Samsung NE58H9970WS/AA Manual de usuario

Electric Range

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

NE58H9970WS

anti-tip device

WARNING

WARNING - To reduce the risk of tipping the range, the

range must be secured by a properly installed Anti-Tip

device. AFTER THE RANGE HAS BEEN INSTALLED,

CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN

PROPERLY INSTALLED AND VERIFY THAT THE ANTI-

TIP DEVICE IS PROPERLY ENGAGED. Refer to the

installation manual for instructions.

a) If the anti-tip device is not installed, a child or adult can tip

the range and be killed.

b) Verify the anti-tip device has been properly installed and

engaged at the rear right (or rear left) of the range bottom.

If you move the range and then move it back into place,

ensure the anti-tip device is re-engaged at the right or left

rear of the range bottom.

Do not operate the range without the anti-tip device in place

and engaged.

Failure to do so can result in death or serious burns to

children or adults.

WARNING WARNING

Do not step, lean, or sit on the oven door or warming

drawer of the range. You can cause the range to tip,

resulting in burns or serious injuries.

English - 2

Conﬁrm that the Anti-Tip device is installed properly. Then, to

verify that the Anti-Tip device is engaged, grasp the top rear

edge of the range and carefully attempt to tilt it forward. The

Anti-Tip device should prevent the range from tilting forward

more than a few inches.

If you pull the range out from the wall for any reason, make

sure the anti-tip device is properly engaged when you push

the range back against the wall. If it is not, there is a risk of

the range tipping over and causing injury if you or a child

stand, sit, or lean on an open door.

Never completely remove the leveling legs. If you remove

the leveling legs, the range will not be secured to the anti-tip

device properly.

English - 3

contents

IMPORTANT SAFETY

INSTRUCTIONS

7 Important safety instructions

INTRODUCING YOUR NEW

RANGE

26 Overview

26 What’s included with your range

BEFORE YOU BEGIN

27 27 Before you begin

GETTING STARTED

27 27 Setting the clock

27 Control panel display modes

28 Turning the oven light on and o

28 Control lockout

29 Setting the kitchen timer

INDUCTION COOKTOP

COOKING

30 About induction cooktop cooking

32 How to set the appliance for

cooktop cooking

34 Before using the cooktop

36 Cookware for induction cooking

zones

36 Use the correct size cookware

37 Size of pans

37 Operating noises

37 Using suitable induction cookware

38 Temperature detection

39 Suggested settings for cooking

speciﬁc foods

40 Protecting the cooktop surface

English - 4

OPERATING THE OVEN

41 41 The oven control panel

42 Using the oven racks

45 Using the gliding rack

46 Using the partition

47 Twin cooking mode temperature

setting ranges

48 Minimum and maximum settings

49 Chef baking

50 Convection baking

52 Convection roasting

53 Timed cooking

54 Delay start

55 Broiling

57 Using the favorite cook feature

58 Using the healthy cook feature

60 Using the keep warm function

61 Using the bread proof function

61 Using the options function

65 Using the temp probe

67 Setting the sabbath feature

USING THE WARMING

DRAWER

69 About the warming drawer

69 Turning the warming drawer on or

o

contents

MAINTAINING YOUR

APPLIANCE

70 Self-cleaning

73 Steam-cleaning

74 Care and cleaning of the oven

77 Care and cleaning of the glass

cooktop

80 Removing and replacing the oven

door

82 Removing and replacing the

warming drawer

83 Changing the oven light

English - 5

contents

WARRANTY (CANADA)

92 92 Warranty (CANADA)

WARRANTY (U.S.A)

90 90 Warranty (U.S.A)

TROUBLESHOOTING

84 84 Troubleshooting

English - 6

important safety instructions

Read and follow all instructions before using your oven

to prevent the risk of ﬁre, electric shock, personal injury,

or damage when using the range. This guide does not cover

all possible conditions that may occur. Always contact your

service agent or manufacturer about problems that you do not

understand.

