1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
6-1. S/W Download
7. Level 2Repair
7-1. Disassembly and Assembly Instructions
7-2. Calibration
7-3. IMEI/ESN Writing
8. Level 3Repair
8-1. Block Diagram
8-2. PCB Diagram
8-3. Troubleshooting
8-4. Service Schematics
9. Reference data
GSM TELEPHONE CONTENTS
SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test, because the specification of cellular phone is sensitive for
surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.
SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. Otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.
SAMSUNG Proprietary-Contents may change without notice
2. Specification
This Document can not be used without Samsung's authorization
2-1
2-1. GSM General Specification
GSM 850 EGSM 900 DCS1800 PCS1900 W-CDMA
900 W-CDMA
2100
Freq. Band[MHz]
Uplink/Downlink 824~849
869~894 880~915
925~960 1710~1785
1805~1880 1850~1910
1930~1990 880-915
925-960 1920~1980
2110~2170
ARFCN range 128~25 0~124 &
975~1023 512~885 512~810 UL:2712-2863
DL: 2937
-3088
UL:9612~9888
DL:10562~
10838
Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz 45MHz 130MHz
Mod. Bit rate/
Bit Period 270.833kbps
3.692us 270.833kbps
3.692us 270.833kbps
3.692us 270.833kbps
3.692us 3.84Mcps 3.84Mcps
Time Slot
Period/Frame
Period
576.9us
4.615ms 576.9us
4.615ms 576.9us
4.615ms 576.9us
4.615ms
Frame length:
10ms
Slot length :
0.667ms
Frame length:
10ms
Slot length :
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSK
HQPSK QPSK
HQPSK
MS Power 33dBm
~5dBm 33dBm
~5dBm 30dBm
~0dBm 30dBm
~0dBm 24dBm ~ -
50dBm 24dBm ~ -
50dBm
Power Class 4
(max
+33dBm)
4
(max
+33dBm)
1
(max
+30dBm)
1
(max
+30dBm)
3
(max +24dBm) 3
(max +24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm
TDMAMux8888 - -
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km
SAMSUNG Proprietary-Contents may change without notice
Specification
2-2
This Document can not be used without Samsung's authorization
TX Power
control level GSM850
GSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3 dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
2-2. GSM Tx Power Class
SAMSUNG Proprietary-Contents may change without notice
3. Product Function
3-1
This Document can not be used without Samsung's authorization
Main Function
－HSDPA /HSUPA/ UMTS, EDGE, GPRS
－MP3 /40Poly Melody
－BT 2.1 + EDR
－Video Sharing /Streaming
－USB 2.0
－WAP2.0, JAVA, MPEG4
－MIDP 2.0 / CLDC 1.1
－Auto Time Setting,
－MMS /SMS
－Weight: 109g
－Camera: 3.2 Mega Pixel, CMOS
－LCD : 2.62" TFT (LCD)
－Size: 114.9x59x10.8 mm
－GPRS/EDGE :class 12
－Battery: 1500mAH
－Memory: 256MB DDR +512
MB ROM
－Band: GSM 850/900/1800/1900, FDD1, FDD8
－BB: Qualcomm MSM7225
－RF: Qualcomm RTR6285
－WLAN 802.11 b/g
－A-GPS
SAMSUNG Proprietary-Contents may change without notice
4. Exploded View and Parts List
4-1
This Document can not be used without Samsung's authorization
4-1. Cellular phone Exploded View
SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
4-2
This Document can not be used without Samsung's authorization
Design LOC Discription SEC CODE
QCR101 SCREW-MACHINE 6001-002005
QLC01 LCD-L5F30977 GH07-01446A
QAN02 INTENNA-MAIN(GT-B7330B) GH42-02414A
QSP01 MODULE-SPK+ENCLOSURE (GT-B7330) GH59-07783A
QMW02 PCT WINDOW-MAIN_CANADA GH72-58030A
