Samsung SyncMaster C24A650X Manual de usuario

User Manual

C24A650X

C27A650X

C24A650U

C27A650U

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00082D-02

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

7 Symbols for safety precautions

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

9 Safety Precautions

9 Electricity and Safety

11 Installation

13 Operation

17 Correct posture to use the product

PREPARATIONS 18 Checking the Contents

18 Removing the Packaging

19 Checking the Components

21 Parts

21 Frontal Buttons

23 Reverse Side

25 Installation

25 Attaching the Stand

26 Adjusting the Product Tilt and Height

26 Rotating the Monitor

27 Attaching and detaching the wireless-

connection dongle (Rx)

28 Installing a Wall-mount Kit or Desktop Stand

29 Anti-theft Lock

30 "MagicRotation Auto"

USING "CENTRAL

STATION"

31 About "Central Station"

32 Software Installation for Using "Central

Station"

32 Installing "Samsung Central Station Setup"

Table Of Contents

Table Of Contents 3

34 Connecting the Product to a PC to Use

"Central Station"

34 Connecting to a PC via Wireless USB

38 Connecting to a PC via the USB Cable

39 Utilizing "Central Station"

39 Using the Product as a USB HUB

41 Connecting to a LAN

42 Configuring the Central Station Monitor

42 Dynamic IP

43 Static IP

46 Notice before your use of Wireless USB

or USB Mode

CONNECTING AND USING

A SOURCE DEVICE

47 Before Connecting

47 Pre-connection Checkpoints

48 Connecting and Using a PC

48 Connecting to a PC

50 Driver Installation

51 Setting Optimum Resolution

52 Changing the Resolution Using a PC

54 Connecting Headphones

55 Connecting the Power

SCREEN SETUP 56 MAGIC

56 SAMSUNG MAGIC Bright

58 SAMSUNG MAGIC Color

59 Brightness

59 Configuring Brightness

60 Contrast

60 Configuring Contrast

61 Sharpness

61 Configuring Sharpness

Table Of Contents

Table Of Contents 4

62 Coarse

62 Adjusting Coarse

63 Fine

63 Adjusting Fine

64 Response Time

64 Configuring Response Time

CONFIGURING TINT 65 Red

65 Configuring Red

66 Green

66 Configuring Green

67 Blue

67 Configuring Blue

68 Color Tone

68 Configuring the Color Tone Settings

69 Gamma

69 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

70 Image Size

70 Changing the Picture Size

71 H-Position & V-Position

71 Configuring H-Position & V-Position

72 Menu H-Position & Menu V-Position

72 Configuring Menu H-Position & Menu V-

Position

Table Of Contents

Table Of Contents 5

SETUP AND RESET 73 HUB

73 Auto Wireless Detection

74 Wireless Connection

75 USB Connection

76 Analog

77 HDMI

78 USB Super Charging

78 Wireless ID

79 ECO

79 Eco Motion Sensor

81 Eco Light Sensor

84 Eco Saving

85 Eco Icon Display

87 Menu Transparency

87 Changing Menu Transparency

88 Language

88 Changing the Language

89 PC/AV Mode

89 Configuring PC/AV Mode

90 Auto Source

90 Configuring Auto Source

91 Display Time

91 Configuring Display Time

92 Key Repeat Time

92 Configuring Key Repeat Time

93 Customized Key

93 Configuring Customized Key

94 Off Timer On/Off

94 Configuring Off Timer On/Off

95 Off Timer Setting

95 Configuring Off Timer Setting

Table Of Contents

Table Of Contents 6

96 Reset

96 Initializing Settings (Reset)

INFORMATION MENU AND

OTHERS

97 INFORMATION

97 Displaying INFORMATION

97 Configuring Brightness in the Startup

Screen

TROUBLESHOOTING

GUIDE

98 Requirements Before Contacting

Samsung Customer Service Center

98 Testing the Product

98 Checking the Resolution and Frequency

99 Check the followings.

101 Q & A

SPECIFICATIONS 103 General

104 PowerSaver

105 Standard Signal Mode Table

APPENDIX 106 Contact SAMSUNG WORLD WIDE

110 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

Symbols for safety precautions

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor with a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. A rise in the internal temperature may cause

a fire and damage the product. Be sure to allow the amount of space as shown below or greater

when installing the product.

The exterior may differ depending on the product.

Precautions for storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used

nearby.

Be sure to contact Samsung Customer Service Center (page 106) if the inside of the monitor needs

cleaning. (service fee will be charged).

Safety Precautions

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

10 cm

10 cm 10 cm

10 cm

Before Using the Product

Warning

Do not use a damaged power cord or plug, or a loose power socket.

An electric shock or fire may result.

Do not plug many products into the same power socket.

Otherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

An unstable connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated devices

only).

An electric shock or injury may result.

Do not bend or pull the power cord with force. Do not weigh the power cord

down with a heavy object.

A damaged power cord may cause an electric shock or fire.

Do not place the power cord or product near heat sources.

An electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

Otherwise, a fire may result.
