2_ features of your new range

features of your new

range

Enhanced convenience. Better cooking. Easy maintenance. Your new gas

range has been designed to bring you these beneﬁts and more.

 

With a capacity of 5.8 cubic feet, your new range has more space than

many leading competitors in the United States and Canadian markets. This

means greater convenience for you when cooking for the holidays or when

entertaining.

 

Power burners, simmer burners, as well as a center oval burner provide

ﬂexible cooktop heat for a variety of cookware.

The center oval burner provides even heating over large areas, so it is

perfect for griddle cooking.

FX710BGS_FX510BGS_DG68-00356A-01.indd 2 2011-08-19 �� 4:25:40

important safety instructions _3



important safety

instructions

READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE

All electrical and gas equipment with moving parts can be dangerous. Please read the

important safety instructions for this appliance in this manual. The instructions must be

followed to minimize the risk of injury, death, or property damage.

Save this manual / Please Do Not Discard

SAFETY SYMBOLS



WARNING

Means that death or serious personal injury is a risk.

CAUTION

Means that there is a potential risk for personal injury or

property damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or

personal injury when using your gas range, follow these basic

safety precautions:

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power cord from the electrical outlet.

Make sure the range is plugged into an earth grounded

electrical outlet to prevent electric shock. An outlet equipped

with a Ground Fault Interrupter (GFI) is highly recommended.

Call the service center for help. see page 80.

Note

These warning icons are here to prevent injury to you and others.

Please observe them explicitly.

Do not discard this manual. Please keep it in a safe place for future reference.

FX710BGS_FX510BGS_DG68-00356A-01.indd 3 2011-08-19 �� 4:25:41

4_ important safety instructions

WARNING

If the instructions in this manual is not followed exactly, a ﬁre or explosion may

result, causing death, personal injury, or property damage.

– Do not store or use gasoline or other ﬂammable vapors and liquids in the

vicinity of this or any other appliance.

– WHAT TO DO IF YOU SMELL GAS:

• DONOTtrytolightanyappliance.

• DONOTtouchanyelectricalswitch.

• DONOTuseanyphoneinyourbuilding.

• Immediatelycallyourgassupplierfromaneighbor’sphone.Followthe

gassupplier’sinstructions.

• Ifyoucannotreachyourgassupplier,calltheredepartment.

– Installation and service must be performed by a qualiﬁed installer, service

agency, or the gas supplier.

ANTI-TIP DEVICE

WARNING WARNING

ALL RANGES CAN TIP, RESULTIONG IN PERSONAL

INJURY.

TIPPING RANGES CAN CAUSE BURNS FROM SPILLS,

PERSONAL INJURY, AND/OR DEATH.

INSTALL AND CHECK THE ANTI-TIP BRACKET

FOLLOWING THE INSTRUCTIONS AND TEMPLATE

SUPPLIED WITH THE BRACKET.

To prevent accidental tipping of the range, attach an approved anti-tip device

to the ﬂoor. (See Installing the Anti-Tip Device in the Installation Instructions.)

Check for proper installation by carefully tipping the range forward. The anti-tip

device should engage and prevent the range from tipping over.

If the range is pulled out away from the wall for any reason, make sure the anti-

tip device is reengaged after the range has been pushed back into place.

Follow the installation instructions found in the Installation Manual. Failure to

follow these instructions can result in death, serious personal injury, and / or

property damage.

FX710BGS_FX510BGS_DG68-00356A-01.indd 4 2011-08-19 �� 4:25:41

important safety instructions _5



IMPORTANT SAFETY

PRECAUTIONS

WARNING

Follow basic precautions when installing and using this range to reduce the risk

of ﬁre, electrical shock, injury, or death to persons, including:



This range must be properly located and installed in accordance with the

installation instructions before it is used.

Professional installation is strongly recommended.

Due to the size and weight of the range, it is highly recommended that two or

more people move or install this appliance.

All ranges can tip over and cause severe injuries. Install the anti-tip device

packed with this range following the instructions found in the Installation

Instructions.

Never try to repair or replace this appliance on your own unless it is speciﬁcally

recommended in this manual. This appliance should be serviced only by a

qualiﬁed service technician.

Know the location of the gas shut-o valve and how to shut it o if necessary.

Properly remove or destroy the packaging materials after the appliance is

unpacked.



Unplug or disconnect power before servicing.

Do not tamper with the controls. Grates and griddles (if equipped) are heavy.

They can be dangerous if dropped.

The inner portion of the split oven rack (if equipped) could drop down

accidentally if not assembled properly. Place the inner rack in the proper

position within the outer rack.

Always position the oven racks at the same level on each cavity side. Failure to

do so could allow food to fall from position and pose a risk of burns.

FX710BGS_FX510BGS_DG68-00356A-01.indd 5 2011-08-19 �� 4:25:41

6_ important safety instructions



Do not store any object of interest to children on the cooktop or backguard

of the range. Children climbing on the range to reach items could be killed or

seriously injured.

The inner rack of the Split Rack can be dropped if it is not assembled properly.

Place the Inner rack in the proper place on the Outer rack. Always insert the

rack or split rack assembly (if equipped) on the same level of the oven cavity

side.

Keep all packaging materials out of reach of children. Children may play with

them. Failure to dispose of plastic bags could result in suocation.

Do not leave children alone or unattended in an area where a range is in use.

They should never be allowed to sit or stand on any part of a range.

Do not let little children touch the range.

The cooktop grates and griddle (if equipped) are heavy and presents a risk of

injury if dropped on a foot. Teach children not to touch or play with grates or

griddle.

Teach children not to touch or play with the controls or any part of the range.

We recommend you utilize the control / door lockout feature to reduce the risk

of mis-use by children.

Before disposing of the range, cut o the power cord to prevent it being

connected to a power source. Remove the door to prevent children and

animals from getting trapped.



Do not touch oven burners, drawer burners, or interior surfaces of the oven.

Cooking surfaces, grates, cooktop burners and caps, as well as oven walls

may be hot even though they are dark in color. Interior oven surfaces can

become hot enough to cause burns. During and after use, do not touch or let

clothing or other ﬂammable materials contact oven burners, drawer burners, or

interior surfaces of the oven until they have had sucient time to cool.

Do not let a pot holder touch a hot heating element. Do not use a towel or

other bulky cloth as a pot holder.

Do not use your range to heat unopened food containers or to dry wet stu.

Keep oven vent ducts unobstructed. Clean vents frequently to avoid grease

buildup. See page 55. There can be slight popping sound during oven

cooking. This sound may occur during normal oven burner cycling, when the

oven burner ﬂame is extinguished.

FX710BGS_FX510BGS_DG68-00356A-01.indd 6 2011-08-19 �� 4:25:41

important safety instructions _7



Never use your range for any purposes but cooking. Doing so could result in

carbon monoxide poisoning and/or overheating of the oven.

Loose-ﬁtting or hanging garments should not be worn while using this

appliance.

DO NOT STORE OR USE combustible materials, gasoline, or other ﬂammable

vapors or liquids in the vicinity of this appliance. See “WHAT TO DO IF YOU

SMELL GAS” under the Gas Warnings.

Do not pour water into the cooktop well while cleaning the cooktop. This could

leak down into the range gas and electrical systems causing a risk of electrical

shock or high levels of Carbon Monoxide, due to corrosion of fuel oriﬁces.

Do not use water on a grease ﬁre. Water might cause a grease ﬁre to explode,

spreading the ﬁre and creating a larger ﬁre and health hazard. Turn o heat

source and smother with tight-ﬁtting lid or use a multipurpose dry chemical or

foam-type ﬁre extinguisher.

Never leave surface units unattended at high heat settings. Boilovers cause

smoke, and greasy spillovers could ignite.

Do not use a ﬂame to check for gas leaks. Use a soapy water mixture around

the area you are checking instead.

