Sanyo VCC-3912 Manual de usuario

INSTRUCTIONMANUAL

COLORCCDCamera VCC-3912

L53L2/US GB 1995, 11, 1

1AC6P1P0866--

L53L2/US (1095SY)

21350LassenStreet,

Chatsworth,CA91311

Printed in Japan

SANYOINDUSTRIALVIDEO

COLORVIDEOCAMERALIMITEDWARRANTY

OBLIGATIONS

In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center

at the user’s expense, unless specifically stated otherwise in this warranty. The names and addresses of Authorized Sanyo

Service Centers may be obtained by writing to SFS Corporation, SFC’s warranty administrator, at any of the addresses listed

below, or by calling (toll-free) 1-800-421-5013.

New Jersey Office

210 Riser Road

Little Ferry, NJ 07643

201-641-3000

California Office

1200 W. Artesia Blvd.

Compton, CA 90220

310-537-5830

Illinois Office

900 N. Arlington Heights Rd.

Itasca, IL 60143

708-775-1414

THIS WARRANTY IS VALID ONLY ON SANYO PRODUCTS PURCHASED OR RENTED IN THE UNITED STATES OF

AMERICA, EXCLUDING HAWAII AND ALL U.S. TERRITORIES AND PROTECTORATES. THIS WARRANTY APPLIES ONLY

TO THE ORIGINAL RETAIL USER. THE ORIGINAL DATED BILL OF SALE, SALES SLIP OR RENTAL AGREEMENT MUST BE

SUBMITTED TO THE AUTHORIZED SANYO SERVICE CENTER AT THE TIME WARRANTY SERVICE IS REQUESTED.

Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO FISHER (USA) CORPORATION warrants this SANYO

product against defects in materials and workmanship for the periods specified below. SFC will repair or replace (at its

option) the product and any of its parts which fail to conform to this warranty. The warranty period commences on the date

the product was first purchased or rented at retail.

LABOR PARTS IMAGE DEVICE

2 YEARS 2 YEARS 2 YEARS

EXCLUSIONS

This warranty does not cover (A) the adjustment of customer-operated controls as explained in the appropriate model’s

instruction manual, or (B) the repair of any product whose serial number has been altered, defaced or removed.

This warranty shall not apply to the cabinet or cosmetic parts, antenna, knobs, batteries or image burns to projection or

picture tubes caused by electronic devices or games.

This warranty does not apply to uncrating, setup, installation, removal of the product for repair or reinstallation of the product after repair.

This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of SFC including, but

not limited to, any malfunction, defect or failure caused by or resulting from unauthorized service or parts, improper

maintenance, operation contrary to furnished instructions, shipping or transit accidents, modification or repair by the user,

abuse, misuse, neglect, accident, incorrect power line voltage, fire, flood or other Acts of God, or normal wear and tear.

The foregoing is in lieu of all other expressed warranties and SFC does not assume or authorize any party to assume for it

any other obligation or liability.

THE DURATION OF ANY WARRANTIES WHICH MAY BE IMPLIED BY LAW (INCLUDING THE WARRANTIES OF

MERCHANTABILITY AND FITNESS) IS LIMITED TO THE TERM OF THIS WARRANTY. IN NO EVENT SHALL SFC BE LIABLE

FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF THIS PRODUCT,

OR FOR ANY DELAY IN THE PERFORMANCE OF ITS OBLIGATIONS UNDER THIS WARRANTY DUE TO CAUSES BEYOND

ITS CONTROL.

SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW

THE EXCLUSION OR LIMITATION OF CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS

MAY NOT APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.

ATTENTION

For your protection in the event of theft or loss of this product, please fill in the information below for you own personal records.

ModelNo.___________________________________________ SerialNo.___________________________________________

(Locatedonbackorbottomsideofunit.)

DateofPurchase____________________________________ PurchasePrice _____________________________________

WherePurchased _____________________________________________________________________________________________

L53L2/US GB 1995, 11, 1

CONTENTS

ACCESSORIES....................................................1

INFORMATION TO USER..................................2

FEATURES..........................................................3

PRECAUTIONS...................................................4

PREPARATION...................................................5

CONNECTIONS..................................................8

SETTINGS.........................................................10

TROUBLESHOOTING.......................................13

SPECIFICATIONS .............................................14

Important settings

Depending on the conditions of use,

installation and environment, please be sure

to make the following settings and

adjustments. If you need help with

installation and/or settings, please consult

your dealer.

