Samsung ML-3750ND Manual de usuario

ML-375x Series

User’s Guide

Basic

imagine the possibilities

This guide provides information concerning installation, basic operation and troubleshooting on

windows.

1. Introduction

This chapter provides information you need to know before using the

machine.

•Keybenefits 3

•Featuresbymodels 5

•Usefultoknow 6

• About this user’s guide 7

• Safety information 8

• Machine overview 14

• Control panel overview 17

• Turning on the machine 18

• Installing the driver locally 19

• Reinstalling the driver 20



Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature.

• To save paper, you can print multiple pages on one single sheet of

paper (see Advanced Guide).

• To save paper, you can print on both sides of the paper (double-

sided printing) (see Advanced Guide).

• To save electricity, this machine automatically conserves electricity

by substantially reducing power consumption when not in use.

Print with excellent quality and speed

• You can print with a resolution of up to 1,200 x 1,200 dpi effective

output.

• Fast, on-demand printing.

- For single-side printing, 35 ppm (A4) or 37 ppm (Letter).

- For duplex printing, 17 ppm (A4) or 18 ppm (Letter).

Convenience

• Samsung Easy Printer Manager and Samsung Printer Status (or Smart

Panel) are a program that monitors and informs you of the machine’s

status and allows you to customize the machine’s settings (see

Advanced Guide).

• AnyWeb Print helps you screen-capture, preview, scrap, and print

the screen of Windows Internet Explorer more easily, than when you

use the ordinary program (see Advanced Guide).

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on

page 79).

• Print watermark: You can customize your documents with words,

such as “Confidential” (see Advanced Guide).

• Print posters: The text and pictures of each page of your document

are magnified and printed across the multiple sheets of paper and

can then be taped together to form a poster (see Advanced Guide).



Key benefits

• You can print in various operating systems (see "System requirements" on page 82).

• Your machine is equipped with a USB interface and/or a network interface.

Expand your machine’s capacity

• This machine has an extra memory slot for adding more memory (see "Available accessories" on page 48).

• Emulation compatible with PostScript 3 (PS3) enables PS printing.



Features by models

Some features and optional goods may not be available depending on model or country.

( ●: Included, ○: Optional, Blank: Not available)

Features ML-3750ND ML-3753ND

Hi-Speed USB 2.0 port 1 ● ●

Hi-Speed USB 2.0 port 2 ●

IEEE 1284 parallel connector ○ ○

Network Interface Ethernet 10/100/1000 Base TX wired LAN ● ●

IPv6 ● ●

Eco printing ● ●

Duplex (2-sided) printing ● ●

Samsung Easy Printer Manager ● ●

Memory ○ ○

Tray 2 (520 sheets) ○ ○

SyncThru™ Web Service ● ●

PCL printer driver ● ●

PS printer driver ● ●

XPS printer driver ● ●

Useful to know

The machine does not print.

• Open the print queue list and remove the document from

the list (see "Canceling a print job" on page 40).

• Remove the driver and install it again (see "Installing the

driver locally" on page 19).

• Select your machine as your default machine in your

Windows.

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/

region to view product service information.

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual

and troubleshoot accordingly (see "Understanding the

status LED" on page 69).

A paper jam has occurred.

• Open and close the front door.

• Check the instructions on removing jammed paper in this

manual and troubleshoot accordingly (see "Clearing

paper jams" on page 63).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner

cartridge.

• Try a different print resolution setting.

• Replace the toner cartridge.

Where can I download the machine’s driver?

• Visit www.samsung.com/printer to download the latest

machine’s driver, and install it on your system.

1. Introduction

About this user’s guide

This user's guide provides information for your basic understanding

of the machine as well as detailed steps to explain machine usage.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the

troubleshooting chapter.

• Terms used in this user’s guide are explained in the glossary

chapter.

• All illustrations in this user’s guide may differ from your machine

depending on its options or model you purchased.

• The screenshots in this user's guide may differ from your machine

depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows



Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.



General icons

Icon Text Description

Caution

Gives users information to protect the

machine from possible mechanical damage

or malfunction.

Note

Provides additional information or detailed

specification of the machine function and

feature.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to

you and others, and to prevent any potential damage to your

machine. Be sure to read and understand all of these instructions

before using the machine. After reading this section, keep it in a safe

place for future reference.