Do not place portable appliances, or any other object other than cookware on

the cooktop. Damage or ﬁre could occur if the cooktop is hot.

Do not attempt to operate this appliance if it is damaged, malfunctioning, or

has missing or broken parts.

Never place plastic, paper, or other items that could melt or burn near the oven

vents or any of the surface burners.

If the self-clean mode malfunctions, turn the oven o and disconnect the power

supply. Refer to pages 77 and 78 to contact a qualiﬁed service technician.

There can be slight popping sound during oven cooking.



Use care when opening the oven door. Let hot air or steam escape before

removing or placing food in a hot oven.

Use only dry pot holders. Putting moist or damp pot holders on hot surfaces

may result in burns from steam.

FX710BGS_FX510BGS_DG68-00356A-01.indd 7 2011-08-19 �� 4:25:41

8_ important safety instructions



– The burner spreader can be blocked by food or dust. Clean the spreader

if it appears blocked. If you clean the spreader with water, assemble it only

after it is completely dry. If the spreader is wet, it might prevent the burners

from igniting.

– Do not pour water on the cooktop for cleaning. It can get inside the range

and cause the parts inside to rust.

– Only ignite the cooktop burners with the burner caps in place. If the

burner caps are not in place, you can damage the controls or cause an

unintended large or dangerous ﬂame.

– Heating of beverages can result in delayed eruptive boiling. To prevent

delayed eruptive boiling, ALWAYS allow heated beverages to stand at least

20 seconds after you have turned the burner o so that the temperature

in the liquid can stabilize. In the event of scalding, follow these FIRST AID

instructions:

• Immersethescaldedareaincoldwaterforatleast10minutes

• Coverwithclean,drydressing

• Donotapplyanycreams,oilsorlotions

– The‘Sparkmark’ontheDualburnerspreadermustbeplacedbesidethe

electrode when it is assembled to prevent an abnormal ﬂame.

– After turning on a surface burner, check to make sure that the burner has

ignited. Adjust the level of the ﬂame by turning the burner knob.

– When you set a burner to simmer, do not turn the burner knob quickly.

Watch the ﬂame to make sure it stays on.

FX710BGS_FX510BGS_DG68-00356A-01.indd 8 2011-08-19 �� 4:25:41

important safety instructions _9



GAS WARNINGS

WARNING

If the instructions in this manual are not followed exactly, a ﬁre or explosion

may result, causing death, personal injury, or property damage.

1. Close the valve and do not use the range.

2. DO NOT light a match, candle, or cigarette.

3. DO NOT turn on any gas or electric appliances.

4. DO NOT touch any electrical switches or plug powercord into the outlet.

5. DO NOT use any phone in your building.

6. Clear the room, building, or area of all occupants.

7. Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegas

supplier’sinstructions.

8. If you cannot reach your gas supplier, call the ﬁre department.



Installation of this range must conform with local codes or, in the absence of

local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest

edition. In Canada, installation must conform with the current Natural Gas

Installation Code, CAN/CGA-B149.1, or the current Propane Installation Code,

CAN/CGA-B149.2, and with local codes where applicable. This range has

been design-certiﬁed by ETL according to ANSI Z21.1, latest edition, and

Canadian Gas Association according to CAN/CGA-1.1, latest edition.

Do not install the appliance at a place which is exposed strong draft.

Installation and service must be performed by a qualiﬁed installer, service

agency, or gas supplier.

Have the installer show you the location of the gas shut-o valve and how to

shut it o.

Always use NEW ﬂexible connectors when installing a gas appliance. Never

reuse old ﬂexible connectors. The use of old ﬂexible connectors can cause gas

leaks and personal injury.

Never use this appliance as a space heater to heat or warm the room. Doing

so may result in carbon monoxide poisoning and overheating of the oven.

Never block the oven vents (air openings). They provide the air inlet and

exhaust that are necessary for the oven to operate properly with correct

combustion.

