Samsung PL-50P5HD Manual de usuario

Owner’s Instructions

PL-50P5H

This device is a Class B digital apparatus.

BN68-00866V-01Eng(cover) 3/9/06 3:59 PM Page 3

Important Warranty Information

Regarding Television Format Viewing

Wide screen format PDP Displays (16:9, the aspect ratio of the screen width to height) are primarily

designed to view wide screen format full-motion video. The images displayed on them should primarily

be in the wide screen 16:9 ratio format, or expanded to fill the screen if your model offers this feature

and the images are constantly moving. Displaying stationary graphics and images on screen, such as

the dark side-bars on nonexpanded standard format television video and programming, should be

limited to no more than 5% of the total television viewing per week.

Additionally, viewing other stationary images and text such as stock market reports, video game

displays, station logos, web sites or computer graphics and patterns, should be limited as described

above for all televisions. Displaying stationary images that exceed the above guidelines

can cause uneven aging of PDP Displays that leave subtle, but permanent burned-in

ghost images in the PDP picture. To avoid this, vary the programming and images,

and primarily display full screen moving images, not stationary patterns or dark

bars.

On PDP models that offer picture sizing features, use these controls to view different formats as a full

screen picture.

Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a

result of format selection and use, as well as burned-in images, are not covered by your Samsung

limited warranty.

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 2

User Instructions

Screen Image retention

Do not display a still image (such as on a video game) on the plasma display panel for more than

several minutes as it can cause screen image retention. This image retention is also known as

“screen burn”. To avoid such image retention, refer to page 45 of this manual to reduce the

degree of brightness and contrast of the screen when displaying a still image.

Altitude

The PDP will not operate normally at altitudes above 6500 ft.

Heat on the top of the PDP TV

The top side of the product may be hot after long periods of use as heat dissipates from the panel

through the vent hole in the upper part of the product.

This is normal and does not indicate any defect or operation failure of the product.

However, children should be prevented from touching the upper part of the product.

The product is making a ‘cracking’ noise.

A ‘cracking’ noise may occur when the product contracts or expands due to a change of

surrounding environment such as temperature or humidity. This is normal and not a defect of the

unit.

Cell Defects

The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which

require sophisticated technology to produce. However, there may be few bright or dark pixels on

the screen. These pixels will have no impact on the performance of the product.

Avoid operating the TV at temperatures below 5°C (41°F)

A still image displayed too long may cause permanent damage to the PDP Panel.

Watching the PDP TV in 4:3 format for a long period of time may leave

traces of borders displayed on the left, right and center of the screen caused

by the difference of light emission on the screen.

Playing a DVD or a game console may cause similar effect to the screen.

Damages caused by the above effect are not covered by the Warranty.

Afterimage on the Screen.

Displaying still images from Video games and PC for longer than a certain period of time may

produce partial afterimages.

To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images for a

long time.

Warranty

Warranty does not cover any damage caused by image retention.

Burn-in is not covered by the warranty.

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 3

General Information

Your New Plasma Display Panel......................8

Remote Control Buttons ................................11

Wall Installation Instructions ..........................13

How to assemble the Stand-Base ..................17

Connections

Connecting VHF and UHF Antennas ..............20

Connecting Cable TV ..................................21

Connecting a VCR ......................................23

Connecting a Camcorder ............................24

Connecting a DVD Player (480i, 480p) ........25

Connecting a DTV Receiver (480p, 720p,

1080i) ......................................................26

Connecting to HDMI (High Definition

Multimedia Interface) (480p, 720p, 1080i) ..27

Connecting a Digital TV Set-Top Box (480p,

720p, 1080i) ............................................28

Connecting to an Analog Amplifier ..............29

Operation

Turning the TV On and Off ..........................32

Plug & Play Feature ....................................34

Memorizing the Channels ............................37

Adding and Erasing Channels ......................39

Viewing an External Signal Source................41

Picture Control

Changing the Picture Standard ....................44

Customizing the Picture Settings ....................45

Viewing the DNIe Demonstration ..................47

Changing the Screen Size ............................48

Viewing the Picture-in-Picture.........................50

Setting the My Color Control Mode ...............56

Sound Control

Customizing the Sound ..............................62

Using Automatic Sound Settings ...................63

Setting the TruSurround XT............................64

Choosing a Multi-Channel Sound (MTS) track ..65

Using the Auto Volume ................................66

Setting the On/Off Melody ..........................67

Selecting the Internal Mute ..........................68

Channel Control

Fine Tuning Analog Channels ......................70

LNA (Low Noise Amplifier) ..........................71

Connecting a PC and Operation

Connecting a PC ........................................74

Changing the Position of the Image ..............78

Picture Quality Adjustment............................79

Image Reset ................................................82

Table of Contents

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 4

Time Setting

Setting the Clock ........................................84

Setting the Sleep Timer ................................85

Setting the On/Off Timer..............................86

Function Description

Selecting a Menu Language ........................88

Digital Noise Reduction................................89

Setting the Blue Screen ................................90

Using the Color Weakness Enhancement

Option ......................................................91

Viewing Closed Captions ............................92

Using the Energy Saving Feature ..................93

Preventing Screen Burn-in ............................94

Reducing the Effects of Screen Burn ..............95

Appendix

Troubleshooting ..........................................98

Care and Maintenance ................................99

Specifications............................................100

Note

•The information contained in this Owner’s

Instructions is subject to change without prior

notice for improvement, and may vary

depending on the version of the TV’s software

and the regional conditions.

