Samsung SC7803 Manual de usuario
VACUUM CLEANER
❈Before operating this unit, please read the instructions carefully.
❈Indoor use only.
Operating Instructions
EN
Mode d’emploi
FR
Gebruiksaanwijzing
NL
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 1
IMPORTANT SAFEGUARDS
1. Read all instructions carefully. Before switching on, make sure that the voltage of your
electricity supply is the same as that indicated on the rating plate on the bottom of the
cleaner.
2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.
Do not use to suck up water.
3. Close supervision is necessary when any appliance is used by or near children. Do not
allow the vacuum cleaner to be used as a toy. Do not allow the vacuum cleaner to run
unattended at any time. Use the vacuum cleaner only for its intended use as described in
these instructions.
4. Do not use the vacuum cleaner without a dust bag(dust bin). Empty the dust bin before it
is full in order to maintain the best efficiency.
5. Do not use the vacuum cleaner to pick up matches,live ashes or cigarette butts. Keep the
vacuum cleaner away from stoves and other heat sources. Heat can deform and dis-
colour the plastic parts of the unit.
6. Avoid picking up hard,sharp objects with the vacuum cleaner as they may damage the
cleaner parts. Do not stand on the hose assembly. Do not put a weight on the hose. Do
not block the suction or the exhaust port.
7. Switch the vacuum cleaner off on the body of the machine before unplugging from the
electrical outlet. Disconnect plug from the electrical outlet before changing the dust bag or
dust container. To avoid damage, please remove the plug by grasping the plug itself, not
by pulling on the cord.
8. The plug must be removed from the socket outlet before cleaning or maintaining the appli-
ance.
9. The use of an extension cord is not recommended.
10. If your vacuum cleaner is not operating correctly,switch off the power supply and consult
an authorized service agent.
11. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
12. Don’t carry the vacuum cleaner by holding the hose.
Use the handle on the vacuum cleaner set.
EN-1
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 2
1ASSEMBLING THE CLEANER
Features may vary according to model.
▼
For storage, park the floor nozzle.
OPTION
EN-2
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 3
2OPERATING THE CLEANER
2-1 POWER CORD 2-2 ON/OFF SWITCH
2-3 POWER CONTROL
NOTE
When removing the
plug from the
electrical outlet,grasp the
plug,not the cord.
MIN = For delicate surface e.g. net curtains.
MAX = For hard floors and heavily soiled carpets.
2-4 AIR CONTROL
To reduce suction for cleaning draperies, small
rugs, and other light fabrics, pull the tap air until
the hole is open.
EN-3
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 4
- Detach transparent drum
cover for easy cleaning.
- Transparent tube
CREVICE
DUSTING
UPHOLSTERY
2-5 USING FLOOR TOOLS
Carpets
Bare floors
OPTION
OPTION
EN-4
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 5
3-1 CHANGING THE DUST BAG
3INDICATOR LIGHTS (BAG TYPE)
When the indicator light comes on,
please change the DUST BAG(3-1)
as shown in the following illustrations.
134
25
OPTIONAL
• FOR CLOTH BAG
After using, if the cloth bag is full of dust, clean the cloth bag and use it again.
NOTE
Please make sure to retain the support-filter when you dispose of the dust bag.
NOTE
A used dust bag can be sealed by removing the paper from the adhesive strip and
sealing the strip over the hole.
support-filter support-filter
EN-5
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 6
4
INDICATOR LIGHTS (CASSETTE FILTER TYPE)
1 2 3
4 5 6
78
NOTE
The Cyclone Filter must
be used at all times to
retain optimum efficiency.
4-1 CLEANING THE CYCLONE FILTER
When the indicator light comes on, please empty
and clean the Cyclone Filter (4-1) and the cassette
filter (4-2) as shown in the following illustrations.
OPTIONAL
DIGITAL SIGNAL
EN-6
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 7
NOTE
You can rinse the cassette filter with water.
Do not immerse the whole cleaner in water.
Ensure completely dry before replacing.
1 2 3 4
5 6 7
4-2 CLEANING THE CASSETTE FILTER
4-2-1 EMPTYING THE CASSETTE FILTER
21 3 4
5 6 7 8
4-2-2 CLEANING THE GRILL
EN-7
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 8
5CLEANING THE INLET FILTER
123
6
4 5
5-1 BAG TYPE
NOTE :
Please do not throw away the filter. It must be retained to maintain cleaning efficiency.
123
4 5
NOTE
Please do not throw
away the filter. It must
be retained to maintain
cleaning efficiency.
5-2 CASSETTE FILTER TYPE
EN-8
DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 9
6OUTLET FILTER
- MICRO FILTER
Remove and replace the blocked outlet-filter.
NOTE :
Replacement filters or bags can be bought from your local Samsung distributor.
OPTION - CARBON FILTER
OPTION - HEPA-FILTER
EN-9
