Electric Range

user manual

FE-R500**

FE-R500_XAC DG68-00295A.indb 1 2010-02-18 �� 11:33:08

features of your new range

Enhanced convenience. Better cooking. Easy maintenance. Your new electric range has been designed to

bring you these beneﬁts and more.

The latest in heat-distribution technology•

Other ranges with just one fan tend to make a swirl of heat that fails to cover the whole inside of

the oven. This means uneven heat distribution and uneven cooking. Your new range has Surround

Airvection™, which Samsung innovated by adding a third heating element and a multi-fan system

that circulates the heat evenly in all directions. You get more efﬁcient energy consumption and

more even cooking.

Steam Quick cleaning•

Thanks to Steam Quick™, Samsung’s unique technology for light-duty cleaning jobs, keeping

your oven Spic-and-Span is a snap — no hassle, no odor, no chemicals. Steam Quick™ cleans

the inside of your range with high-temperature steam in just 20 minutes.

Bigger is better•

With a capacity of 5.9 cubic feet, your new range is equipped with more space than any of its

competitors in the U.S. market. This means greater convenience for you when cooking for the

holidays or when entertaining.

A cooktop with 5 burners•

Four main burners with two that dial heat up to different pot sizes.

A smaller warming burner in the center of the range top.

FE-R500_XAC DG68-00295A.indb 2 2010-02-18 �� 11:33:08

Important safety instructions _3

important safety instructions

Read and follow all instructions before using your oven to prevent the

risk of ﬁre, electric shock, personal injury, or damage when using the

range. This guide does not cover all possible conditions that may occur. Always

contact your service agent or manufacturer about problems that you do not

understand.

WHAT YOU NEED TO KNOW ABOUT SAFETY

INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not cover all

possible conditions and situations that may occur. It is your responsibility to use

common sense, caution, and care when installing, maintaining, and operating

your oven.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS

What the icons and signs in this user manual mean:

WARNING

Hazards or unsafe practices that may result in severe

personal injury or death.

CAUTION

Hazards or unsafe practices that may result in minor

personal injury or property damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or

personal injury when using your oven, follow these basic

safety precautions.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent electric

shock.

Call the service center for help.

Note

These warning signs are here to prevent injury to you and others.

Please follow them explicitly.

After reading this section, keep it in a safe place for future reference.

FE-R500_XAC DG68-00295A.indb 3 2010-02-18 �� 11:33:09

4_ Important safety instructions

ANTI-TIP DEVICE

WARNING

WARNING- To reduce the risk of tipping the range, the range must be

secured by a properly installed Anti-Tip device. Refer to the installation

manual for instructions.

WARNING WARNING

ALL RANGES CAN TIP AND CAUSE INJURIES TO

PERSONS

INSTALL THE ANTI-TIP DEVICE PACKED WITH RANGE

FOLLOW ALL INSTALLATION INSTRUCTIONS

Do not step, lean, or sit on the doors of the range. These can cause

the range to tip, resulting in burns or serious injuries.

Check to see that the Anti-Tip device is installed properly. Then grasp the

top rear edge of the range and carefully attempt to tilt it forward. Verify

that the Anti-Tip device is engaged.

If you pull the range out from the wall for any reason, make sure the

device is properly engaged when you push the range back against the

wall. If it is not, there is a possible risk of the range tipping over and

causing injury if you or a child stand, sit or lean on an open door.

FOR YOUR SAFETY

When using electrical appliances, basic safety precautions should be

followed, including the following:

CAUTION Use this appliance only for its intended purpose as described in this

Owner’s Manual.

Potentially hot surfaces include the cooktop, areas facing the cooktop,

oven vent opening, surfaces near the opening, crevices around the oven

door.

Be sure your appliance is properly installed and grounded by a qualiﬁed

technician.

User servicing- Do not repair or replace any part of the appliance unless

speciﬁcally recommended in the manual. All other servicing should be

referred to a qualiﬁed technician.

Always disconnect power to appliance before servicing by removing the

fuse or switching off the circuit breaker.

FE-R500_XAC DG68-00295A.indb 4 2010-02-18 �� 11:33:10

Important safety instructions _5

Do not enter inside the oven.

