Samsung SyncMaster S19B150B Manual de usuario

User manual

S19B150B

S24B150BL

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00192E-04

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

6 Copyright

6 Icons used in this manual

7 Cleaning

8 Securing the Installation Space

8 Precautions for storage

9 Safety Precautions

9Symbols

10 Electricity and Safety

11 Installation and Safety

13 Operation and Safety

17 Correct posture to use the product

PREPARATIONS 18 Checking the Contents

18 Removing the Packaging

19 Checking the Components

20 Parts

20 Frontal Buttons

22 Reverse Side

23 Installation

23 Attaching the Stand

24 Adjusting the Product Tilt

24 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

25 Before Connecting

25 Pre-connection Checkpoints

25 Connecting the Power

26 Connecting and Using a PC

26 Connecting to a PC

27 Driver Installation

28 Setting Optimum Resolution

29 Changing the Resolution Using a PC

Table Of Contents

Table Of Contents 3

SCREEN SETUP 33 Brightness

33 Configuring Brightness

34 Contrast

34 Configuring Contrast

35 Sharpness

35 Configuring Sharpness

36 SAMSUNG MAGIC Bright

36 Configuring SAMSUNG MAGIC Bright

37 Coarse

37 Adjusting Coarse

38 Fine

38 Adjusting Fine

CONFIGURING TINT 39 SAMSUNG MAGIC Color

39 Configuring SAMSUNG MAGIC Color

40 Red

40 Configuring Red

41 Green

41 Configuring Green

42 Blue

42 Configuring Blue

43 Color Tone

43 Configuring the Color Tone Settings

44 Gamma

44 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

45 H-Position & V-Position

45 Configuring H-Position & V-Position

46 Image Size

46 Changing the Image Size

Table Of Contents

Table Of Contents 4

47 Menu H-Position & Menu V-Position

47 Configuring Menu H-Position & Menu V-

Position

SETUP AND RESET 48 Reset

48 Initializing Settings (Reset)

49 Language

49 Changing the Language

50 Eco Saving

50 Configuring Eco Saving

51 Off Timer On/Off

51 Configuring Off Timer On/Off

52 Off Timer Setting

52 Configuring Off Timer Setting

53 PC/AV Mode

53 Configuring PC/AV Mode

54 Key Repeat Time

54 Configuring Key Repeat Time

55 Customized Key

55 Configuring Customized Key

56 Auto Source

56 Configuring Auto Source

57 Display Time

57 Configuring Display Time

58 Menu Transparency

58 Changing Menu Transparency

INFORMATION MENU AND

OTHERS

59 INFORMATION

59 Displaying INFORMATION

60 Configuring Brightness and Contrast in

the Initial Screen

Table Of Contents

Table Of Contents 5

INSTALLING THE

SOFTWARE

61 Magic Tune

61 What is MagicTune?

61 Installing the Software

62 Removing the Software

63 MultiScreen

63 Installing the Software

64 Removing the Software

TROUBLESHOOTING

GUIDE

65 Requirements Before Contacting

Samsung Customer Service Center

65 Testing the Product

65 Checking the Resolution and Frequency

65 Check the following.

67 Q & A

SPECIFICATIONS 69 General

71 PowerSaver

72 Standard Signal Mode Table

APPENDIX 75 Contact SAMSUNG WORLDWIDE

81 Responsibility for the Pay Service (Cost

to Customers)

81 Not a product defect

81 A Product damage caused by customer's fault

81 Others

82 Correct Disposal

82 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

83 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 75) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

An electric shock or fire may result.

Do not plug many products into the same power socket.

Otherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

An unstable connection may cause a fire.

Ensure you connect the power plug to a grounded power socket. (type 1

insulated devices only).

An electric shock or injury may result.

Do not bend or pull the power cord with force. Do not weigh the power cord

down with a heavy object.

A damaged power cord may cause an electric shock or fire.

Do not place the power cord or product near heat sources.

An electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

Otherwise, a fire may result.