Important safety symbols

Explanation of all icons and signs used in this chapter



Operating environment

Warning

Warning Hazards or unsafe practices that may result in

severe personal injury or death.

Caution Hazards or unsafe practices that may result in

minor personal injury or property damage.

Do not attempt.

Do not use if the power cord is damaged or if the

electrical outlet is not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water,

small metal or heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke,

makes strange noises, or generates an odd odor,

immediately turn off the power switch and unplug the

machine.

• The user should be able to access the power outlet in

case of emergencies that might require the user to pull

the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by

a heavy object could result in electric shock or fire.

Safety information 9

1. Introduction

Caution



Operating method

Caution

Do not remove the plug by pulling on the cord; do not

handle the plug with wet hands.

This could result in electric shock or fire.

During an electrical storm or for a period of non-

operation, remove the power plug from the electrical

outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet

appears damaged, unplug the machine from all

interface connections and request assistance from

qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the plug does not easily enter the electrical outlet, do

not attempt to force it in.

Call an electrician to change the electrical outlet, or this

could result in electric shock.

Do not allow pets to chew on the AC power, telephone

or PC interface cords.

This could result in electric shock or fire and/or injury to

your pet.

If the machine does not operate properly after these

instructions have been followed, unplug the machine

from all interface connections and request assistance

from qualified service personnel.

Otherwise, this could result in electric shock or fire.

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine

and paper tray.

You may get injured.

Safety information 10

1. Introduction



Installation / Moving

Warning

Caution

Do not block or push objects into the ventilation

opening.

This could result in elevated component temperatures

which can cause damage or fire.

Be care when replacing paper or removing jammed

paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the

paper output area may get hot. Do not allow children to

touch.

Burns can occur.

When removing jammed paper, do not use tweezers or

sharp metal objects.

It can damage the machine.

Do not allow too many papers to stack up in the paper

output tray.

It can damage the machine.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord

from the electrical outlet.

Do not place the machine in an area with dust, humidity,

or water leaks.

This could result in electric shock or fire.

Before moving the machine, turn the power off and

disconnect all cords.

Then lift the machine:

• If the machine weighs under 20 kg (44.09 lbs), lift with

1 person.

• If the machine weighs 20 kg (44.09 lbs) - 40kg (88.18

lbs), lift with 2 people.

• If the machine weighs more than 40 kg (88.18 lbs), lift

with 4 or more people.

The machine could fall, causing injury or machine

damage.

Otros manuales para ML-3750ND

Tabla de contenidos

Otros manuales de Impresora de Samsung

Samsung

Samsung ML--6100 Guía de inicio rápido

Samsung

Samsung ML-1910 Manual de usuario

Samsung

Samsung CLP-300 Manual de usuario

Samsung

Samsung SRP-350 Bixolon Manual de usuario

Samsung

Samsung ProXpress M3320ND Instrucciones de funcionamiento

Samsung

Samsung 6050 Series Manual de usuario

Samsung

Samsung QWIKLASER 5100A Manual de usuario

Samsung

Samsung ML-2150 Manual de usuario

Samsung

Samsung ML-1865W Guía del usuario

Samsung

Samsung CLP-680ND: CLP-775ND Manual del operador

Samsung

Samsung ML-1200 Series Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Samsung

Samsung ProXpress M4530NX Manual de usuario

Samsung

Samsung ML-1200 Series Manual de usuario

Samsung

Samsung CLP-770ND - Color Laser Printer Manual de usuario

Samsung

Samsung ML-2010 Series Manual de usuario

Samsung

Samsung Xpress M2875FD Manual de usuario

Samsung

Samsung C41x Series Manual de usuario

Samsung

Samsung CLP-650 Series Manual de usuario

Samsung

Samsung SPP 2020 - Photo Printer - 20 Sheets Manual de usuario

Samsung

Samsung SCX 6555N - MultiXpress Mono Multifunction Manual de usuario

Samsung

Samsung Xpress M2020W Manual de usuario

Samsung

Samsung CLP-325 Series Manual de usuario

Samsung

Samsung ML-1610 - B/W Laser Printer Guía del usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario