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 5

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 6

PLASMA DISPLAY PANEL

General Information

Your New Plasma Display Panel ......................................................8

Remote Control Buttons ................................................................11

Wall Installation Instructions ..........................................................13

How to assemble the Stand-Base....................................................17

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 7

Your New Plasma Display Panel

Front Panel

ŒSOURCE button

Press to display all of the available video

sources (TV, AV1, AV2, S-Video1, S-Video2,

Component1, Component2, PC, and HDMI).

´MENU button

Displays the main on-screen menu.

ˇVOL +,

buttons

Press to increase or decrease the volume.

Also used to select or adjust items on the

on-screen menu.

¨CH( , ) buttons

Press CH or CH to change channels.

Also used to move up or down in the on-screen

menu.

ˆ(Enter) button

Press to confirm a selection.

ØPower button

Press to turn the TV on and off.

Power indicator

- Power Off : Blue

- Power On : Off

∏Remote Control Sensor

Aim the remote control towards this spot on

the TV.

”

Speakers

∏”Ø

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 8

Side of the TV

Audio Input (L, R)

Video Input

S-Video Input

Checking Accessories

Power Cord Warranty Card/

Registration Card/

Safety Guide Manual

(Not available in all locations)

Owner’s Instructions Remote Control/

AAA Batteries

The following parts are sold separately and are available at most electronics stores.

Once you have unpacked your TV, check to make sure that you have all the parts shown here.

If any piece is missing or broken, call your dealer.

Antenna Cable

Component Cables (RCA)

HDMI/DVI cable

S-VIDEO Cable HDMI Cable

PC Cable PC Audio Cable

BN68-00866V-01Eng(002~031) 3/9/06 3:59 PM Page 9

Rear Panel

Notes

•Please be sure to match the color coded input terminals and cable jacks.

•For further details about connections, refer to pages 20-29.

•Whenever you connect an audio or video system to your television, ensure that all elements are

switched off. Refer to the documentation supplied with your equipment for detailed connection

instructions and associated safety precautions.

ŒPOWER IN

Connect the supplied power cord.

´SERVICE ONLY

Connector for service only.

ˇHDMI/DVI IN

Connect to the HDMI jack of a device with

HDMI output.

These inputs can also be used as a DVI

connection with separate analog audio inputs.

An optional HDMI/DVI cable will be

necessary to make this connection.

When using the optional HDMI/DVI adapter,

the DVI analog audio inputs on your TV allow

you to receive left and right audio from your

DVI device. (Not compatible with PC)

¨DVI AUDIO IN (AUDIO-L/R)

Connect to the DVI audio output jack of an

external device.

ˆPC IN

Connect to the video output jack on your PC.

ØPC AUDIO IN

Connect to the audio output jack on your PC.

∏COMPONENT IN 1, 2

Video (Y/PB/PR) and audio (L-AUDIO-R)

component inputs.

”ANT IN

75ΩCoaxial connector for Air/Cable

Network.

’AV OUT (VIDEO / AUDIO L/R)

Connect to the audio/video input jacks of a

recording VCR.

˝AV IN 1 (VIDEO / AUDIO L/R)

Video and audio inputs for external devices,

such as a camcorder or VCR.

ÔS-VIDEO 1

Video input for external devices with an

S-Video output, such as a camcorder or VCR.

BN68-00866V-01Eng(002~031) 3/10/06 10:37 AM Page 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Samsung

Samsung

Samsung S32R75 Series Manual de usuario

Samsung

Samsung 226CW - SyncMaster Manual de usuario

Samsung

Samsung SyncMaster 2033HD Manual de usuario

Samsung

Samsung QB43C Manual de usuario

Samsung

Samsung SyncMaster C27A750X Guía del usuario

Samsung

Samsung 275T - SyncMaster - 27" LCD Monitor Manual de usuario

Samsung

Samsung 400DXn - SyncMaster - 40" LCD Flat Panel... Manual de usuario

Samsung

Samsung SyncMaster 320P Manual de usuario

Samsung

Samsung SyncMaster S23B550V Guía del usuario

Samsung

Samsung SyncMaster CKG7507L Manual de usuario

Samsung

Samsung C24F392FH series Manual de usuario

Samsung

Samsung 940T - SyncMaster - 19" LCD Monitor Manual de usuario

Samsung

Samsung SyncMaster 172N Manual de usuario

Samsung

Samsung SYNCMASTER P2050N Manual de usuario

Samsung

Samsung 220WM - SyncMaster 22" LCD Monitor Manual de usuario

Samsung

Samsung 244T - SyncMaster - 24" LCD Monitor Manual de usuario

Samsung

Samsung SyncMaster 400EXn Manual de usuario

Samsung

Samsung SyncMaster S22A450BW Manual de usuario

Samsung

Samsung LSC460HJ03 Manual de usuario

Samsung

Samsung SyncMaster 650FP Manual de usuario

Samsung

Samsung SyncMaster 732NW PLUS Guía del usuario

Samsung

Samsung SyncMaster P2770FH Manual de usuario

Samsung

Samsung HLP4663W - 46" Rear Projection TV Manual de usuario

Samsung

Samsung SyncMaster S24A650S Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