QMP01 A/S ASSY-PBA MAIN(CNDA)GT-B7330B GH82-04763A
QCA01 ASSY CAMERA-CAM MOD ASSY,GT-B7330(3M) GH96-03957A
QVO01 ASSY KEY-VOL GH98-13565A
QCK01 ASSY KEY-CAM GH98-13566A
QBC00 ASSY COVER-BATT GH98-14193A
QFR01 ASSY CASE-FRONT GH98-16282A
QME01 KEY FPCB-GT-B7330 GH59-07785A
QMI03 RMO RUBBER-MIC GH73-13228A
QLB01 ASSY BRACKET-LCD GH98-16097A
QKP01 ASSY KEYPAD-(BLK/BMC) GH98-16491A
QRE01 ASSY CASE-REAR GH98-13563A
QIF01 PMO COVER-IF GH72-54474A
QSD01 PMO COVER-SD GH72-54475A
QCW01 PCT WINDOW-CAM GH72-54483A
QCD01 ASSY DECO-CAM GH98-14192A
4-2. Cellular phone Parts list
SAMSUNG Proprietary-Contents may change without notice
5. MAIN Electrical Parts List
5-1
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
0403-001741 ZD603 DIODE-ZENER
0404-001245 D700 DIODE-SCHOTTKY
0406-001167 ZD507 DIODE-TVS
0406-001167 ZD508 DIODE-TVS
0406-001267 D600 DIODE-TVS
0406-001267 ZD500 DIODE-TVS
0406-001267 ZD501 DIODE-TVS
0406-001267 ZD504 DIODE-TVS
0406-001267 ZD505 DIODE-TVS
0406-001267 ZD506 DIODE-TVS
0406-001267 ZD509 DIODE-TVS
0406-001267 ZD510 DIODE-TVS
0406-001281 ZD502 DIODE-TVS
0406-001281 ZD503 DIODE-TVS
0406-001369 ZD602 DIODE-TVS
0406-001375 ZD600 DIODE-TVS
0406-001375 ZD601 DIODE-TVS
0407-001002 D400 DIODE-ARRAY
0407-001002 D500 DIODE-ARRAY
0504-000168 TR401 TR-DIGITAL
0505-002088 Q600 FET-SILICON
0601-001905 LED500 LED
0801-003139 U203 IC-CMOS LOGIC
0801-003200 U301 IC-CMOS LOGIC
0801-003265 U300 IC-CMOS LOGIC
1001-001488 U501 IC-ANALOG SWITCH
1001-001580 U600 IC-ANALOG MULTIPLEX
1001-001593 U601 IC-ANALOG SWITCH
1108-000262 UME300 IC-MCP
1201-002856 U202 IC-RF AMP
1201-002864 U500 IC-AUDIO AMP
1201-002887 PAM200 IC-POWER AMP
1201-002888 PAM202 IC-POWER AMP
1201-002961 PAM100 IC-POWER AMP
1203-003924 U402 IC-VOL. DETECTOR
1203-004596 U701 IC-MULTI REG.
1203-004776 U704 IC-POSI.FIXED REG.
1203-004792 U705 IC-POSI.FIXED REG.
1203-004798 U502 IC-SWITCH VOL. REG.
1203-004802 U201 IC-POSI.FIXED REG.
1203-004818 U703 IC-POSI.FIXED REG.
1203-004945 U702 IC-MULTI REG.
1203-005092 U401 IC-POWER SUPERVISOR
SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-2
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
1203-005225 U706 IC-MULTI REG.
1203-005554 U405 IC-VOL. DETECTOR
1203-005689 U602 IC-BATTERY
1203-005916 U700 IC-BACKLIGHT DRIVER
1204-002746 U200 IC-TUNER
1205-003297 U100 IC-TRANSCEIVER
1205-003790 UCP300 IC-MODEM
1404-001221 TH400 THERMISTOR-NTC
2007-000138 R321 R-CHIP
2007-000141 R103 R-CHIP
2007-000148 R208 R-CHIP
2007-000148 R420 R-CHIP
2007-000171 R118 R-CHIP
2007-000174 R505 R-CHIP
2007-001217 R504 R-CHIP
2007-007008 R503 R-CHIP
2007-007014 R402 R-CHIP
2007-007014 R406 R-CHIP
2007-007190 R500 R-CHIP
2007-007190 R501 R-CHIP
2007-007309 R108 R-CHIP
2007-007310 R605 R-CHIP
2007-007317 R311 R-CHIP
2007-007317 R312 R-CHIP
2007-007318 R603 R-CHIP
2007-007468 R409 R-CHIP
2007-007798 R701 R-CHIP
2007-007798 R702 R-CHIP
2007-008045 R111 R-CHIP
2007-008045 R207 R-CHIP
2007-008045 R324 R-CHIP
2007-008045 R327 R-CHIP
2007-008045 R502 R-CHIP
2007-008045 R610 R-CHIP
2007-008046 R106 R-CHIP
2007-008046 R107 R-CHIP
2007-008049 R329 R-CHIP
2007-008055 R300 R-CHIP
2007-008055 R315 R-CHIP
2007-008055 R328 R-CHIP
2007-008055 R400 R-CHIP
2007-008055 R401 R-CHIP
2007-008055 R403 R-CHIP