FX710BGS_FX510BGS_DG68-00356A-01.indd 9 2011-08-19 �� 4:25:41

10_ important safety instructions

CALIFORNIA SAFE DRINKING

WATER AND TOXIC

ENFORCEMENT ACT

The California Safe Drinking Water and Toxic Enforcement Act requires the

Governor of California to publish a list of substances known to the state to

cause birth defects or other reproductive harm and requires businesses to

warn customers of potential exposure to such substances.

WARNING

Gas appliances can cause minor exposure to four of these substances,

namely, carbon monoxide, formaldehyde, and soot, caused primarily by the

incomplete combustion of natural gas or LP fuels. Properly adjusted burners,

indicated by a bluish rather than yellow ﬂame, will minimize incomplete

combustion. Exposure to these substances can be minimized by venting with

an open window or by using a ventilation fan or hood.

IN THE COMMONWEALTH OF

MASSACHUSETTS

This product must be installed by a licensed plumber or gas ﬁtter qualiﬁed or

licensed by the State of Massachusetts.

When using ball-type gas shut-o valves, they shall be the T-handle type.

Multiple ﬂexible gas lines must not be connected in series.

FX710BGS_FX510BGS_DG68-00356A-01.indd 10 2011-08-19 �� 4:25:41

Otros manuales para FX510BGS/XAA

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Rango de Samsung

Samsung

Samsung NX58F5700WS Manual de usuario

Samsung

Samsung NSI6D 91 Series Manual de usuario

Samsung

Samsung NX58M6850S Series Manual de usuario

Samsung

Samsung NE59M6850 SERIES Manual de usuario

Samsung

Samsung NX60A6751SS Manual de usuario

Samsung

Samsung NX58K7850S SERIES Manual de usuario

Samsung

Samsung NE63T8111SS Manual de usuario

Samsung

Samsung NX58H5600SS/AA Manual de usuario

Samsung

Samsung NE63 6517S Series Manual de usuario

Samsung

Samsung NX60T8111S Manual de usuario

Samsung

Samsung NX58R4311SS Manual de usuario

Samsung

Samsung NX58M9960P series Manual de usuario

Samsung

Samsung NX60 85 S Series Manual de usuario

Samsung

Samsung NE63 871 Series Manual de usuario

Samsung

Samsung FTQ353IWUX - 30in Electric Range Manual de usuario

Samsung

Samsung NX58F5500SB Manual de usuario

Samsung

Samsung NE59M4310 Series Manual de usuario

Samsung

Samsung NE58R9311 Manual de usuario

Samsung

Samsung NX58F5500SS Manual de usuario

Samsung

Samsung NE59J342 Manual de usuario

Samsung

Samsung NE59N6630S Series Manual de usuario

Samsung

Samsung NX58H9950W Series Manual de usuario

Samsung

Samsung NX58M6630SS/AA Manual de usuario

Samsung

Samsung NE58F9500SS Manual de usuario

Manuales populares de Rango de otras marcas

Kenmore

Kenmore 790.45712 Manual de usuario

Wolf

Wolf CHR CHSSR Manual de usuario

Smeg

Smeg Built-in Microwave Oven Manual de instrucciones

Zanussi

Zanussi ZCG054G Manual de usuario

Whirlpool

Whirlpool 8575985-W Manual de lista de piezas

Frigidaire

Frigidaire 316000635 Manual de usuario

GE JCSS630 Manual de usuario

Hotpoint

Hotpoint RB524R Guía de instalación

Whirlpool

Whirlpool Roper FGP305KW3 Manual de usuario

Amana

Amana ART6610 SERIES Manual de usuario

Maytag

Maytag MERH770WB Manual de usuario

Fulgor Milano

Fulgor Milano SOFIA Manual de usuario

Premier

Premier EF-4358GH Manual de usuario

Kenmore

Kenmore 790.9010 Series Manual de usuario

KitchenAid

KitchenAid KESC300 Manual de usuario

Frigidaire

Frigidaire FFEF3012LS Guía del usuario

Diamond

Diamond G65/2F4T Manual de usuario

LG LRE3091 Manual de usuario