Auto-i is lens setting..............................6 ~ 7

Flange-back adjustment............................10

Lens i is adjustment ..................................10

White balance adjustment........................11

Elect onic i is function setting .................. 11

Backlight compensation setting...............11

High speed elect onic shutte setting...... 12

CAUTION:

Before installing and using the camera,

please read this manual carefully. Be sure

to keep it handy for later reference.

ACCESSORIES

1C mount adaptor 5 mm).................1 pc.

The C mount adaptor must be used to

be able to install a C mount lens on the

camera.

2Lens iris plug 4-pin).........................1 pc.

3AC adaptor ......................................1 pc.

L53L2/US GB 1995, 11, 1

English 1

Safety Guard

THIS SYMBOL INDICATES THAT

THERE ARE IMPORTANT

OPERATING AND

MAINTENANCE INSTRUCTIONS

IN THE LITERATURE

ACCOMPANYING THIS UNIT

WARNING:

TO PREVENT THE RISK OF FIRE OR

ELECTRIC SHOCK , DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR

MOISTURE

ENGLISH

INFORMATION TO USER

For the customers in Canada

This Class B digital apparatus meets all

requirements of the Canadian Interference-

Causing Equipment Regulations.

Pour la clientèle canadienne

Cet appareil numerique de la Classe B

respecte toutes les exigences du Reglement

sur le material brouilleur du Canada.

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to Part

15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and

can radiate radio frequency energy and,

if not installed and used in accordance

with the instructions, may cause

harmful interference to radio

communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does

cause harmful interference to radio or

television reception, which can be

determined by turning the equipment

off and on, the user is encouraged to

try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between the

equipment and receiver.

– Connect the equipment into an

outlet on a circuit different from that

to which the receiver is connected.

– Consult the dealer or an experienced

radio/TV technician for help.

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions: 1) This device

may not cause harmful interference,

and 2) this device must accept any

interference received, including

interference that may cause undesired

operation.

Changes or modifications not expressly

approved by Sanyo may void the user’s

authority to operate this camera.

L53L2/US GB 1995, 11, 1

2 English

FEATURES

Electronic iris function

The electronic iris function regulates the

electronic shutter speed. To the contrary of

electronic shutters with a fixed speed, the

electronic iris modifies the shutter speed

according to the CCD input. The electronic

iris will automatically control the amount of

light entering the camera, so manual iris

lenses can be used on the camera.

Backlight compensation function

The backlight compensation function will

divide the screen in two areas A) and B),

as illustrated below. Then, the iris is

automatically set so the outside zone B)

brightness is given less weight than the

brightness from the center zone A), giving

the best possible image.

1/3 inch solid state image device CCD

CS type lens mount

C mount lenses can also be used with the

supplied C mount adaptor.

High speed electronic shutter

8 speeds, selectable by switches.

Terminology explanation

About the DC type lenses

These lenses use a DC power supply

without amplifier circuits. They are also

referred to as non internal amplifier type

lens or coil type lens.

About the VIDEO type lenses

These lenses use both a video signal

amplified by internal amplifier circuits and a

DC power supply. They are referred to as

internal amplifier type lens.

L53L2/US GB 1995, 11, 1

English 3

PRECAUTIONS

In case of problem

Do not use the camera if smoke or a

strange odor comes from the unit, or if it

seems not to function correctly. Disconnect

the power cord immediately, and consult

your dealer or a Sanyo Authorized Service

Center).

Do not open or modify

Do not open the cabinet, as it may be

dangerous and cause damage to the unit.

For internal settings and repairs, consult

your dealer or a Sanyo Authorized Service

Center).

Do not put objects inside the unit

Make sure that no metal objects or

flammable substance get inside the camera.

If used with a foreign object inside, it could

cause a fire, short-circuits or damages.

If water or a liquid gets inside the camera,

disconnect the power cord immediately,

and consult your dealer or a Sanyo

Authorized Service Center). Be careful to

protect the camera from rain, sea water,

etc.

Be careful when handling the unit

To prevent damages, do not drop the

camera or subject it to strong shock or

vibration.

