Sanyo Xacti VPC-CG10BK Manual de usuario

VPC-CG10EX

VPC-CG10

VPC-CG10GX

INSTRUCTION MANUAL

Dual Camera

Please read these instructions carefully before using the camera.

Make sure to read and understand the separate booklet “SAFETY MANUAL”.

Keep this manual in a safe place for later reference.

Important note

This manual explains how to safely operate the VPC-CG10EX, VPC-CG10

and VPC-CG10GX.

Any information regarding only one of these products will be labeled as such.

iEnglish

HOW TO READ THIS MANUAL

For first-time users

Please read the sections on “SETUP” and “SIMPLE” in this manual,

as well as the included “QUICK GUIDE” to familiarize yourself with

your camera’s operation.

↓

To use the various camera features

Please read the sections on “NORMAL” and “OPTION SETTINGS” in

this manual. To connect the camera to a computer or view images on

a TV, please read the section on “OTHER DEVICES AND

CONNECTIONS” in this manual.

↓

To use additional features

Visit the Sanyo website to learn how to adjust the camera settings for

various shooting scenes. There you’ll also find information about the

software for playing back data recorded with your camera and for

burning (recording) DVDs (page 151).

You may find the answers to questions or problems concerning camera

operation in the sections “COMMONLY ASKED QUESTIONS” (page 164)

and “TROUBLESHOOTING” (page 172).

Symbols used in this manual

HINT Points giving some extended instructions or special points to pay

attention to.

CAUTION Points that require special attention.

(page xx) Refer to the page indicated for detailed information.

English ii

SHOOT, PLAY BACK AND SAVE

Preparing the camera

1 Insert the battery pack.

2 Insert the SD Memory Card.

hAn SD Memory Card is not included with your camera. Please

purchase a commercially sold card.

hIn this manual, the SD Memory Card is referred to as the “card”.

1While pressing, push

towards the bottom.

2Open

3Insert by matching the

connector markings

4Close

Battery cover

Connector

markings

Monitor unit

1Open

Card slot cover

2Open

Card

3Insert

4Close

iii English

SHOOT, PLAY BACK AND SAVE

Shooting

1 Press the ON/OFF button

for at least 1 second to turn

the camera on.

hIf the screen to set the

date and time appears,

press the MENU button 2

times to cancel it.

For how to set the date

and time, see page 33.

2 Record.

To record a video clip:

hPress the [ ] button to

begin recording a video

clip.

hPress the [ ] button

again to end the

recording.

To take a photo:

hPress the [ ] button.

hA still image is captured.

-S

357 00:13:51

ON/OFF button

[]button

[ ] button

MENU button

English iv

Before capturing those important shots, be sure to first take a

test shot to confirm that your camera is set up and ready to go

Sanyo declines any claim for compensation for recorded contents etc. in case

of photographing or recording failure due to a chance camera or card flaw.

Playback

Press the REC/PLAY

button.

The display changes to

the Playback Screen.

Select the image to play

back.

hToggle the SET button

left, right, up or down to

move the orange frame

to the image you wish to

play back.

hThe image information

for the framed image is

shown at the bottom of

the screen.

HD-SHQ

100-0006

00:00:05

6.5MB

2009.12.24 18:41

SET button

REC/PLAY button

Remaining battery power idication

Orange frame

vEnglish

SHOOT, PLAY BACK AND SAVE

3 Press the SET button.

hPlayback begins.

hPress the REC/PLAY button.

When you are finished using the camera...

Press the ON/OFF button for at least 1 second to turn the camera off.

English vi

Copy files to the computer (Windows XP)

Connect your camera to a computer, and copy files to the computer.

1 Turn on the computer, and use the supplied dedicated USB interface

cable to connect your camera to the computer.

hConnect the cable between the camera’s USB/AV terminal and the

computer’s USB connector.

2 Turn on the camera (page 30).

hThe USB Connection Screen appears on the camera’s monitor.

3 Select “COMPUTER”, and press the SET button.

hThe screen to select the computer connection mode appears.

COMPUTER

PRINTER

CANCEL

OKCANCEL

USB CONNECTION

To USB/AV terminalTo USB connector on

the computer

Supplied

dedicated USB

interface cable

SET button

vii English

SHOOT, PLAY BACK AND SAVE

4 Select “CARD READER”, and press the SET button.

hThe message [Found New Hardware] appears in the task tray,

showing that the camera is recognized as a drive.

hThe card is recognized (mounted) as a disk, and the [XACTI (E:)] icon

appears in the [My Computer] window.

hThe drive name (E:) may be different on your computer.

hClick on [Exit] to cancel the access menu.

5 Select an action.

hIf the [XACTI (E:)] window appears automatically, select the desired

procedure from the window.

6 Copy files from the camera to a computer.

English viii

Dismounting the camera

CAUTION

iTo disconnect your camera, be sure to follow the procedure below. Failure

to follow this procedure may cause faulty operation of your computer or

corrupt the files in your camera.

1 Left-click on the icon for safely removing hardware in the task tray.

hA list appears showing the devices connected to the computer’s USB

connector.

2 Left-click on the camera drive (E:).

hThe camera can now be disconnected.

hThe drive name (E:) may be different on your computer.

No software is included with this camera. Instructions for obtaining

the software can be found on page 152.

1English

CONTENTS

HOW TO READ THIS MANUAL ............................................................. i

QUICK SEARCH BY OPERATION ........................................................ 6

CHECKING THE INCLUDED ACCESSORIES .................................... 11

How to use the accessories .......................................................... 13

ABOUT THE CARD ............................................................................. 14

Media cards that can be used with this camera ............................ 14

What “card” means in this manual ................................................ 14

GETTING THE MOST OUT OF YOUR CAMERA ............................... 15

High-quality images with “High Definition” .................................... 15

Includes SIMPLE mode for quick-and-easy operation .................. 16

Image stabilizer for sharp pictures ................................................ 16

Sharp face shots ........................................................................... 17

SYSTEM MAP ..................................................................................... 18

SETUP

PARTS NAMES ................................................................................... 19

CHARGING THE BATTERY PACK ..................................................... 21

Charging the battery pack ............................................................. 22

INSTALLING THE CARD ..................................................................... 24

INSTALLING THE BATTERY PACK .................................................... 26

Installing the DC adaptor (sold separately: VAR-A3U/A3EX) ....... 27

About the temperature alert icon \ .......................................... 29

TURNING THE CAMERA ON AND OFF ............................................. 30

Turning on the camera .................................................................. 30

Turning on the camera when the power save (sleep) mode is

active ........................................................................................ 31

Turning off the camera .................................................................. 32

DATE AND TIME SETTING ................................................................. 33

SWITCHING BETWEEN THE RECORDING MODE AND

PLAYBACK MODE .......................................................................... 36

SWITCHING THE OPERATING MODE .............................................. 37

Switching between the SIMPLE and NORMAL modes ................ 37

Accessing/exiting the SIMPLE/NORMAL Mode Menu Screen ..... 38

Overview of the SIMPLE Mode Setting Screen ............................ 43

Overview of the NORMAL Mode Setting Screen .......................... 47
