adjust the LEVEL

volume on the lens casing to correct.

VIDEO

A. I.

LENS

L53Z4/US GB 2001, 4, 2

6 English

FLANGE-BACK ADJUSTMENT

If the pick up surface is not correctly positioned with relation to the lens focal point, the picture will be out of

focus (in particular when using auto iris power zoom lenses, sold separately). If that is the case, adjust the

flange back position as described below.

1Using a + screwdriver, loosen the flange-back lock screw (M2:+).

2Set the zoom lens to the maximum telephoto position, set the focus using the focus ring on the lens.

3Set the zoom lens to the maximum wide angle position, set the focus using the flange-back adjustment

lever.

4Repeat steps 2 and 3, until the image stays in focus when changing from a telephoto shot to a wide angle

shot.

When the setting is complete, tighten the flange-back lock screw.

Note:

When flange back lock screw is completely tighten it will protrude slightly as shown in the illustration (Fig 1).

Do not tighten the screw further.

Fig. 1

Flange-back lock screw

1, 4

L53Z4/US GB 2001, 4, 2

English 7

MOUNTING THE LENS

Please use a DC type auto-iris lens (sold separately)

Checking the lens mount

Do not use a lens if length “L” is more than 5 mm. If not, that may damage the camera and prevent

proper installation.

1Remove the lens mount cap from the camera

2Install the auto-iris lens

CS mount type lens

Carefully align the lens mount with the camera opening, then turn the lens slowly to install it.

C mount type lens

To allow for flange back adjustment, install the C-mount adaptor (option) on the lens mount, then

carefully align the lens mount with the camera opening and turn the lens slowly to install it.

3Connect the lens plug to the lens iris output connector (LENS) on the side of the camera

When using lenses from other makers, the plug shape may not correspond to the terminal on the camera.

In such a case, remove the original plug and using a soldering iron, connect the supplied lens iris plug

according to the diagram. (Refer to page 9.)

C mount type lens

CS mount type lens

L53Z4/US GB 2001, 4, 2

8 English

MOUNTING THE LENS

Rewiring the lens cable in the lens iris plug

1Prepare the lens cable

Cut the cable at the plug, then remove approx. 8 mm of the cable sheath and strip about 2 mm from each wire.

2Install the lens iris plug

Solder the cable to the pins following the correct pin layout (refer to the table and illustrations), then close

the plug cover.

Pin layout

DC type lenses VIDEO type lenses

1Brake coil (–) +12 V DC (50 mA max.)

2Brake coil (+) Not used

3Drive coil (+) Video output (1.0 Vp p, high impedance)

4Drive coil (–) Ground (for video signal and DC power)

L53Z4/US GB 2001, 4, 2

English 9

Otros manuales de Cámara de seguridad de Sanyo

Sanyo

Sanyo VCB-3574IRP Manual de usuario

Sanyo

Sanyo VCC-6584E - 1/3" Color CCD DSP High-Resolution... Manual de usuario

Sanyo

Sanyo VCC-7912P Manual de usuario

Sanyo

Sanyo VDC-D1185VP Manual de usuario

Sanyo

Sanyo VCC-9500 Manual de usuario

Sanyo

Sanyo VCC-W9875VP Guía del usuario

Sanyo

Sanyo VDC-DP7584S - 1/4" Color CCD Vandal-Resistant Dome... Manual de usuario

Sanyo

Sanyo VCC-6674 Manual de usuario

Sanyo

Sanyo VDC-DP9584N - Network Camera Manual de usuario

Sanyo

Sanyo VCC-WB4000 Manual de usuario

Sanyo

Sanyo Colour CCD Camera VCC-5775P Manual de usuario

Sanyo

Sanyo VCC-HD5600P Series Manual de usuario

Sanyo

Sanyo VDC-D1184VA Manual de usuario

Sanyo

Sanyo VDC-HD3100 - Full HD 1080p Vandal Dome... Manual de usuario

Sanyo

Sanyo VCC-HD5400 Guía del usuario

Sanyo

Sanyo VCC-9684VA - 1/4" Color CCD Indoor Mini Dome... Manual de usuario

Sanyo

Sanyo VCC-3944 - 1/4" Color CCD DSP Camera Manual de usuario

Sanyo

Sanyo VCC-HD3300 Manual de usuario

Sanyo

Sanyo VCC-3944 - 1/4" Color CCD DSP Camera Manual de usuario

Sanyo

Sanyo VCC-9684VA - 1/4" Color CCD Indoor Mini Dome... Manual de usuario

Sanyo

Sanyo VCC-HD4600P Manual de usuario

Sanyo

Sanyo VCC-XZ600N - Network Camera - Weatherproof Manual de usuario

Sanyo

Sanyo VCC-ZM400 Manual de usuario

Sanyo

Sanyo VCC-HD2100 - Full HD 1080p Network Camera Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
