Samsung YP-K5AB Manual de usuario

For Your Safety

Read this manual carefully to ensure proper use of the player and

to avoid any danger or physical damage.

WARNING

Product Use

Improper use can result in explosion,

fire or electric shock. To avoid your hearing damage

Do not disassemble, repair

or modify this player on

your own.

Do not get the player wet

or drop it in water.

If the player gets wet, do not

switch it on. Contact a Service

Center.

Do not place the player in

damp, dusty or sooty areas,

as it could result in fire or

electric shock.

Avoid using your player at

high volume levels, as it may

result in permanent

hearing damage.

If you experience ringing in

your ears while using the

earphone, remove the

earphone immediately and

lower the volume.

To avoid a risk of traffic accident

Do not use the earphones while you are

driving a bicycle, automobile or motorcycle.

It can cause a serious accident and furthermore,

is prohibited by law in some areas.

Using the earphones while walking, in particular,

on a crosswalk, can lead to a serious accident.

Take care not to tangle the earphone cable

around your arms or neighboring objects

while driving, working out or walking, as it

could result in a car accident or other

injuries.

Do not leave the player in

areas above 35°C(95°F)

(such as a sauna or inside

a parked car).

During hot weather, the

temperature inside a car may

rise up to 80°C(176°F).

Failing to heed the player instructions may cause serious injury.

Chapter 1. Preparation

CAUTION

Product Use

Management of Important Data Avoid malfunction

Be sure to back up

important data.

Please be aware that we

claim no responsibility for

damage from data loss due

to breakdown, repair or other

causes.

Avoid malfunction

Failure to follow all instructions lead to physical injuries or damage to the player.

Do not cause excessive

impact on the player by

dropping it. Do not place

heavy objects on top of the

player.

Prevent any foreign

particles or dust from

entering into the player.

Always use the accessories

provided by or approved by

Samsung.

Do not spray water on the

player. Never clean the

player with chemical

substances such as

benzene or thinner, as it may

cause fire, electric shock or

deteriorate the surface.

Do not place the player near

magnetic objects, as it may

cause a malfunction.

Basic Information .......................................6

Components...............................................6

Screen Display Information........................9

Button Functions......................................10

Charging the battery ................................12

Basic Use.................................................13

Contents

Chapter 1. Preparation

Chapter 2.

Loading Your Desired File

Loading Your Desired File......................16

Installing Samsung Media Studio ............16

Connecting to your PC.............................17

Adding Files/Folders in

Samsung Media Studio............................18

Transferring Files to the Player with

Samsung Media Studio............................20

Using as a Removable Disk ...................22

Disconnecting from your PC..................23

Chapter 3. Multimedia function

Listening to Music....................................24

Creating a Playlist Using

Samsung Media Studio............................28

To Play a Playlist......................................30

Using the Music Option Menu..................31

Photo Viewing ...........................................33

Photo Viewing..........................................33

Using the Photo Option Menu..................34

Listening to FM Radio .............................35

Listening to FM Radio..............................35

Setting FM Presets ..................................38

To Delete Presets.....................................40

Setting FM Radio.....................................41

For Your Safety ..........................................2

Contents .......................................................4

Chapter 4. Setting

Settings.......................................................42

Setting Alarm............................................42

Setting Display.........................................44

Setting Time ............................................46

Setting Language.....................................48

Setting the System ..................................49

Chapter 5. Troubleshooting

Troubleshooting........................................51

Chapter 6. Appendix

Menu Tree...................................................53

Product Specifications............................54

Product Features

High-quality Stereo Speaker! Longer Play Time and Shorter

Downloading!

■

Slide the speaker unit to reveal it, with

which you can enjoy a dynamic music.

■

You can share your favorite music anytime

and anywhere.

■

A fully charged battery can play up to 30

hours of music (when using the earphone).

■

The player supports USB 2.0 capability,

much faster than USB 1.1 to enable faster

communication with the PC.

Touchpad Supporting Various File

Formats!

■

You can tap on the touch pad to navigate

through the menus.

■

Supports various file formats including

MP3, WMA and Ogg.

■

The image file is converted to JPG format

before transmitted to the player.

Easy & Simple Menu Structure Convenience

■

Easy to use with a simple menu structure.

■

You can set your own graphic display by

taking advantage of the screen saver and

user equalizer.

■

You can take advantage of a variety of

features including FM radio, alarming,

photo view, etc.

■

You can add your favorite music file to

the alarm melody list.

Chapter 1. Preparation

Product Features/Components

Front, Right Side and Top

Power &

Hold Switch

Speaker

Screen Display

Back Button

Play/Pause &

Select Button

Menu Button

Button

All buttons are 'Light-touch' buttons.

Components

Basic Information

Bottom/Rear

USB

Connection

Port

Earphone

Jack Reset Hole

Components (Continued)

Basic Information

[Rear]

[Bottom]

Checking the Accessories

Player Earphones USB Cable

Installation CD

■Design of accessories is subject to change for the purpose of improvement, without notice.

Chapter 1. Preparation

Components/Screen Display Information

Screen Display Information

Basic Information

NOTE

■ The screen pictures are for illustration purposes only. The actual screen may differ.

1Repeat Play Display

3Music Information

2Equalizer

4Play Status Bar

5Current Music Number/

Total Number Display

6Alarm Display

7Battery Status Display

8Play Time Indicator

9Play/Pause Display

Music

Normal

1.Life is cool

0002/0020

√

00:02:20

Button Functions

Basic Information

■

Slide and hold the button in the opposite direction of the arrow to turn the

power on/off.

■ Slide and release it in the arrow direction to lock the buttons.

■ Moving up, down, left and right and Function Selection.

Tap to move up or down by one selection.

Tap to move left or right by one selection.

Press and hold to move up or down continuously.

Short tap to select the play/pause and function, move to the

next screen.

■ Search for a track and control volume while listening to music.

Press and hold to scan to a point on the current track.

Tap to move to the previous track or to play the current track

from the start.

Press and hold to scan to a point on the current track.

Tap and release to move to the next track.

Tap to reduce/increase the volume.

■ Long tap to move to the main menu.

■

Short tap to move to the previous screen.

Buttons Functions and Use

■

Tap to display the option menu.
