Samsung S19C170B Manual de usuario

User Manual

S19C170B

S22C170B

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols for safety precautions

11 Electricity and Safety

12 Installation and Safety

14 Operation

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Removing the Packaging

20 Checking the Components

21 Parts

21 Frontal Button

23 Reverse Side

24 Installation

24 Attaching the Stand

25 Removing the Stand

26 Adjusting the Product Tilt

27 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

28 Before Connecting

28 Pre-connection Checkpoints

Table Of Contents

Table Of Contents 3

29 Connecting and Using a PC

29 Connection Using the D-SUB Cable (Analogue

Type)

30 Connection Using the DVI Cable

30 Connecting the Power

31 Driver Installation

32 Setting Optimum Resolution

33 Changing the Resolution Using a PC

SCREEN SETUP 37 Brightness

37 Configuring Brightness

38 Contrast

38 Configuring Contrast

39 Sharpness

39 Configuring Sharpness

40 Game Mode

40 Configuring Contrast

41 SAMSUNG MAGIC Bright

41 Configuring SAMSUNG MAGIC Bright

42 SAMSUNG MAGIC Upscale

42 Configuring SAMSUNG MAGIC Upscale

43 Image Size

43 Changing the Image Size

45 H-Position & V-Position

45 Configuring H-Position & V-Position

47 Coarse

47 Adjusting Coarse

48 Fine

48 Adjusting Fine

CONFIGURING TINT 49 Red

49 Configuring Red

Table Of Contents

Table Of Contents 4

50 Green

50 Configuring Green

51 Blue

51 Configuring Blue

52 Color Tone

52 Configuring the Color Tone Settings

53 Gamma

53 Configuring Gamma

COORDINATING OSD 54 Language

54 Configuring Language

55 Menu H-Position & Menu V-Position

55 Configuring Menu H-Position & Menu V-

Position

56 Display Time

56 Configuring Display Time

57 Transparency

57 Changing Transparency

SETUP AND RESET 58 Reset All

58 Initializing Settings (Reset All)

59 Eco Saving

59 Configuring Eco Saving

60 Off Timer

60 Configuring Off Timer

61 Configuring Turn Off After

62 PC/AV Mode

62 Configuring PC/AV Mode

63 Key Repeat Time

63 Configuring Key Repeat Time

Table Of Contents

Table Of Contents 5

64 Source Detection

64 Configuring Source Detection

INFORMATION MENU AND

OTHERS

65 INFORMATION

65 Displaying INFORMATION

66 Configuring Brightness and Contrast in

the Initial Screen

INSTALLING THE

SOFTWARE

67 MagicTune

67 What is "MagicTune"?

67 Installing the Software

68 Removing the Software

TROUBLESHOOTING

GUIDE

69 Requirements Before Contacting

Samsung Customer Service Center

69 Testing the Product

69 Checking the Resolution and Frequency

69 Check the following.

72 Q & A

SPECIFICATIONS 74 General

76 PowerSaver

77 Standard Signal Mode Table

APPENDIX 79 Contact SAMSUNG WORLD WIDE

85 Responsibility for the Pay Service (Cost

to Customers)

85 Not a product defect

85 A Product damage caused by customer's fault

85 Others

87 Correct Disposal

87 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

Table Of Contents

Table Of Contents 6

88 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

2013 Samsung Electronics

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor with a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire and

damage the product. Be sure to allow the amount of space as shown below or greater when installing

the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 79) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

10 cm10 cm

10 cm

Before Using the Product

Safety Precautions

Symbols for safety precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
