Sangean DPR-99 Plus Manual de usuario

DNLEFGB

Revision 2

DPR-99+

Contents

Controls ......................................................................... 2-3

Battery operation ........................................................... 4-5

Using the AC adaptor ........................................................ 5

Operating your radio - DAB .............................................. 6

Selecting a station - DAB .................................................. 7

Secondary services - DAB ................................................ 7

Display modes - DAB ........................................................ 8

Finding new stations - DAB .............................................. 9

Signal strength display - DAB .......................................... 9

Manual tuning - DAB ....................................................... 10

Autoselect - DAB ............................................................ 10

ynamic range control - DAB ......................................... 11

Operating your radio - FM ............................................... 12

Manual tuning - FM ......................................................... 13

Display modes - FM ........................................................ 14

Presetting stations .......................................................... 15

Stereo / Mono setting - FM ............................................. 16

Scan sensitivity setting - FM ........................................... 17

Software version ............................................................. 18

System reset ................................................................... 18

Headphone socket ......................................................... 19

Display backlight ............................................................. 19

A few words about batteries ...................................... 20-21

General ............................................................................ 22

Specications .................................................................. 23

Circuit features ............................................................... 23

Controls

1. Loudspeaker

2. Band button

3. LCD display

4. Charge LED indicator

5. Auto Tune button

6. Menu/Info button

7. On/Off button

8. Volume control

9. Tuning Up/Down buttons

10. Select button

11. Preset buttons

(Front)

Controls

(Back)

12. Battery compartment

13. Telescopic aerial

14. Headphone socket

15. DC jack socket

Battery operation using alkaline batteries

1. Remove the battery cover on the back of the unit by sliding the cover

in the direction of the arrow.

2. Insert six LR6 (AA size) alkaline batteries into the spaces in the

compartment. Take care to ensure all batteries are inserted with the

correct polarity as shown inside the battery compartment.

3. Slide the battery switch to the Alkaline position and then replace the

battery cover.

●Important: when using alkaline batteries the battery switch

must be placed in the alkaline position. Failure to do so could

result in serious damage to the batteries or radio.

●Reduced power, distortion and a 'tuttering' sound are all signs that

the batteries may need replacing.

●If the radio is not to be used for any extended period of time it is

recommended that the batteries are removed from the radio.

●We would recommend for economy that the radio is used via the AC

adaptor whenever possible with battery operation for occasional or

stand-by use only. If extended listening using batteries is anticipated,

then the use of rechargeable batteries is recommended.

Battery operation using rechargeable batteries

1. Remove the battery cover on the back of the unit by sliding the cover

in the direction of the arrow.

2. Insert six Rechargeable LR6 (AA size) batteries into the spaces

in the compartment. Take care to ensure all batteries are inserted

with the correct polarity as shown inside the battery compartment.

The radio is designed to be used with Nickel Metal Hydride (NiMH)

rechargeable batteries.

3. Slide the battery switch to the Rechargeable position and then

replace the battery cover.

4. The charge indicator lights to show that the batteries are charging.

Batteries will be fully charged in around 7 hours.

●Important: when using rechargeable batteries the battery switch

must be placed in the rechargeable position. Batteries will only

be charged when the radio is switched off and connected to the

AC adaptor.

●Reduced power, distortion or your radio switching off by itself are all

signs that the batteries may need recharging.

●If the radio is not to be used for any extended period of time it is

recommended that the batteries are removed from the radio.

IMPORTANT: The batteries should not be exposed to excessive

heat such as sunshine, fire or the like. After use, disposable

batteries should if possible be taken to a suitable recycling centre.

On no account should batteries be disposed of by incineration.

Using the AC adaptor

The AC adaptor for use with the radio should provide 12 volts DC output

at 1 amp, centre pin positive.

1. Insert the adaptor plug into the DC in socket on the left hand side of

your radio.

2. Plug the adaptor into a standard 13A mains socket outlet. Whenever

the adaptor is plugged in to the radio and switched on at the mains

the batteries are automatically disconnected. If the adaptor is

plugged in to the radio but not switched on then the radio will run

from the batteries if tted. The AC adaptor should be disconnected

from the mains supply and the radio when not in use.

●IMPORTANT: The mains adaptor is used as the means of

connecting the radio to the mains supply. The mains socket used

for the radio must remain accessible during normal use. In order to

disconnect the radio from the mains completely, the mains adaptor

should be removed from the mains socket outlet completely.

Operating your radio - DAB

1. Carefully extend the telescopic aerial.

2. Press the On/Off button to switch on your radio. The display will

show “Welcome to Digital Radio” for a few seconds.

3. If this is the first time the radio is used to scan of Band III DAB

channels will be carried out, known as Auto-tune. The display will

show “Welcome to DAB”.

4. During Auto-tune, the lower line of the display shows a bar graph

indicating progress of auto-tune. If the radio has been used before,

then the last used station will be selected instead of the Auto-tune

process.

5. When the Auto-tune is completed the rst station found (in numeric-

alpha order 0...9...A....Z) will be selected.

6. If the station list is still empty after the Auto-tune your radio will

display “No DAB station”.

7. If no stations are found it may be necessary to relocate your radio to

a position giving better reception.

Selecting a station - DAB

1. The top line of the display shows the name of the station currently selected.

2. Press either of the Tuning Up or Down buttons to scroll through the

list of available stations.

3. Press and release the Select button to select the station. The display

may show “Now tuning” while your radio nds the new station.

4. Adjust the Volume control to the required setting.

Note:

If after selecting a station the display shows “Service not available”

it may be necessary to relocate your radio to a position giving better

reception.

Secondary services - DAB

1. Certain radio stations have one or more secondary services

associated with them. If a station has a secondary service

associated with it the display will show “>>” next to the station

name on the station list. The secondary service will then appear

immediately after the primary service as you press the Tuning Up

button.

2. Press the Select control to select the station.

Display modes – DAB

Your clock radio has a range of display modes:-

1. Press and release the Info button to cycle through the various modes.

a. Scrolling text Displays scrolling text messages such as

artist/track name, phone in number, etc.

b. Programme type Displays type of station being listened to

e.g. Pop, Classic, News, etc.

c. Multiplex name Displays name of the DAB multiplex to

which the current station belongs.

d. Time and date Displays current time and date.

e. Channel and

frequency

Displays channel and frequency for the

station being listened to.

f. Audio type and

bit rate

Displays audio type and bit rate for the

station being listened to.

g. Signal strength Displays signal strength for the station

being listened to.

Finding new stations - DAB

As time passes new stations may become available. To find new

stations proceed as follows:-

1. Press and release the Auto Tune button, the display will show

“Scanning”. Your radio will perform a scan of the DAB III frequencies.

As new stations are found the station counter on the right-hand side

of the display will increase and stations will be added to the list.

Signal strength display - DAB

1. Repeatedly press and release the Info button until the display shows

the signal strength.

2. Position your radio and carefully angle the telescopic aerial for

best reception using the signal strength display as a guide. Move

your radio around and position it so as to give maximum number of

black rectangles on the signal strength display. The clear unfilled

rectangle indicates the minimum signal level required for satisfactory

reception.

3. Press the Info button to exit the signal strength display.
