Samsung SmartThings Vision Manual de usuario

SmartThings Vision

Welcome to your

Smart Light

DVS Sensor

Indicator LED

Function Button

USB Charging Port

Light Sensor

Holder

Installation Guide

Indoor installation is recommended. Avoid installing in wet or humid place, otherwise it

may cause malfunctions.

Avoid installing in high temperature environment or near a radiator, heating device,

stove, and other heat sources (including an ampliﬁer).

This product must be attached to ﬂat and clean wall surface. Remove the ﬁlm on the

tape before use. In addition, holder can be attached to iron surface or furniture by

utilizing magnet on the holder.

Avoid installing on the appliances that generate vibration, such as refrigerator or air

conditioner. Otherwise it may cause malfunctions.

Since this product connects to WI-FI, please avoid installing it near devices that emit

strong EM waves.

In the event of device fails to operate:

Please unplug the power cable and plug again after1 minute.If this status persists,

press and hold the function button for more than 7 seconds to reset the device.

Reset takes several minutes. Please do not unplug the power cable before indicator LED

status alternately ﬂashes green and red light.

Trouble Shooting

Recommended

installation height ：

1.5m ~ 1.7m

In the event of Internet is disconnected:

The indicator light shows red. Please check your internet connection.

In the event of app fails to operate:

Please re-start the app. If this status persists, please visit www.SmartThings.com.

1.5m~1.7m

Power on Green On

Green Blinking System boot

Setting standby status Alternately ﬂashes

green and red light

Setting error Red Blinking

Person detected Yellow Blinking for 3 seconds

Function error

Network error

Red Blinking

Red On

Error

Status

Power off No light

LED Status Indicator

※

After login，select “+", and add

device.

Connect your phone to WI-FI where device is used, and

download SmartThings App.

SmartThings

2. 3. Select "SmartThings", in the

"All brands" tab.

Plug the power cable, and wait LED

indicator ﬂashes green and red

alternately.

4. 6.5.

After click “Vision sensor”，select “SmartThings Vision”. After setup location for your

SmartThings Vision, click next.

7. Scan the QR code on the device,

as shown in the picture.

If QR code on device or package

is damaged or fell off, device

will be unable to setup. Please

keep QR code safe.

8. The installation will begin after

scanning QR code.

9. After the installation is ﬁnished,

completion status is as shown in the

picture.

Connecting to Vision sensor

Plug yourVision sensor into an outlet

and wait until the left light starts

blinking green and red.

Add yourdevice by scanning its

QR code.

The code or serial numbermay be on the

back of the device or in the instruction

booklet.

Enter serial number instead

※

My home

Kitchen >

Living room >

No devices

Add device

All brands

SmartThings

Auto detect

SmartThings

vision sensor

My home-Living room

Successfully connected

SmartThings Vision

SmartThings

vision sensor

Vision sensor

SmartThings Vision

Select a location for yourVision sensor.

My home

Add new location
