QUICK

START

GUIDE

ET-YO324

Gear VR Controller

Printed in Korea

GH68-47658B Rev.1.0

EU/ASIA Type 02/2017

Bluetooth

is a registered trademark of

Bluetooth SIG, Inc. worldwide.

•

Please read this guide before using the device

to ensure safe and proper use.

•

Images may differ in appearance from the

actual product. Content is subject to change

without prior notice. You can access the

full user manual for more information. Visit

www.samsung.com

to view device information,

the user manual, and more.

•

Before using the controller, make sure it is

compatible with your device.

•

To view the open source licence for the

controller, refer to

opensource.samsung.com

•

Your consumer rights are governed by the law

of the country in which you purchased the

product. Please contact your service provider

for more information.

Device layout

Touchpad Wrist strap

connection hole

Trigger Battery

compartment

Back key Battery cover

Home key Wrist strap

Volume key Controller holder

Indicator light

Colour Status

Flashes red, green,

and blue

The controller is in

Bluetooth pairing mode.

Flashes blue three

times Bluetooth is connected.

Flashes blue one

time

Sleep mode is

deactivated.

About the Gear VR controller

You can connect the controller to a mobile device

connected with a Gear VR via Bluetooth. Control

various Gear VR features with the controller keys

and touchpad.

Connecting the wrist strap

When you connect the wrist strap to your

controller, you can use the controller safely

without dropping it.

1. While pressing on the backside of the

controller, slide the battery cover towards the

top of the triangle to open it.

Do not bend or twist the battery cover

excessively. Doing so may damage the

battery cover.

2. Insert the wrist strap loop into the wrist strap

connection hole and attach it to the hook to

secure it. ( )

Installing the batteries

1. Insert batteries with the positive and negative

terminals properly aligned with the + and -

symbols on the controller.

2. Place the battery cover on the controller and

slide the battery cover back until it clicks back

into place.

•

If the indicator light flashes red while

using the controller, replace the

batteries.

•

Do not recharge the provided batteries

(AAA batteries).

Using the controller

1. Controller Press and hold the Home key to

enter Bluetooth pairing mode.

The indicator light will flash red, green, and

blue.

2. Mobile device After activating

the Bluetooth feature, tap Gear VR

Controller(0000) on the list of available

devices to complete Bluetooth pairing.

The indicator light will flash blue three times.

3. Connect your mobile device to the Gear VR

and control the Gear VR with the controller’s

keys and touchpad.

•

The PIN for the controller is the four-

digit number in parenthesis displayed

on the other device’s Bluetooth settings

screen. The number differs depending

on the controller.

•

You can take photos and record videos

with your controller after connecting it

to the Gear 360 via Bluetooth.

Storing the controller

If you use the controller with the Gear VR, attach

the controller holder to the Gear VR and put your

controller in it for storage.

Insert the controller into the controller

holder properly. If it is not securely

inserted, the controller may accidentally

separate from the controller and become

damaged.

If you do not use the controller for an

extended period, store the controller

after removing the batteries.

Safety information

Read all safety information before using the

device to ensure safe and proper use. To view

the full safety information, refer to the Samsung

website.

Use manufacturer-approved batteries,

accessories, and supplies

Do not touch the device with wet hands

Do not drop or cause an impact to the device

Do not bend or twist the device excessively

The device can be used in locations with an

ambient temperature of 0 °C to 35 °C. You can

store the device at an ambient temperature

of -20 °C to 50 °C. Using or storing the device

outside of the recommended temperature

ranges may damage the device or reduce the

battery’s lifespan

Use the device only for their intended

purposes

Do not allow children or animals to chew or

suck the device

Do not disassemble, modify, or repair your

device

Correct disposal

This marking on the product,

accessories or literature

indicates that the product and

its electronic accessories (e.g.

charger, headset, USB cable)

should not be disposed of with

other household waste.

This product is RoHS compliant.

This marking on the battery,

manual or packaging indicates

that the batteries in this product

should not be disposed of with

other household waste.

For information on Samsung’s environmental

commitments and product-specific regulatory

obligations, e.g. REACH, WEEE, Batteries, visit

samsung.com/uk/aboutsamsung/

samsungelectronics/corporatecitizenship/

data_corner.html
