Samsung SC7053 Manual de usuario

Operating Instructions

VACUUM CLEANER

❈Before operating this unit, please read the instructions carefully.

❈For indoor use only.

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 1

1ASSEMBLING THE CLEANER

Features may vary according to model.

▼

For storage, park the floor nozzle.

EN-1

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 2

2OPERATING YOUR CLEANER

2-1 POWER CORD

2-2 HANDLE CONTROLTYPE ONLY

2-3 USING CYCLONE FILTER

NOTE

When removing the plug

from the socket, please

take care to grasp the

plug, not the cord in order

to avoid undue stress.

• SLIDETOTHE STOP POSITION

Vacuum-cleaner switches off (stand by mode)

• SLIDE FORWARDTO MAX

Suction capacity increases smoothly up to maximum.

EN-2

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 3

2-4 USING FLOORTOOLS

-TRANSPARENT TUBE

PARQUET SPECIALIST

CREVICE

3CHECK FILTER INDICATOR

When the light is illuminated, check

the Cassette Filter and clean it.

OPTION

HARD FLOOR

OPTION

OPTIONAL (Dust Bag type)

Check the Dust bag and change it.

DUSTING

UPHOLSTERY

EN-3

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 4

MAINTAINING THE CASSETTE FILTER

NOTE

The cassette filter should be washed thoroughly as well as emptied if:

•

the CHECK FILTER indicator lights continuously

•

the suction power feels weaker than normal

•

the Turbo Brush (optional) is not working properly

1 2 3

6 5 4

7 8 9

4-1 EMPTYINGTHE CASSETTE FILTER(Optional)

•Ensure completely dry

before replacing.

•Allow 12 hours for it to dry.

•Brush the Filter media with

water until the stuck fine

dust is removed.

EN-4

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 5

CLEANING THE CYCLONE FILTER (Optional)

- CLEANINGTHE INNER PART OF CYCLONE FILTER

NOTE

It is necessary to use

Cyclone Filter while cleaning.

1 2 3

4 5 6

12 3

OPTIONAL

●FOR CLOTH FILTER BAG

After using, if the cloth bag is full of dust, clean the cloth filter bag and use it again.

4-2 CHANGINGTHE DUST BAG (Optional)

VP-95B TYPE

EN-5

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 6

6CLEANING THE INLET FILTER

7OUTLET FILTER

1 2 3

PROBLEM CAUSE REMEDY 0

- IFYOU HAVE A PROBLEM

Motor does not start.

No power supply.

Thermal cut-out.

Check cable, plug and socket.

Leave to cool.

Suction force is gradually

decreasing. Nozzle, suction hose or tube

is blocked. Remove the object and

empty/wash cassette filter as

required.

Cord does not rewind fully. Check that the cord is not

twisted or wound unevenly. Pull the cord out 2-3m and

push down the cord rewind

button.

Vacuum cleaner does not

pick up dirt.

Crack or hole in hose.

Check hose and replace if

required.

NOTE :

Do not allow the filter to become clogged as this may cause power reduc-

tion or may damage the motor.

EN-6

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 7

IMPORTANT SAFEGUARDS

1. Read all instructions carefully. Before switching on, make sure that the voltage of your

electricity supply is the same as that indicated on the rating plate on the bottom of the

cleaner.

2.WARNING: Do not use the vacuum cleaner when rug or floor is wet.

Do not use to suck up water.

3. Close supervision is necessary when any appliance is used by or near children. Do not

allow the vacuum cleaner to be used as a toy. Do not allow the vacuum cleaner to run

unattended at any time. Use the vacuum cleaner only for its intended use as described in

these instructions.

4. Do not use the vacuum cleaner without Cassette Filter. Empty the Cassette Filter before it

is full in order to maintain the best efficiency.

5. Do not use the vacuum cleaner to pick up matches, live ashes or cigarette butts. Keep the

vacuum cleaner away from stoves and other heat sources. Heat can deform and discolour

the plastic parts of the unit.

6. Avoid picking up hard, sharp objects with the vacuum cleaner as they may damage the

cleaner parts. Do not stand on the hose assembly. Do not put a weight on the hose. Do

not block the suction or the exhaustion part.

7. Switch the vacuum cleaner off at the machine before unplugging from the electrical outlet.

Grasp the plug to disconnect cord from the electrical outlet before caring Cassette Filter

and filters.

8.The plug must be removed from the socket out-let before cleaning or maintaining the

appliance.

9.The use of an extension cord is not recommended.

10. If your vacuum cleaner is not operating correctly, switch off the power supply and consult

an authorized service agent.

11. If the supply cord is damaged, it must be replaced by the manufacturer or its service

agent or a similarly qualified person in order to avoid a hazard.

EN-7

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 8

Instrucciones de

funcionamiento

ASPIRADORA

❈Antes de poner en marcha esta unidad, lea detenidamente las instrucciones.

❈Sólo para uso en interiores.

Gane premios cuando registre su producto en www.samsung.com/global/register

DJ68-00178X(EN+ES)-0.0 3/16/05 2:29 PM Page 9

1MONTAJE DE LAASPIRADORA

Las características pueden variar en función del modelo.

▼

Para guardarla, quite el accesorio

para el suelo.

ES-1
