SDC-89440BF

4M AHD Analog Bullet Camera

User Manual

Hanwha Techwin

Trademark

Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered

trademark of their respective company.

Restriction

Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially

or wholly, without formal authorization.

Disclaimer

Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal

guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.

Hanwha Techwin reserves the right to change the contents of this document without prior notice.

Design and specications are subject to change without prior notice.

4M AHD Analog Bullet Camera

User Manual

English _3

● OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.

(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents

as they may deform or cause damage to the product.)

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and

the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been dropped.

overview

4_ overview

overview

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric shock is present within

this unit.

This exclamation point symbol is intended to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation

instructions.

WARNING

1. Be sure to use only the standard adapter that is specified in the specification sheet.

Using any other adapter could cause fire, electrical shock, or damage to the product.

2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or

damage to the product.

3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat

generation or fire.

4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.

5. When installing the camera, fasten it securely and firmly. The fall of camera may cause personal injury.

6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water

on top of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.

7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.

8. If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately

disconnect the power source and contact the service center. Continued use in such a condition may cause

fire or electric shock.

9. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this

product in any way. (Hanwha Techwin is not liable for problems caused by unauthorized modifications or

attempted repair.)

10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric

shock.

English _5

● OVERVIEW

CAUTION

1. Do not drop objects on the product or apply strong shock to it. Keep away from a location subject to

excessive vibration or magnetic interference.

2. Do not install in a location subject to high temperature, low temperature, or high humidity. Doing so may

cause fire or electric shock.

3. If you want to relocate the already installed product, be sure to turn off the power and then move or reinstall

it.

4. Remove the power plug from the outlet when then there is a lightning. Neglecting to do so may cause fire or

damage to the product.

5. Keep out of direct sunlight and heat radiation sources. It may cause fire.

6. Install it in a place with good ventilation.

7. Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage the

CMOS image sensor.

8. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,

shall be placed on the apparatus.

9. The Mains plug is used as a disconnect device and shall stay readily operable at any time.

10. Do not expose the camera to radioactivity. Radioactivity exposure may damage the CMOS.

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus

6_ overview

overview

CONTENTS

OVERVIEW

3Important Safety Instructions

4Safety Precautions

6Contents

7Product Features

8Part Names and Functions

INSTALLATION

9Precautions

9Installing the camera

10 Protection of Cable from Water

10 Connecting the DVR

APPENDIX

11 Product Specification

13 Product Overview

14 Troubleshooting

English _7

● OVERVIEW

PRODUCT FEATURES

•High resolution

Use the 4 mega-pixel CMOS, and provide high resolution equivalent to 1200TVL horizontal resolution.

•High sensitivity

The built-in high sensitive COLOR CMOS can produce a clear image. 0Lux (Auto IR LED On)

•D-WDR (Digit Wide Dynamic Range)

With the 4M-pixel CMOS sensor, this camera can provide a clear and quality image even under the

circumstance of backlight, by way of and accurate exposure for the dark area and reducing exposure for the

bright area: resulting in a clear, detailed and accurate image.

Package Contents

Check if the product package includes the following items.

SDC-89440BF User Manual Type L-Allen wrench

Screw Anchor 60ft Camera Cable

M `The appearance of the components may differ from the image shown.

`Depending on the model you purchased, there may be difference in the type and number of accessory.

8_ overview

overview

PART NAMES AND FUNCTIONS

Name Description

aLens 3.6mm focal length enables you to monitor at a wider field of view

bIR LED Infrared LED lights are controlled by the illumination sensor.

cIllumination Sensor Detects incoming light to control the IR LED.

dBNC Cable BNC terminal for video signal output.

ePower Cable Use to power the camera.

d e

English _9

●INSTALLATION

installation

PRECAUTIONS

Ensure you read out the following instructions before installing the camera:

•Select an area (ceiling or wall) that can withstand 5 times the camera weight

•Stuck-in or peeled-off cables can cause damage to the product or a fire.

•For safety purposes, keep anyone else away from the installation site.

And put aside personal belongings from the site, just in case.

INSTALLING THE CAMERA

The camera can be installed on the wall, ceiling, shelf or a desired position using the provided mounting bracket.

1. Choose an installation site that can sufficiently support the weight of the camera to be installed.

2. Adhere the installation template onto the ceiling and use it as installation locating tool. “Please refer to

Page15 (Quick Guide)”

3. Attach the camera mount to the wall using the supplied screws.

4. Adjust the direction of the camera to the desired direction, and tighten the bracket.

5. Adjust camera angle as needed.

6. Connect the camera cable to the camera.

Take caution when installing the camera outdoors because the cable connectors may be wet with

moisture or pile up with impurities.

Although the camera is IP66 rated, direct exposure to water or moisture may cause problem such as

condensation.

CAMERA FRONT

Screw holes for

the Camera

installation

10_ installation

installation

PROTECTION OF CABLE FROM WATER

If this product is mounted outdoor, water leakage may occur at gap between cables. As shown below, butyl rubber

(available on the market) shall be used to protect from water.

1. Connect power supply and BNC power source.

2. Cover black sheath of the cable (Zone A), and ensure half of butyl rubber can cover the cable joint.

J `Poor water protection at the cable sheath may cause water leakage. Make sure to wrap tightly.

`The water-proof butyl rubber is made of rubber that expands to twice the original length.

`If you do not use cable joint, it must be covered with water-proof tape.

CONNECTING THE DVR

Connect the BNC connector of the camera to the enclosed 60ft camera cable, and then connect the BNC

connector of the camera cable to the BNC Video Input port of the DVR.

J `The way to connect the power adaptor to the camera may vary depending on the DVR model. You may select one among

the methods provided above as appropriate.

HDMI

VGA

LAN

VIDEOINPUT

12V

RS-485

3 1

4 2

AUDIO

INPUT AUDIO

OUTPUT

CAUTION

RISKOFELECTRI SHOCK

DONOTOPEN

CAUTION:TO REDUCE THE RISK OF ELECTRICAL SHOCK

DONOT OPEN COVERS. NO USER SERVICEABLE

PARTSINSIDE.REFER SERVICING TO QUALIFIED

SERVICEPERSONNEL.

WARNING:TO PREVENT FIRE OR SHOCK HAZARD. DO NOT

EXPOSE UNITS NOT SPECIFICALLYDESIGNED

FOR OUTDOOR USE TO RAIN OR MOISTURE.

HDMI

VGA

LAN

VIDEOINPUT

12V

RS-485

3 1

4 2

AUDIO

INPUT AUDIO

OUTPUT

CAUTION

RISKOFELECTRI SHOCK

DONOTOPEN

CAUTION:TO REDUCE THE RISK OF ELECTRICAL SHOCK

DONOT OPEN COVERS. NO USER SERVICEABLE

PARTSINSIDE.REFER SERVICING TO QUALIFIED

SERVICEPERSONNEL.

WARNING:TO PREVENT FIRE OR SHOCK HAZARD. DO NOT

EXPOSE UNITS NOT SPECIFICALLYDESIGNED

FOR OUTDOOR USE TO RAIN OR MOISTURE.