Install away from electric or

magnetic fields

If installed close to a TV, radio transmitter,

magnet, electric motor, transformer, audio

speakers the magnetic field they generate

will distort the image.

Protect from humidity and dust

To prevent damages to the camera, do not

install it where there is greasy smoke or

steam, where the dampness may get too

high, or where there is a lot of dust.

Protect from high temperatures

Do not install close to stoves, or other heat

generating devices, such as spotlights, etc.,

or where it could be subject to direct

sunlight, as that could cause deformation,

discoloration or other damages.

Be careful when installing close to the

ceiling, in a kitchen or boiler room, as the

temperature may raise to high levels.

Install where the temperature range will

stay between –10˚C and 50˚C.

no condensation)

Cleaning

•Dirt can be removed from the cabinet

by wiping it with a soft cloth. To

remove stains, wipe with a soft cloth

moistened with a soft detergent

solution and wrung dry, then wipe dry

with dry soft cloth.

•Do not use benzine, thinner or other

chemical product on the cabinet, as that

may cause deformation and paint

peeling. Before using a chemical cloth,

make sure to read all accompanying

instructions. Make sure that no plastic

or rubber material comes in contact

with the cabinet for a long period of

time, as that may cause damage or

paint peeling.

L53L2/US GB 1995, 11, 1

4 English

PREPARATION

Came a installation

A: Lens mount cap

Remove the lens mount cap before

installing the lens sold separately).

•Use with this camera a CS mount type

auto-iris lens for 1/3 inch).

Auto-iris lenses regulate the amount of

light entering the camera according to

the brightness of the subject.

•C mount auto-iris lenses can also be used

with the supplied adaptor see page 7).

B: Installation bracket

The bracket can be fitted at the top or

bottom of the camera. To fix the

bracket, make sure to use the screws

that held the bracket before, and use

the other two screws to seal the

openings on the opposite side.

1Opening sealing screws M3x4)

shorter)

2Bracket fixing screws M3x6) longer)

3Threaded hole for the support

1/4"–20 UNC)

•Mounting at the top R1)

•Mounting at the bottom R2)

CAUTION:

•When installing the camera support,

select a location that can support the

total weight of the camera and

accessories.

•This installation should be made by

a qualified service person and

should conform to all local codes

R1 R2

1232

21BA

L53L2/US GB 1995, 11, 1

English 5

Installation of a DC type lens (sold sepa ately)

1/3 inch CS mount type

(Flange-back: 12 5 mm)

1Remove the lens mount cap.

2Install the auto-iris lens onto the camera.

Sanyo auto-iris lenses

(sold separately)

•VCL-CS8LY: Standard angle, f= 8 mm

•VCL-CS4LY: Wide angle, f= 4 mm

•VCL-CS2LY: Ultra-wide angle,

f= 2.8 mm

CAUTION:

Do not use a lens if the length “L” is

more than 5 mm. That may damage the

camera and prevent proper installation.

3Connect the lens plug to the LENS

connector on the side of the camera.

When using lenses from other makers,

make sure that the pins connections in the

plug correspond to the ones of the camera.

Refer to the lens specifications to check the

pins connections in the plug. If they are

different from the ones indicated in the

diagram, remove the original plug and

connect the supplied plug according to the

connections indicated by the diagram.

For VIDEO type lenses, please refer to

page 7.)

LENS connector layout (A)

1:Brake coil –) 2:Brake coil +)

3:Drive coil +) 4:Drive coil –)

4Set the A I LENS switch to the DC

position.

The factory default setting is DC.

(A) 1

VIDEO

L53L2/US GB 1995, 11, 1

6 English

PREPARATION

Installation of a VIDEO type lens (sold sepa ately)

1/2 or 2/3 inch C mount type

(Flange-back: 17 526 mm)

1Remove the lens mount cap.

2Attach the supplied C mount adaptor to

the auto-iris lens.

3Install the auto-iris lens onto the camera.

CAUTION:

Do not use a lens if the length “L” is

more than 5 mm. That may damage the

camera and prevent proper installation.

4Check the lens specifications sheet to

make sure the lens iris plug layout is

compatible with the layout of the LENS

connector on the side of the camera.

