Samsung 840 EVO Manual de usuario

DATA SHEET

Rev. 1.1, August, 2013

Summary

-2.5” SATA 6Gb/s SSD for Desktop & Laptop PC

-Samsung 3-core MEX controller

-Samsung 1x nm Toggle DDR 2.0 NAND Flash

memory

-Up to 1GB Samsung Low Power DDR2 SDRAM

cache memory

-Samsung Magician 4.2 Software for SSD

management

-Samsung Data Migration 2.0 Software

-7mm profile

The must-have solution for

your PC upgrade

The evolution of the SSD has arrived as the

Samsung SSD 840 EVO with more speed, more

reliability and much easier upgrade tools.

Combining the best SSD technology from

Samsung, 840 EVO delivers a superior

computing experience.

Faster performance for everyday use

The market-leading 840 Series SSD was

significantly improved upon in the 840 EVO.

Samsung’s new TurboWrite technology delivers

dramatically faster sequential write performance.

And, with upgrades to NAND, a new controller

and firmware, the 840 EVO has superfast

responsiveness under everyday workloads.

Proven quality and trusted reliability

Samsung’s unparalleled end-to-end integration

allows us to deliver a reliable, high-performance

2nd generation 3-bit MLC SSD. The upgraded

firmware and advanced signal processing

guarantees the same level of endurance and

reliability as our previous generation, while

improving performance. The 840EVO’s ultra-low

power consumption helps extend laptop battery

life longer than before.

In addition, Samsung’s “Dynamic Thermal Guard”

algorithm in 840 EVO maintains optimal

operating temperature for the drive.

Samsung 840 EVO is backed by the same 3-year

limited warranty as the previous generation.

Samsung SSD 840 EVO

Data Sheet, Rev. 1.1 (August, 2013)

DATA SHEET

Rev. 1.1, August, 2013

Easier-than-ever upgrade tools

As SSDs become more main stream, it is

important to make the installation process as

smooth and simple as possible. Samsung’s One-

stop Installation Navigator is a comprehensive

guide for software setup, data migration process

and hardware installation. The Samsung Data

Migration software is simple to use - yet provides

a very powerful “Custom Cloning” feature that

makes migration work even when source data is

greater than the SSD’s capacity. In addition,

SATA to USB 3.0 connector makes data

migration up to three times faster than USB 2.0

for laptop upgrades*. Together, it is now easier

than ever to get setup and running with

Samsung SSDs.

(*SATA to USB 3.0 connector is bundled only with Laptop

Upgrade package)

Samsung Magician Software

Magician eliminates the confusion and

uncertainties of SSD management, making it

simple for users to maximize the performance

and lifetime of their Samsung SSD. In addition to

its performance optimization features, Magician

(from the version 4.2) also provides 840 EVO

users the option to enable RAPID mode (Real-

time Accelerated Processing of Input-output

Data) –an innovative performance

enhancement that processes data on a system

level by using free DRAM memory as a cache.

Once enabled in Magician, RAPID mode provides

an overall PC performance boost.

More Powerful Data Security

Solutions

The Samsung SSD 840 EVO introduces two

important features for data security: hardware-

based AES 256bit Full Disk Encryption (FDE) and

PSID. Hardware-based AES Encryption helps

safeguard data against attack by encrypting all

information on the disk at the hardware level,

which means there is no detrimental effect on

performance.

When you forget your SSD security password,

PSID protects your data on the drive by

executing a cryptographic erase which returns

the drive to its factory status, preventing any

unauthorized access to your data.

A complete, user-friendly

solution

With a wide range of capacities from 120GB to

the spacious 1TB, the 840 EVO will help you find

the perfect SSD for your PC upgrade. And,

Samsung’s 1TB drive is a real 1,000GB of user-

addressable capacity.

The Samsung SSD 840 EVO is available in three

packaging configurations: Basic (Drive only),

Laptop Upgrade and Desktop Upgrade kit. The

Laptop Upgrade kit comes with a SATA to USB

3.0 connector and a mounting spacer. The

Desktop Upgrade kit includes a SATA to USB 2.0

connector, a SATA data cable, screws, a 2.5” to

3.5” adapter bracket.

DATA SHEET

Rev. 1.1, August, 2013

Technical Specifications

Samsung SSD 840 EVO

Usage Application

Client PCs*

Capacity

120GB, 250GB, 500GB,750GB,1TB

Dimensions (LxWxH)

100 x 69.85 x 6.8 (mm)

Interface

SATA 6Gb/s (compatible with SATA 3Gb/s and SATA 1.5Gb/s)

Form Factor

2.5-inch

Controller

Samsung 3-core MEX Controller

NAND Flash Memory

1x nm Samsung Toggle DDR 2.0 NAND Flash Memory (400Mbps)

DRAM Cache Memory

256MB (120GB) or 512MB(250GB&500GB) or 1GB (750&1TB) LPDDR2

Performance**

Sequential Read:

Max. 540 MB/s

Sequential Write***:

Max. 520 MB/s (250GB/500GB/750GB/1TB)

Max. 410 MB/s (120GB)

4KB Random Read (QD1):

Max. 10,000 IOPS

4KB Random Write(QD1):

Max. 33,000 IOPS

4KB Random Read(QD32):

Max. 98,000 IOPS (500GB/750GB/1TB)

Max. 97,000 IOPS (250GB)

Max. 94,000 IOPS (120GB)

4KB Random Write(QD32):

Max. 90,000 IOPS (500GB/750GB/1TB)

Max. 66,000 IOPS (250GB)

Max. 35,000 IOPS (120GB)

TRIM Support

Yes (Requires OS Support)

Garbage Collection

Yes

S.M.A.R.T

Yes

Security

AES 256-bit Full Disk Encryption (FDE)

Weight

Max. 53g (1TB)

Reliability

MTBF: 1.5 million hours

Power Consumption

Average : 0.1W **** (Typical)

Idle : 0.045W (Typical, DIPM ON)

Temperature

Operating:

Non-Operating:

0°C to 70°C

-55°C to 95°C

Humidity

5% to 95%, non-condensing

Vibration

Non-Operating:

20~2000Hz, 20G

Shock

Non-Operating:

1500G , duration 0.5m sec, 3 axis

Etc.

Worldwide Name (WWN), LED Indicator support

Warranty

3 years limited

System Configuration : Intel Core i7-3770 @ 3.4GHz, 4GB DDR3 SDRAM (2GBx2) 1333Mbps; Asus motherboard with Intel 7 Series Z77

Chipset; Windows 7 Ultimate x64 SP1; IRST 11.2, MS performance guide pre-condition.

* 840 EVO is not validated for data center usage.

** Sequential performance measurements based on CrystalDiskMark v.3.0.1. Random performance measurements based on

Iometer 2010. Performance may vary based on SSD’s firmware version, system hardware & configuration

*** Sequential Write performance measurements reflect TurboWrite operation.

****Power consumption measured with MobileMark 2007 in Windows 7. Values calculated using laptop computer and represent

system-level power consumption.

DATA SHEET

Rev. 1.1, August, 2013

Product Lineup

Density

Model Name

Box Contents

Model Code

120 GB

MZ-7TE120

Basic (SSD Only)

MZ-7TE120BW

Desktop Upgrade Kit

MZ-7TE120KW

250 GB

MZ-7TE250

Basic (SSD Only)

MZ-7TE250BW

Laptop Upgrade Kit

MZ-7TE250LW

Desktop Upgrade Kit

MZ-7TE250KW

500 GB

MZ-7TE500

Basic (SSD Only)

MZ-7TE500BW

Laptop Upgrade Kit

MZ-7TE500LW

750 GB

MZ-7TE750

Basic (SSD Only)

MZ-7TE750BW

1TB

MZ-7TE1T0

Basic (SSD Only)

MZ-7TE1T0BW

Contents

Basic

Laptop upgrade

Desktop Upgrade

3.5” bracket with screws

Yes

SATA data cable

Yes

Mounting spacer

Yes

SATA to USB connector

Yes

(USB 3.0)

Yes

(USB 2.0)

SSD Installation Guide(Printed)

Yes

SSD Warranty Summary(Printed)

Yes

Samsung software & manual CD

Yes

Samsung Activation Sticker

Yes

For more information, please visit www.samsung.com/ssd.

To download the latest software & manuals, please visit www.samsung.com/samsungssd

DISCLAIMER

SAMSUNG ELECTRONICS RESERVES THE RIGHT TO

CHANGE PRODUCTS, INFORMATION AND

SPECIFICATIONS WITHOUT NOTICE.

Products and specifications discussed herein are for

reference purposes only. All information discussed

herein may change without notice and is provided

on an “AS IS” basis, without warranties of any kind.

This document and all information discussed herein

remain the sole and exclusive property of Samsung

Electronics. No license of any patent, copyright,

mask work, trademark or any other intellectual

property right is granted by one party to the other

party under this document, by implication,

estoppels or otherwise. Samsung products are not

intended for use in life support, critical care,

medical, safety equipment, or similar applications

where product failure could result in loss of life or

personal or physical harm, or any military or defense

application, or any governmental procurement to

which special terms or provisions may apply. For

updates or additional information about Samsung

products, contact your nearest Samsung office.

This material is copyrighted by Samsung Electronics.

Any unauthorized reproductions, use or disclosure

of this material, or any part thereof, is strictly

prohibited and is a violation under copyright law.

TRADEMARKS & SERVICE MARKS

The Samsung Logo is the trademark of Samsung

Electronics. Adobe is a trademark and Adobe

Acrobat is a registered trademark of Adobe Systems

Incorporated. All other company and product

names may be trademarks of the respective

companies with which they are associated.