CAUTION - Do not store items of interest to children in cabinets above a

range or on the back guard of a range. Children climbing on the range to

reach items could be seriously injured.

Do not leave children alone. Children should not be left alone or

unattended in an area where appliance is in use. They should never be

allowed to sit or stand on any part of the appliance.

Never use your appliance for warming or heating the room.

Do not use water on grease ﬁres. Turn off the oven to avoid spreading

the ﬂame. Smother the ﬁre or ﬂame by closing the door or use dry

chemical, baking soda, or foam-type extinguisher.

Storage in or on appliance. Flammable materials should not be

stored in an oven or near surface units. Be sure all packing materials are

removed from the appliance before operating it. Keep plastics, clothes,

and paper away from parts of the appliance that may become hot.

Wear proper apparel. Loose-ﬁtting or hanging garments should never

be worn while using the appliance.

Use only dry potholders. Moist or damp potholders on hot surfaces

may result in burns from steam. Do not let the potholder touch hot

heating elements. Do not use a towel or other bulky cloth.

Teach children not to play with the controls or any other part of the range.

CAUTION

FE-R500_XAC DG68-00295A.indb 5 2010-02-18 �� 11:33:10

6_ Important safety instructions

SURFACE COOKING UNITS

Never leave surface units unattended at high heat settings.

Boilovers cause smoking and greasy spillovers that may ignite.

Do not lift the cooktop. Lifting the cooktop can lead to damage and

improper operation of the range.

Do not operate the cooktop when there is no cookware. If the cooktop

operates without a cookware, the control knob will become hot.

Never use the glass cooktop surface as a cutting board.

Use care when touching the cooktop. The glass surface of the

cooktop will retain heat after the controls have been turned off.

Be careful when placing spoons or other stirring utensils on the

glass cooktop surface when it is in use. They may become hot and

could cause burns.

Use proper pan sizes. This appliance is equipped with surface units of

different sizes. Select utensils having ﬂat bottoms large enough to cover

the surface unit heating element. The use of undersized utensils will

expose a portion of the heating element to direct contact and may result

in ignition of clothing. Proper relationship of utensil to burner will also

improve efﬁciency.

Glazed cooking utensils. Only certain types of glass, glass/ceramic,

ceramic,earthenware, or other glazed utensils are suitable for range-top

service without breaking due to the sudden change in temperature.

Utensil handles should be turned outward and not extend over

adjacent surface units. To reduce the risk of burns, ignition of

ﬂammable materials, and spillage due to unintentional contact with the

utensil, the handle of a utensil should be positioned so that it is turned

outward, and does not extend over adjacent surface units.

Read and follow all instructions and warnings on the cleaning cream

labels.

Be sure you know which control knob operates each surface unit. Make

sure you turned on the correct surface unit.

Always turn the surface units off before removing cookware.

When preparing ﬂaming foods under the hood, turn the fan on.

Keep an eye on foods being fried at high or medium high heat settings.

FE-R500_XAC DG68-00295A.indb 6 2010-02-18 �� 11:33:10

Important safety instructions _7

OVEN

DO NOT TOUCH HEATING ELEMENTS OR INTERIOR SURFACES

OF THE OVEN. Heating elements may be hot even though they are dark

in color. Interior surfaces of an oven become hot enough to cause burns.

During and after use, do not touch or let clothing or other ﬂammable

materials contact heating elements or interior surfaces of the oven until

they have had sufﬁcient time to cool. Other surfaces of the appliance may

become hot enough to cause burns. Among these surfaces are oven

vent openings and surfaces near these openings, oven doors, and the

oven door window.

Do not heat unopened food containers. Build-up of pressure may

cause the container to burst and result in injury.

Do not use the oven to dry newspapers. If overheated, they can

catch on ﬁre.

Do not use the oven for a storage area. Items stored in an oven can

ignite.

Use care when opening door. Let hot air or steam escape before you

remove or replace food in the oven.

Protective liners. Do not use aluminum foil to line the oven bottoms,

except as suggested in the manual. Improper installation of these liners

may result in a risk of electric shock or ﬁre.

Keep oven vent ducts unobstructed. The oven vent is located above

the right rear surface unit. This area could become hot during oven use.

