Samsung OH46D Manual de usuario

User Manual

The colour and the appearance may differ depending on the

product, and the specifications are subject to change without

prior notice to improve the performance.

OH46D OH55D

Table of contents

Before Using the Product

Safety Precautions 7

Symbols 7

Cleaning 7

Storage 8

Electricity and Safety 8

Installation 9

Operation 11

Preparations

Checking the Components 14

Parts 15

ILLUMINANCE SENSOR & REMOTE SENSOR 15

Reverse Side 16

Power Box 17

Remote Control 18

Before Installing the Product

(Installation Guide) 20

Switching between portrait and landscape 20

Ventilation 20

Dimensions 22

Power Box Dimensions 22

Wall Mount Specifications 23

Connecting and Using a Source

Device

Before Connecting 24

Pre-connection Checkpoints 24

Before connecting cables 25

Connecting to a PC 26

Connection Using an HDMI-DVI Cable 26

Connection Using an HDMI Cable 26

Connecting to a Video Device 27

Connection Using an HDMI-DVI Cable 27

Connection Using an HDMI Cable 27

Connecting the HDBase-T 28

Connecting to an Audio System 29

Connecting the Power box 30

Changing the Input source 31

Source 31

Using MDC

MDC Programme Installation/Uninstallation 32

Installation 32

Uninstallation 32

Connecting to MDC 33

Using MDC via RS-232C

(serial data communications standards) 33

Using MDC via Ethernet 34

Home feature

Player 35

Approving a connected device from the server 36

Network Channel 38

Local Channel 38

Deployed Folders 38

My Templates 38

Available features in the Player page 39

Player page Settings menu 40

When Content is Running 41

File Formats Compatible with Player 43

File Formats Compatible with Video Wall 48

Schedule 50

Available features in the Schedule page 50

Template 52

Clone Product 55

ID Settings 56

Device ID 56

PC Connection Cable 56

Video Wall 57

Network Status 58

Picture Mode 59

On/Off Timer 60

On Timer 60

Off Timer 61

Holiday Management 61

Table of contents

Ticker 62

More settings 62

URL Launcher 63

Screen Adjustment

Picture Mode 64

Backlight / Contrast / Brightness / Sharpness /

Colour / Tint (G/R) 65

Colour Temperature 66

White Balance 67

2 Point 67

10 Point 67

Gamma 68

Calibrated value 68

Advanced Settings 69

Dynamic Contrast 70

Black Tone 70

Flesh Tone 70

RGB Only Mode 70

Colour Space 70

Motion Lighting 70

Picture Options 71

Colour Tone 72

Digital Clean View 72

MPEG Noise Filter 72

HDMI Black Level 72

Film Mode 73

Dynamic Backlight 73

Picture Size 74

Position 75

Zoom/Position 75

Picture Off 76

Reset Picture 76

OnScreen Display

Display Orientation 77

Onscreen Menu Orientation 77

Source Content Orientation 77

Aspect Ratio 77

Screen Protection 78

Auto Protection Time 78

Screen Burn Protection 78

Message Display 81

Source Info 81

No Signal Message 81

MDC Message 81

Menu Transparency 82

Menu Language 82

Reset OnScreen Display 83

Sound Adjustment

Sound Mode 84

Sound Output 84

Reset Sound 85

Network

Network Status 86

Network Settings 86

Network Type 86

Network Settings (Wired) 87

Multimedia Device Settings 89

Connect to server 89

MagicInfo Mode 89

Server Access 89

FTP Mode 89

Device Name 89

System

Setup 90

Initial settings (System) 90

Time 92

Clock Set 92

DST 92

Sleep Timer 92

Table of contents

Power On Delay 92

Auto Source Switching 93

Primary Source Recovery 93

Primary Source 93

Secondary Source 93

Power Control 94

Auto Power On 94

Max. Power Saving 94

Standby Control 94

Power Button 94

Network Standby 94

Eco Solution 95

Brightness Limit 95

Energy Saving 95

Eco Sensor 95

Screen Lamp Schedule 96

No Signal Power Off 96

Auto Power Off 96

Fan and Temperature 97

Fan Control 97

Fan Speed Setting 97

Outdoor Mode 97

Temperature Control 97

Device Manager 98

Keyboard Settings 98

Mouse Settings 99

Pointer Settings 100

Play via 101

Change PIN 101

General 102

Security 102

BD Wise 102

Anynet+ (HDMI-CEC) 103

Troubleshooting for Anynet+ 105

HDMI Hot Plug 107

DivX® Video On Demand 107

Game Mode 107

Reset System 108

Support

Software Update 109

Update now 109

Auto update 109

Contact Samsung 109

Go to Home 110

Player 110

Schedule 110

Template 110

Clone Product 110

ID Settings 110

Video Wall 111

Network Status 111

Picture Mode 111

On/Off Timer 111

Ticker 111

More settings 111

Reset All 112

Playing photos, videos and music

(Media Play)