CAUTION:

If the lens iris plug shape and/or the

connections layout are different, the

supplied lens iris plug will have to be

fitted, in order to be able to connect the

lens to the LENS connector on the side

of the camera.

LENS connector layout

1:+12 V DC 50 mA max.)

2:Not used

3:Video output 1.0 Vp-p, high impedance)

4:Ground for video signal and DC power)

5Set the A I LENS switch to the VIDEO

position.

Set the ALC and LEVEL controls on the

lens to adjust the iris. Normally the ALC

volume should be turned all the way to

Av Average).

If using a VIDEO type auto-iris lens

Depending on the type of lens used, the

lens may not perform properly. In such a

case, adjust the LEVEL volume on the lens

casing to correct.

Compatible auto-iris lens

•f= 9 mm Standard angle)

•f= 12 mm Telephoto)

•f= 16 mm More telephoto)

VIDEO

23L

L53L2/US GB 1995, 11, 1

English 7

CONNECTIONS

Basic connection fo monito ing o eco ding

The peripheral devices (VCR, monitor,

etc ) and cables are sold separately

1Make the video signal connection

between the camera and the monitor or

time lapse VCR.

2Connect DC connecting cord from the

AC adaptor to the 12V DC IN terminal

on the camera.

3Plug the AC adaptor into an AC outlet.

4Turn on the power of all the devices

connected to the camera.

When the power is connected to the

camera, the POWER indicator A) will

light. Adjust the picture on the monitor

using the Brightness and Contrast

controls.

WARNING:

•This AC adaptor is specially conceived

for this camera. Never use another type

of AC adaptor with this camera, and do

not use this AC adaptor to power other

types of cameras.

•Not for use with toys.

•Never try to disassemble or modify the

AC adaptor.

Coaxial cable type and maximum

length

•Cable type RG-59U, 100 m maximum.

•Cable type RG-39U, 200 m maximum.

CAUTION:

The RG-59U type cable should not be

run through electrical conduits or

through the air.

4(A)

(Video signal connections)

: VIDEO IN

: VIDEO OUT

L53L2/US GB 1995, 11, 1

8 English

Otros manuales de Cámara de seguridad de Sanyo

Sanyo

Sanyo VCB-3384 - 1/3" B/W CCD Camera Manual de usuario

Sanyo

Sanyo VCC-6674 Manual de usuario

Sanyo

Sanyo VCB-3524 Manual de usuario

Sanyo

Sanyo VCC-XZ600P Manual de usuario

Sanyo

Sanyo VCC-WD8874 - Wide Dynamic Range Color Manual de usuario

Sanyo

Sanyo VCC-ZMN600P Manual de usuario

Sanyo

Sanyo VCB-3574IRP Manual de usuario

Sanyo

Sanyo VCC-P7574 - 1/4" Color CCD Indoor Mini Dome... Manual de usuario

Sanyo

Sanyo VDC-DP7584 - 1/4" Color CCD Vandal-Resistant Dome... Manual de usuario

Sanyo

Sanyo VCB-3512P Manual de usuario

Sanyo

Sanyo VCC-HD5600 - Full HD 1080p Day/Night Pan-Tilt-Zoom... Manual de usuario

Sanyo

Sanyo VCC-ZM300PA Manual de usuario

Sanyo

Sanyo Camera Lens Manual de usuario

Sanyo

Sanyo VCC-P7574N - 1/4" Color CCD Indoor Mini Dome... Manual de usuario

Sanyo

Sanyo Colour CCD Camera VCC-5775P Manual de usuario

Sanyo

Sanyo VCC-4110P Manual de usuario

Sanyo

Sanyo VCC-6574 Manual de usuario

Sanyo

Sanyo VDC-HD3500 - Full HD 1080p Vandal Dome... Manual de usuario

Sanyo

Sanyo VDC-C1074VA Manual de usuario

Sanyo

Sanyo VCC-HD2300 - Full HD 1080p Network Camera Manual de usuario

Sanyo

Sanyo VCC-WD8874 - Wide Dynamic Range Color Manual de usuario

Sanyo

Sanyo VCB-3412P Manual de usuario

Sanyo

Sanyo VCC-9684VA - 1/4" Color CCD Indoor Mini Dome... Manual de usuario

Sanyo

Sanyo VCC-P9575P Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
