Samsung SyncMaster 230MXN Manual de usuario

LCD DISPLAY

quick start guide

230TSN, 230MXN

Introduction

Package Contents

Note

Please make sure the following items are included with your LCD Display.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

Unpacking

LCD Display

Manuals

Quick Setup Guide Warranty Card

(Not available in all loca-

tions)

User's Guide, MagicInfo

Software CD, MagicInfo

Manual CD

Cables

Power Cord

Others

Remote Control Batteries (AAA X 2)

(Not available in all loca-

tions)

Ferrite Core for LAN cable

Sold separately

Wall Mount KIT D-Sub Cable LAN Cable

USB Cable HDMI Cable RS232C Cable

Ferrite Core

•The ferrite cores are used to shield the cables from interfer-

ence.

• When connecting a cable, open the ferrite core and clip it

around the cable near the plug.

Installing a Wall Mount

This product provides a wall mount of 100 mm x 100 mm that complies with the VESA spec-

ifications.

100 mm x 100 mm

A. Wall Mount Base

B. Wall Mount Kit (Optional)

1. Turn the product off and unplug the power cord from the wall outlet.

2. Place a soft cloth or cushion on a flat surface to protect the panel and place the product

face down.

3. Separate the stand.

4. Align the groove of the Monitor's wall mount base with the groove in the wall mount ki

and firmly fix the wall mount kit by fastening the screws.

Introduction

Note

•If you use a screw that is longer than the standard specifications, the inside of the product

may be damaged.

• For wall mounts that are not compatible with the standard VESA specifications, the length

of the screw may differ depending on the corresponding specifications.

• Do not use screws that are incompatible with the standard VESA specifications and do

not assemble them using excessive force.

This may result in damage to the product or injury due to the product falling. Samsung

shall not be held liable for any damage or injury.

• Samsung shall not be held liable for any damage to the product or injury caused by using

a stand that is not compatible with the specified specifications or due to an installation not

performed by an authorized installation engineer.

• When installing the product using a wall mount, purchase a wall mount that provides at

least 4 inches (10 cm) of space from the wall.

• Samsung shall not be held liable for any problems caused by using a stand that is not

compatible with the specified specifications.

• Use a wall mount according to specifications of your country.

Your LCD Display

Front

SOURCE/[ ] button

Switches from PC mode to Video mode. Selects the input source that an

external device is connected to.

[PC] →[HDMI] →[MagicInfo]

Activates a highlighted menu item.

MENU button [MENU]

Opens the on-screen menu and exits from the menu. Also use to exit the

OSD menu or return to the previous menu.

- VOL +

Moves from one menu item to another horizontally or adjusts selected

menu values. When OSD is not on the screen, press the button to adjust

volume.

SEL

Introduction

Moves from one menu item to another vertically or adjusts selected menu

values.

Power button [ ]

Use this button for turning the LCD Display on and off.

Brightness Sensor

Automatically detects the surrounding brightness it accordingly.

Power indicator

Shows PowerSaver mode by blinking green

Note

See PowerSaver described in the manual for further information regarding

power saving functions. For energy conservation, turn your LCD Display

OFF when it is not needed or when leaving it unattended for long periods.

Remote Control Sensor

Aim the remote control towards this spot on the LCD Display.

Rear

Note

For detailed information concerning cable connections, refer to Connecting Cables under

Setup. The LCD Display 's configuration at the back may vary slightly depending on the model.

POWER S/W ON [

│

] / OFF [O]

Switches the LCD Display On/Off.

POWER

The power cord plugs into the LCD Display

and the wall outlet.

Introduction

RGB IN

Connect the RGB IN terminal at the back of

your product to your computer.

VIDEO OUT

Connect between the [VIDEO OUT] port on

the product and the D-Sub port on your mon-

itor using a D-Sub cable.

HDMI IN

Connect the HDMI terminal at the back of

your LCD Display to the HDMI terminal of

your digital output device using a HDMI ca-

ble.