WHAT YOU NEED TO KNOW ABOUT SAFETY

INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not

cover all possible conditions and situations that may occur. It is

your responsibility to use common sense, caution, and care when

installing, maintaining, and operating your oven.

IMPORTANT SAFETY SYMBOLS AND

PRECAUTIONS

What the icons and symbols in this user manual mean:

WARNING

Hazards or unsafe practices that may result in

severe personal injury or death.

CAUTION

Hazards or unsafe practices that may result in

minor personal injury or property damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric

shock, or personal injury when using your

oven, follow these basic safety precautions.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

English - 7

01 IMPORTANT SAFETY INSTRUCTIONS

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent

electric shock.

Call the service center for help.

Note

These warning icons and symbols are here to prevent injury to you

and others.

Please follow them explicitly.

After reading this section, keep it in a safe place for future

reference.

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

FOR YOUR SAFETY

When using electrical appliances, you should follow basic

safety precautions, including the following:

CAUTION

Use this appliance only for its intended purpose as described

in this Owner’s Manual.

Potentially hot surfaces include the cooktop, areas facing the

cooktop, oven vent opening, surfaces near the opening, and

crevices around the oven door.

Be sure your appliance is properly installed and grounded by

a qualiﬁed technician.

User servicing - Do not repair or replace any part of the

appliance unless speciﬁcally recommended in the manual. All

other servicing should be referred to a qualiﬁed technician.

English - 8

Always disconnect the power to the appliance before servicing

by removing the fuse or switching o the circuit breaker.

Do not enter the oven.

Do not store items of interest to children in cabinets

above a range or on the back guard of a range. Children

climbing on the range to reach items could be seriously injured.

Do not leave children alone. Never leave children alone or

unattended in an area where this appliance is in use. They

should never be allowed to sit or stand on any part of the

appliance.

Never use your appliance for warming or heating the

room.

Do not use water on grease ﬁres. Turn o the oven to

avoid spreading the ﬂame. Smother the ﬁre or ﬂame by closing

the door or use a dry chemical, baking soda, or foam-type

extinguisher.

Avoid scratching or impacting glass doors, cooktops, or control

panels. Doing so may lead to glass breakage. Do not cook on a

product with broken glass. Shock, ﬁre, or cuts may occur.

If there is a ﬁre in the oven during baking, smother the ﬁre by

closing the oven door and turning the oven o or by using a

multi-purpose dry chemical or foam-type ﬁre extinguisher.

If there is a ﬁre in the oven during self-clean, turn the oven o

and wait for the ﬁre to go out. Do not force the door open.

Introduction of fresh air at self-clean temperatures may lead to

a burst of ﬂame from the oven. Failure to follow this instruction

may result in severe burns.

If the oven is heavily soiled with oil, self clean the oven before

using the oven again. Leaving the oil in place creates a risk of

ﬁre.

Wipe up heavy soil on the oven bottom with a paper tower or

rag before self cleaning. Self cleaning the oven when there is

heavy soil on the oven bottom requires longer cleaning cycles

and produces more smoke.

English - 9

01 IMPORTANT SAFETY INSTRUCTIONS

Storage in or on appliance. Do not store ﬂammable

materials in the oven or near the surface units. Be sure all

packing materials are removed from the appliance before

operating it. Keep plastics, clothes, and paper away from

parts of the appliance that may become hot.

Wear proper apparel. Never wear loose-ﬁtting or hanging

garments while using the appliance.

Use only dry potholders. Placing moist or damp

potholders on hot surfaces may result in burns from steam.

Do not let the potholder touch hot heating elements. Do not

use a towel or other bulky cloth on or near the range.

Teach children not to play with the controls or any other part

of the range.

For your safety, do not use high-pressure water cleaners or

steam jet cleaners to clean any part of the range.

If the power cord is damaged, it must be replaced by the

manufacturer, its service agent, or similarly qualiﬁed persons

to avoid creating a hazard.

The appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental

capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of

the appliance by a person responsible for their safety.

Do not lean on the range as you may turn the control knobs

accidently.

English - 10