Never block this vent or place plastic or heat-sensitive items on it.

Placement of oven racks. Always place oven racks in the desired

location while the oven is cool. If the rack must be moved while oven

is hot, do not let the potholder come in contact with the hot heating

element in the oven.

Do not allow aluminum foil or meat probe to contact heating elements.

FE-R500_XAC DG68-00295A.indb 7 2010-02-18 �� 11:33:10

8_ Important safety instructions

WARMING DRAWER

DO NOT TOUCH THE HEATING ELEMENT OR THE INTERIOR

SURFACE OF THE DRAWER. These surfaces may be hot enough to

burn.

REMEMBER: The inside surface of the drawer may be hot when the

drawer is opened.

The purpose of the warming drawer is to hold hot cooked foods at

serving temperature. Always start with hot food; cold food cannot be

heated or cooked in the warming drawer.

Use care when opening the drawer. Open the drawer a crack and

let hot air or steam escape before removing or replacing food. Hot air or

steam which escapes can cause burns to hands, face and/or eyes.

Do not use the drawer to dry newspapers. If overheated, they can

catch on ﬁre.

Do not use aluminum foil to line the drawer. Foil is an excellent heat

insulator and will trap heat beneath it. This will upset the performance of

the drawer and it could damage the interior ﬁnish.

Do not leave paper products, plastics, canned food or combustible

materials in the drawer.

Never leave jars or cans of fat drippings in or near your drawer.

Do not warm food in the drawer for more than three hours.

SELF-CLEANING OVENS

Do not clean the door gasket. The door gasket is essential for a good

seal. Care should be taken not to rub, damage, or move the gasket.

Never keep pet birds in the kitchen. The health of birds is extremely

sensitive to the fumes released during an oven self-clean cycle. Fumes

may be harmful or fatal to birds. Move birds to a well-ventilated room.

Clean only parts listed this manual in the self-clean cycle. Before

self-cleaning the oven, remove the broil pan, rack, utensils, and food.

No commercial oven cleaner or oven liner protective coating of any kind

should be used in or on the outside of the oven. Use only a ceramic

cooktop cleaner or the cleaner supplied with this appliance on the glass

cooktop.

FE-R500_XAC DG68-00295A.indb 8 2010-02-18 �� 11:33:10

Important safety instructions _9

Nickel oven shelves should be removed from the oven before beginning

the self-cleaning cycle, or they may discolor.

If the self-clean mode malfunctions, turn the oven off and disconnect the

power supply. Have it serviced by a qualiﬁed technician.

VENTILATING HOOD

Clean ventilating hoods frequently. Grease should not be allowed to

accumulate on the hood or ﬁlter.

When ﬂaming foods under the hood, turn the fan on.

GLASS/CERAMIC COOKING SURFACES

DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS.

Surface units may be hot even though they are dark in color. Areas near

surface units may become hot enough to cause burns. During and after

use, do not touch, or let clothing or other ﬂammable materials contact

surface units or areas near units until they have had sufﬁcient time to

cool. Among these areas are the cook-top and facing the cook-top.

Do not cook on broken cooktop. If cooktop should break, cleaning

solutions and spillovers may penetrate the broken cook-top and create a

risk of electric shock. Contact a qualiﬁed technician immediately.

Clean cooktop with caution. If a wet sponge or cloth is used to wipe

spills on a hot cooking area, be careful to avoid steam burn. Some

cleaners can produce noxious fumes if applied to a hot surface.

BEFORE YOU BEGIN

Clean the oven thoroughly before using for the ﬁrst time. Remove

accessories and operate the oven at the bake setting at 400°F for 1 hour

before using. There will be a distinctive odor; this is normal, but ensure

your kitchen is well ventilated during this conditioning period.

FE-R500_XAC DG68-00295A.indb 9 2010-02-18 �� 11:33:10

10_ Important safety instructions

WARNING

SEVERE WARNING SIGNS FOR INSTALLATION

The installation of this appliance must be performed by a qualiﬁed technician or

service company.

- Failing to do so may result in electric shock, ﬁre, an explosion, problems with

the product, or injury.