Connect your headphones to the Head-

phone connection terminal.

LAN

LAN Connection Terminal

Keyboard / Mouse, Mass Storage Device

Compatible.

AUDIO IN

Connect the audio cable for your product to

the audio port on the back of your computer.

RS232C IN

MDC(Multiple Display Control) Program Port

Introduction

Kensington Lock

The Kensington Lock is a device used to

physically fix the system when using it in a

public place. The locking device has to be

purchased separately. The appearance and

locking method may differ from the illustra-

tion depending on the manufacturer. Refer to

the manual provided with the Kensington

Lock for proper use. The locking device has

to be purchased separately.

Note

The location of the Kensington Lock may be

different depending on the model.

Using the Anti-Theft Kensington Lock

1. Insert the locking device into the Ken-

sington slot on the Monitor and turn

it in the locking direction .

2. Connect the Kensington Lock cable.

3. Fix the Kensington Lock to a desk or a

heavy stationary object.

Note

See Connecting Cables for further information regarding cable connections.

Remote Control

Note

The performance of the remote control may be affected by a TV or other electronic device

operating near the LCD Display , causing a malfunction due to interference with the frequen-

cy.

Introduction

POWER

OFF

Number Buttons

DEL / GUIDE button

+ VOL -

SOURCE

D.MENU

TOOLS

Up-Down Left-Right buttons

INFO

COLOR BUTTONS

TTX/MIX

MTS/DUAL

ENTER/PRE-CH

MUTE

CH/P

RETURN

EXIT

MagicInfo

1. POWER Turns the product On.

2. OFF Turns the product Off.

3. Number Buttons Used to enter the password during the OSD adjustment or

to use MagicInfo.

4. DEL / GUIDE but-

ton

The "-" button is used to select Digital channels.

Electronic Program Guide (EPG) display.

- This function does not work for this LCD Display.

5. + VOL - Adjusts the audio volume.

6. SOURCE Press the button to change the input signal SOURCE.

Changing the SOURCE is only allowed for external devices

that are connected to the LCD Display at the time.

7. D.MENU DTV menu display

- This function does not work for this LCD Display.

8. TOOLS Use to quickly select frequently used functions.

Introduction

- This function does not work for this LCD Display.

9. Up-Down Left-Right but-

tons

Moves from one menu item to another horizontally, vertically

or adjusts selected menu values.

10. INFO Current picture information is displayed on the upper left

corner of the screen.

11. COLOR BUTTONS Press to add or delete channels and to store channels to the

favorite channel list in the “Channel List” menu.

- This function does not work for this LCD Display.

12. TTX/MIX TV channels provide written information services via tele-

text.

- Teletext Buttons

- This function does not work for this LCD Display.

13. MTS/DUAL - This function does not work for this LCD Display.

MTS-

You can select MTS (Multichannel Television Stereo) mode.

Audio Type MTS/S_Mode Default

FM Stereo Mono Mono Manual

Change

Stereo Mono ↔ Stereo

SAP Mono ↔ SAP Mono

DUAL-

STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM

MONO/NICAM STEREO can be operated depending on the

broadcasting type by using the DUAL button on the remote

control while watching TV.

14. ENTER/PRE-CH This button is used to return to the immediately previous

channel.

- This function does not work for this LCD Display.

15. MUTE Pauses (mutes) the audio output temporarily. The audio

comes back on if MUTE or - VOL + is pressed in the Mute

mode.

16. CH/P In TV mode, selects TV channels.

- This function does not work for this LCD Display.

17. TV Selects the TV mode directly.

- This function does not work for this LCD Display.

18. MENU Opens the on-screen menu and exits from the menu or

closes the adjustment menu.

Introduction

19. RETURN Returns to the previous menu.

20. EXIT Exits from the menu screen.

21. MagicInfo MagicInfo Quick Launch Button.

Introduction
