Samsung S19E200NY Manual de usuario

User manual

S19E200NY

S19E200BR

S19E200NW

S19E200BW

S22E200NY

S22E200N

S22E200B

S22E200BW

S23E200B

S24E200BL

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00479A-X0

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

18 Correct posture to use the product

PREPARATIONS 19 Checking the Components

19 Checking the Components

20 Parts

20 Frontal Buttons

24 Reverse Side

25 Installation

25 Attaching the Stand

26 Removing the Stand

27 Adjusting the Product Tilt

28 Installing a Wall-mount Kit or Desktop Stand

29 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

30 Before Connecting

30 Pre-connection Checkpoints

30 Connecting the Power

31 Connecting and Using a PC

31 Connecting to a PC

32 Driver Installation

33 Setting Optimum Resolution

Table Of Contents

Table Of Contents 3

SCREEN SETUP 34 Brightness

34 Configuring Brightness

35 Contrast

35 Configuring Contrast

36 Sharpness

36 Configuring Sharpness

37 Eye Saver Mode

37 Configuring Eye Saver Mode

38 Game Mode

38 Configuring Game Mode

39 SAMSUNG MAGIC Bright

39 Configuring SAMSUNG MAGIC Bright

41 SAMSUNG MAGIC Angle (S19E200NY /

S19E200NW / S22E200NY / S22E200N)

41 Configuring SAMSUNG MAGIC Angle

43 SAMSUNG MAGIC Upscale

43 Configuring SAMSUNG MAGIC Upscale

44 Image Size

44 Changing the Image Size

46 H-Position & V-Position

46 Configuring H-Position & V-Position

47 Coarse

47 Adjusting Coarse

48 Fine

48 Adjusting Fine

CONFIGURING TINT 49 Red

49 Configuring Red

50 Green

50 Configuring Green

Table Of Contents

Table Of Contents 4

51 Blue

51 Configuring Blue

52 Color Tone

52 Configuring the Color Tone Settings

53 Gamma

53 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

54 Language

54 Changing the Language

55 Menu H-Position & Menu V-Position

55 Configuring Menu H-Position & Menu V-

Position

56 Display Time

56 Configuring Display Time

57 Transparency

57 Changing Transparency

SETUP AND RESET 58 Reset

58 Initializing Settings (Reset)

59 Eco Saving Plus

59 Configuring Eco Saving Plus

61 Off Timer

61 Configuring Off Timer

62 Configuring Turn Off After

63 PC/AV Mode (S19E200BR / S19E200BW

/ S22E200B / S22E200BW / S23E200B /

S24E200BL)

63 Configuring PC/AV Mode

64 Key Repeat Time

64 Configuring Key Repeat Time

Table Of Contents

Table Of Contents 5

65 Source Detection (S19E200BR /

S19E200BW / S22E200B / S22E200BW /

S23E200B / S24E200BL)

65 Configuring Source Detection

INFORMATION MENU AND

OTHERS

66 INFORMATION

66 Displaying INFORMATION

67 Configuring Brightness, Contrast and

Sharpness from the Initial Screen

INSTALLING THE

SOFTWARE

68 Magic Tune

68 What is MagicTune?

68 Installing the Software

69 Removing the Software

70 MultiScreen

70 Installing the Software

71 Removing the Software

TROUBLESHOOTING

GUIDE

72 Requirements Before Contacting

Samsung Customer Service Center

72 Testing the Product

72 Checking the Resolution and Frequency

72 Check the following.

75 Q & A

SPECIFICATIONS 77 General (S19E200NY / S19E200NW)

78 General (S19E200BW / S19E200BR)

79 General (S22E200NY / S22E200N)

80 General (S22E200B / S22E200BW)

81 General (S23E200B / S24E200BL)

82 PowerSaver

84 Standard Signal Mode Table

Table Of Contents

Table Of Contents 6

APPENDIX 95 Contact SAMSUNG WORLD WIDE

103 Responsibility for the Pay Service (Cost

to Customers)

103 Not a product defect

103 A Product damage caused by customer's fault

103 Others

104 Correct Disposal

104 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

105 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 95) if the inside of the monitor needs

cleaning. (A service fee will be charged.)

3.93

inches

(10 cm)

3.93 inches (10 cm)

3.93

inches

(10 cm)

3.93 inches

(10 cm)

3.93 inches (10 cm)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
