Santec MPM-210 Manual de usuario

Multi-port Optical Power Meter

Operation Manual

MPM-210

MPM-210 Operation Manual

Trademarks

is a trademark of Santec Corporation.

MPM-210, MPM-211,MPM-212 and MPM-213 are trademark of Santec Corporation.

Notes to Users

Manual may be reproduced or transmitted in any form or by any means, electronic

or mechanical, for any purpose, without the prior written permission of Santec.

2) Information in this Operation Manual is subject to change without notice.

3) Information of this Operation Manual is prepared with careful examination, however,

in the event of any mistake, please contact us.

Notes in Bringing This Product Out of Japan

1) When this product is brought out of Japan, some laws or regulations of a destination

country may prohibit this product from being used there. In such countries, the use

of this product may lead to punishment. Please note, that in such cases Santec

Corporation shall not be held responsible in anyway.

2) When this product is exported (or brought out of Japan), and this product is applicable

to a strategic material specied in the “Foreign Exchange and Foreign Trade Control

Law”, then under law of the Japanese Government, an export permit is required.

Multi-Port Optical Power Meter MPM-210

The packing materials and box of this product are needed for long-term storage or

transportation; keep them in a safe place after unpacking the product.

NOTE

Introduction

Thank you very much for purchasing our product, the Santec Multi-Port Optical

Power Meter MPM Series. This Operation Manual contains the necessary information

for proper operation of the MPM-210, and it is intended for those with sufficient

knowledge about the dangers of lasers and their safe control. Before operating

the MPM-210, you should first read thoroughly through this Operation Manual and

become familiar with its contents. After reading this Operation Manual, keep it close

by for an easy reference anytime.

MPM-210 Operation Manual

How to Read the Manual

Before operating the MPM-210, please read this instruction manual carefully.

This Operation Manual consists of 11 Chapters:

Chapters 1 to 4 illustrate the outline of the product, safety precautions, and installation.

Chapter 5 explains information on communication functions such as external control

of the MPM-210.

Chapter 6 explains the trigger functions.

Chapter 7 explains the analog output (MPM-212).

Chapter 8 explains the specications.

Chapter 9 describes the maintenance and storage methods of the product.

Chapter 10 explains the packing instructions and shipping.

Chapter 11 describes the troubleshooting.

Before using this product, please carefully read this Operation Manual.

NOTE

Multi-Port Optical Power Meter MPM-210

Explanation of Terms

The meanings of the following terms used in this Operation Manual are defined as below:

(1) Meaning

Markings on the instrument

 　　　　　This mark is used on the equipment as warning of danger.

(2) Importance of Information

From the above meanings, the priority of the terms here are as shown below:

DANGER > WARNING > CAUTION > NOTE

NOTE

This indicates pressing DANGER, and if it

is not avoided, personnel death or serious

injury results, therefore, it is the most

emphasized special information.

This indicates potential danger, and if it is

not avoided, personnel death or serious

injury may result, therefore, it is special

information.

This indicates potential danger, and if it

is not avoided, mild or slight injury may

result, therefore, it is special information. It

also indicates potential danger leading to

only physical damage.

This indicates supplementary explanation

of the text, and thus other information than

DANGER, WARNING, and CAUTION.

CAUTION

WARNING!

DANGER!!

DANGER

WARNING

CAUTION

NOTE

MPM-210 Operation Manual

1. Introduction 1-1

2. Product Composition 2-1

3. Panel Description 3-1

3-1 Front Panel 3-1

3-2 MPM-211 (Power meter module 4 ports) 3-2

3-3 MPM-212 (Power meter module and analog output 2 ports) 3-3

3-4 MPM-213 (Current meter module 4 ports) 3-4

3-5 Rear Panel 3-5

4. Installation 4-1

4-1 Warning and Caution 4-1

4-2 Environment 4-1

4-3 Line Voltage Selection 4-1

4-4 Line Fuse 4-2

4-5 Line Cord 4-2

4-6 Zeroing option (To remove electrical offsets) 4-2

4-7 Maximum input optical power 4-3

4-8 Inserting a module 4-3

5. Remote Control 5-1

5-1 GPIB Communication 5-1

5-2 TCP/IP Communication 5-1

5-3 RS-232 Communication 5-2

5-3-1 RS-232 Communication Set up 5-2

5-3-2 RS-232 Connection 5-2

5-4 Commands Form 5-3

5-5 Commands 5-4

5-5-1 Command compatible with the previous MPM-200 model 5-4

Contents

Introduction

How to Read the Manual

Instrument Markings

Explanation of Terms

Multi-Port Optical Power Meter MPM-210

5-5-2 System-related commands 5-5

5-5-3 Measurement-related commands 5-8

5-5-4 ERR? 5-16

5-5-5 A method for wavelength compensation 5-17

5-5-6 LEV/LEV? 5-18

5-6 Logging mode 5-18

5-6-1 Measurement mode (WMOD) 5-18

5-6-2 Fast Gain Switching Average Time 5-19

5-6-3 Measurement data point setting (LOGN) 5-19

5-6-4 LOGG? 5-20

5-6-5 “FREERUN” measurement mode (CEM Mode) 5-23

5-6-6 Sample code for FREERUN Commnad 5-24

5-6-7 Sample code for SME mode measurement 5-25

6. Trigger Input/Output 6-1

6-1 Trigger Input 6-1

6-2 Trigger Output 6-1

7. Analog Output (MPM-212) 7-1

8. Specications 8-1

9. Maintenance 9-1

9-1 Daily Maintenance 9-1

9-2 Cleaning the Optical Power Sensor 9-1

9-3 Replacing Fuses 9-1

9-4 Long-Term Storage 9-1

10. Re-packing and Shipping 10-1

10-1 Re-packing 10-1

10-2 Shipping 10-1

11. Troubleshooting 11-1

MPM-210 Operation Manual

Multi-Port Optical Power Meter MPM-210

1-1

Introduction

The MPM-210 is a multi-port optical power meter for measuring optical characteristic

of optical devices. The MPM-210 is composed of up to five MPM-211/MPM-212/

MPM213 Measurement Modules (MM). There are three types of measurement

modules: MPM-211, MPM-212 and MPM-213.

The MPM-211 MM has 4 optical power measuring ports (4 channels). The MPM-

212 has 2 optical power measuring ports and 2 analog output ports and outputs

analog voltage signal proportional the optical power per each port. The MPM-213

has 4 electrical current measuring ports (4 channels), and is used as same as MPM-

211. The MPM-210 doesn’t have front panel nor display window but it can be easily

operated by remote control. The MPM-210 is controllable by using GPIB, LAN,

RS232 communication and users can interlock the system with other system (santec,

Tunable Laser, TSL-550 or TSL-710 and Polarization Controller PCU-100) and operate

it for measuring PDL and IL. Commands for controlling the MPM-210 are listed and

described in section 5.5.

1-2

MPM-210 Operation Manual