Unpack the oven, remove all packaging material and examine the oven for any

damages such as dents on the interior or exterior of the oven, broken door

latches, cracks in the door, or a door that is not lined up correctly. If there is any

damage, do not operate the oven and notify your dealer immediately.

Plug the power cord into a properly grounded outlet of standard. Your oven

should be the only connected on this circuit.

Keep all packaging materials out of the reach of children. Children may use them

for play.

Install your appliance on a level and hard ﬂoor that can support its weight.

- Failing to do so may result in abnormal vibrations, noise, or problems with the

product.

This appliance must be properly grounded.

Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

- This may result in electric shock, ﬁre, an explosion, or problems with the

product

Do not cut or remove the ground prong from the power cord under any

circumstances.

Connect the oven to a properly grounded circuit.

Do not install this appliance in a humid, oily or dusty location, in a location

exposed to direct sunlight and water (rain drops).

- This may result in electric shock or ﬁre.

Do not use a damaged power cord or loose wall socket.

- This may result in electric shock or ﬁre.

Do not operate any other heating or cooking appliance beneath this appliance.

Do not mount unit over or near any portion of a heating or cooking appliance.

Do not mount over a sink.

Do not pull or excessively bend the power cord.

Do not twist or tie the power cord.

Do not hook the power cord over a metal object, place a heavy object on the

power cord, insert the power cord between objects.

- This may result in electric shock or ﬁre.

When the power cord is damaged, contact your nearest service center.

FE-R500_XAC DG68-00295A.indb 10 2010-02-18 �� 11:33:10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Rango de Samsung

Samsung

Samsung NX58H9950W Series Manual de usuario

Samsung

Samsung NE63T8751/AA Manual de usuario

Samsung

Samsung NX58H9500W Series Manual de usuario

Samsung

Samsung NX60 85 S Series Manual de usuario

Samsung

Samsung NX58M9420SS Series Manual de usuario

Samsung

Samsung NX60T8111SS Manual de usuario

Samsung

Samsung NE59 663 Series Manual de usuario

Samsung

Samsung NX58M9960P series Manual de usuario

Samsung

Samsung NE63 6517S Series Manual de usuario

Samsung

Samsung NX58H5600SS Manual de usuario

Samsung

Samsung NX58H5600SS/AA Manual de usuario

Samsung

Samsung NE595N0PBSR Manual de usuario

Samsung

Samsung NX60 65 S Series Manual de usuario

Samsung

Samsung NE59T7511SS Manual de usuario

Samsung

Samsung NX58J5600S series Manual de usuario

Samsung

Samsung NE63T8311SG Manual de usuario

Samsung

Samsung NX58J7750S series Manual de usuario

Samsung

Samsung FCQ321HTUB Manual de usuario

Samsung

Samsung NX58K7850SS/AA Manual de usuario

Samsung

Samsung FCQ321HTUB Manual de usuario

Samsung

Samsung FE-N500 Series Manual de usuario

Samsung

Samsung NE63 6511S Series Manual de usuario

Samsung

Samsung NX60 83 S Series Manual de usuario

Samsung

Samsung NX60 8 Series Manual de usuario

Manuales populares de Rango de otras marcas

Kenmore

Kenmore 790.45712 Manual de usuario

Wolf

Wolf CHR CHSSR Manual de usuario

Smeg

Smeg Built-in Microwave Oven Manual de instrucciones

Zanussi

Zanussi ZCG054G Manual de usuario

Whirlpool

Whirlpool 8575985-W Manual de lista de piezas

Frigidaire

Frigidaire 316000635 Manual de usuario

GE JCSS630 Manual de usuario

Hotpoint

Hotpoint RB524R Guía de instalación

Whirlpool

Whirlpool Roper FGP305KW3 Manual de usuario

Amana

Amana ART6610 SERIES Manual de usuario

Maytag

Maytag MERH770WB Manual de usuario

Fulgor Milano

Fulgor Milano SOFIA Manual de usuario

Premier

Premier EF-4358GH Manual de usuario

Kenmore

Kenmore 790.9010 Series Manual de usuario

KitchenAid

KitchenAid KESC300 Manual de usuario

Frigidaire

Frigidaire FFEF3012LS Guía del usuario

Diamond

Diamond G65/2F4T Manual de usuario

LG LRE3091 Manual de usuario