Read the following before using media play with a

USB device 113

Using a USB device 115

Playing media content from a PC/mobile device 116

Features provided in the media content list

page 117

Menu items in the media content list page 118

Available buttons and features during photo

playback 119

Available buttons and features during video

playback 120

Available buttons and features during music

playback 121

Supported Subtitle and Media play file

formats 122

Subtitle 122

Supported image resolutions 122

Supported music file formats 123

Supported Video Formats 123

Table of contents

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Centre 125

Testing the Product 125

Checking the Resolution and Frequency 125

Check the followings. 126

Q & A 132

Specifications

General 134

PowerSaver 136

Preset Timing Modes 137

Appendix

Responsibility for the Pay Service

(Cost to Customers) 139

Not a product defect 139

A Product damage caused by customer's fault 139

Others 139

WEEE 140

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment) 140

Correct disposal of batteries in this product 140

Optimum Picture Quality and Afterimage Burn-

in Prevention 141

Optimum Picture Quality 141

Prevention of Afterimage Burn-in 141

Licence 143

Terminology 144

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

•An administration fee may be charged if either

-(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

-(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

•The amount of such administration charge will be advised to you before any work or home visit is carried out.

Chapter 01

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

•Do not use detergents that contain alcohol, solvent or

surface-active agents.

•Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-

coloured stains on the product.

―Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be

charged).

Electricity and Safety

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•An electric shock or fire may result.

Do not use multiple products with a single power socket.

•Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock

may result.

Insert the power plug all the way in so it is not loose.

•An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

•An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the

power cord under a heavy object.

•Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with

a dry cloth.

•A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not

use the power cord with other products.

•A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•The power cord must be disconnected to cut off power to the product

when an issue occurs.

•Note that the product is not completely powered down by using only

the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

•An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF

THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•A fire may result.

Have a technician install the wall-mount hanger.

•Installation by an unqualified person can result in an injury.

•Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or

closet.

•An increased internal temperature may cause a fire.

Install the product at least 10cm away from the wall to allow ventilation.

•An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•Children may suffocate.

Do not install the product on an unstable or vibrating surface (insecure shelf,

sloped surface, etc.)

•The product may fall and become damaged and/or cause an injury.

•Using the product in an area with excess vibration may damage the

product or cause a fire.

Do not install the product within the reach of young children.

•The product may fall and injure children.

•As the front is heavy, install the product on a flat and stable surface.

Edible oil, such as soybean oil, can damage or deform the product. Do not

install the product in a kitchen or near a kitchen counter.

Caution

Do not drop the product while moving.

•Product failure or personal injury may result.

Do not set down the product on its front.

•The screen may become damaged.

When installing the product on a cabinet or shelf, make sure that the

bottom edge of the front of the product is not protruding.

•The product may fall and become damaged and/or cause an injury.

•Install the product only on cabinets or shelves of the right size.

Set down the product gently.

•Product failure or personal injury may result.

SAMSUNG

Installing the product in an unusual place (a place exposed to a lot of fine

dust, chemical substances, extreme temperatures or a significant presence

of moisture, or a place where the product will operate continuously for an

extended period of time) may seriously affect its performance.

•Be sure to consult Samsung Customer Service Centre if you want to

install the product at such a place.

Otros manuales para OH46D

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Samsung

Samsung

Samsung 320TSN - SyncMaster - 32" LCD Flat Panel... Manual de usuario

Samsung

Samsung SyncMaster C27A750X Manual de usuario

Samsung

Samsung SyncMaster S27B550V Manual de usuario

Samsung

Samsung ED65E Manual de usuario

Samsung

Samsung SyncMaster 770TFT, 870TFT, 170T Manual de instrucciones

Samsung

Samsung 400FP-2 - SyncMaster - 40" LCD Flat Panel... Manual de usuario

Samsung

Samsung SyncMaster 2232BWPlus Manual de usuario

Samsung

Samsung HE40A Guía

Samsung

Samsung U24E850R Manual de usuario

Samsung

Samsung XL30 - SyncMaster - 30" LCD Monitor Manual de usuario

Samsung

Samsung QBC Manual de usuario

Samsung

Samsung S27A60U Series Manual de usuario

Samsung

Samsung SyncMaster 2343BW Guía de instalación

Samsung

Samsung 2243WM - SyncMaster - 22" LCD Monitor Manual de usuario

Samsung

Samsung PL-42E71S Manual de usuario

Samsung

Samsung SyncMaster 592V Manual de usuario

Samsung

Samsung S24A400UJ Series Manual de usuario

Samsung

Samsung 932GW - SyncMaster - 19" LCD Monitor Guía del usuario

Samsung

Samsung SyncMaster 210T Manual de usuario

Samsung

Samsung SyncMaster 932NW Manual de usuario

Samsung

Samsung F27T85 Series Manual de usuario

Samsung

Samsung ED32D Manual de usuario

Samsung

Samsung 78DF Manual de usuario

Samsung

Samsung PPM42M8H Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
