Samsung SOD-14C4LN Manual de usuario

Printed in Korea

GVI dba Samsung CCTV

1621 West Crosby, Suite 104

Carrollton, TX 75006

PHONE : 866-492-8246

COLOR QUAD OBSERVATION SYSTEM

Installation Manual

SOD14C4LN

Graphic Symbol Explanation

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the presence

of uninsulated ‘dangerous voltage’ within the product’s

enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing instructions in

the literature accompanying the appliance.

Warning - To Prevent Fire or Shock Hazard, Do Not

Expose This Monitor To Rain or Moisture.

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

IMPORTANT SAFEGUARDS

Caution

Power source is indicated on the rear of the set. It contains high-voltage parts. If you remove

the cover, it may cause fire or electric shock. Do not remove the cover by yourself. (Control

switches are at the front of the monitor .

1. Read Instructions : All the safety and operating instructions should be read before

the appliance is operated.

2. Retain Instructions : The safety and operating instructions should be retained for

future reference.

3. Heed Warnings : All warnings on the monitor and in the operating instructions

should be adhered to.

4. Follow Instructions : All operating and use instructions should be followed.

5. Cleaning : Unplug this monitor from the wall outlet before cleaning. Do not use

liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Exception. A monitor that is meant for uninterrupted service and that for some

specific reason, such as the possibility of the loss of an authorization code for a

CATV converter, is not intended to be unplugged by the user for cleaning or any

other purpose, may exclude the reference to unplugging the monitor in the cleaning

description otherwise required in Item 5.

6. Attachments : Do not use attachments not recommended by SAMSUNG as they

may cause hazards.

. Water and Moisture : Do not use this monitor near water for example, near a

bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a

swimming pool and the like.

8. Accessories : Do not place this monitor on an unstable cart, stand, tripod, bracket,

or table. The monitor may fall, causing serious injury to a child or adult, and

serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or

table recommended by SAMSUNG, or sold with the monitor. Any mounting of the

monitor should follow SAMSUNG’s instructions, and should use a mounting

accessory recommended by SAMSUNG.

9. Ventilation : Slots and openings in the cabinet are provided for ventilation and to

ensure reliable operation of the monitor and to protect it from overheating, and

these openings should never be blocked by placing the monitor on a bed, sofa, rug,

or other similar surface. This monitor should never be placed near or over a

radiator or heat register.

This monitor should not be placed in a built-in installation such as a bookcase or

rack unless proper ventilation is provided or SAMSUNG’s instructions have been

adhered to.

10. Power Sources : This monitor should be operated only from the type of power

source indicated on the making label. If you are not sure of the type of power

supply to your installation site, consult your SAMSUNG dealer or local power

company.

11. Grounding or Polarization : For monitors equipped with a 3-wire grounding-type

plug having a third(grounding pin. This plug will only fit into a grounding type

power outlet. This is a safety feature. If you are unable to insert the plug into the

outlet, contact your electrician to replace your obsolete outlet. Do not defeat the

safety purpose of the grounding-type plug.

12. Power : Cord Protection-Power supply cords should be routed so that they are not

likely to be walked on or pinched by items placed upon or against them, paying

particular attention to cords at plugs, convenience receptacles, and the point where

they exit from the monitor.

13. Lightning : For added protection for this monitor during a lightning storm, or

when it is left unattened and unused for long periods of time, unplug it from the

wall outlet and disconnect the cable system. This will prevent damage to the

monitor due to lightning and power-line surges.

14. Overloading : Do not overload wall outlets and extension cords as this can result

in a risk of fire of electric shock.

15. Object and Liquid Entry : Never push objects of any kind into this monitor

through openings as they may touch dangerous voltage points or short-out parts

that could result in a fire or electric shock.

Never spill liquid of any kind on the monitor.

16. Servicing : Do not attempt to service this monitor yourself as opening or removing

covers may expose you to dangerous voltage or other hazards. Refer all servicing

to qualified service personnel.

1 . Damage Requiring Service : Unplug this monitor from the wall outlet and refer

servicing to qualified service personnel under the following conditions.

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into the monitor.

c. If the monitor has been exposed to rain or water.

d. If the monitor does not operate normally by following the operating instructions.

Adjust only those controls that are covered by the operating instructions as an

improper adjustment of other controls may result in damage and will often require

extensive work by a qualified technician to restore the monitor to its normal

operation.

e. If the monitor has been dropped or the cabinet has been damaged.

f. When the monitor exhibits a distinct change in performance-this indicates a need

for service.

18. Replacement Parts : When replacement parts are required, be sure the service

technician has used replacement parts specified by SAMSUNG or have the same

characteristics as the original parts.

Unauthorized substitutions may result in fire, electric shock or other hazards.

19. Safety Check : Upon completion of any service or repairs to this monitor, ask the

service technician to preform safety checks to determine that the monitor is in

proper operating condition.

FCC & ICES Information

Warning

This equipment has been tested and found to comply the limits for a class A digital

device, pursuant to part 15 of the FCC Rules and ICES-003 of Industry Canada.

These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This

equipment generate, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required

to correct the interference at his own expense.

User-Installer Caution

Your authority to operate this FCC verified equipment could be voided if you make

changes or modifications not expressly approved by the party responsible for

compliance to part 15 of the FCC Rules.

Contents

IMPORTANT SAFEGUARDS..................................................... 3

1. System Components and Installation ........................................ 8

1-1. SYSTEM Components....................................................... 8

1-2. SYSTEM CONFIGURATION .......................................... 9

1-3. Individual Component Installation................................... 10

1-4. Basic System Installation ................................................. 15

2. Connecting Peripheral Devices ............................................... 16

2-1. To connect a PIR Sensor .................................................. 16

2-2. To connect a VCR ............................................................ 16

3. System Overview .................................................................... 17

4. Part Names and Functions....................................................... 18

4-1. Camera ..............................................................................18

4-2. Monitor Front................................................................... 19

4-3. Explanation of Screen Display......................................... 22

4-4. Monitor Rear .................................................................... 24

5. OSD and SETUP menu........................................................... 26

6. How to Use.............................................................................. 29

7. Technical Specification ........................................................... 32

1. System Components and Installation

1-1. System Components

STANDARD CAMERA

CAMERA CABLE

DOME CAMERA

MONITOR

CAMERA MOUNT BRACKET INSTALLATION MANUAL/POWER CORD

1-2. SYSTEM CONFIGURATION

Model Name Quantity Note

Monitor SOD14M 1 Color Quad Monitor

Standard Camera SOD14C 3

Dome Camera SOD14DC 1 Tapping Screw 2

Camera Mount Bracket SBR-110 3 Tapping Screw 3

Camera Cable MCB-60 4 60ft(1ft=0.3048m

Installation Manual 1

Power Cord 1
