Samsung MD65C Manual de usuario

LFD DISPLAY

User Manual

The colour and the appearance may differ depending on the

product, and the specifications are subject to change without

prior notice to improve the performance.

MD65C

BN46-00350C-00

Table of contents

Before Using the Product

Safety Precautions 8

Symbols 8

Cleaning 8

Storage 9

Electricity and Safety 9

Installation 10

Operation 12

Preparations

Checking the Contents 15

Removing the Packaging 15

Checking the Components 16

Parts 19

Control Panel 19

Reverse Side 21

Assembling the Holder-Wire stand 22

Remote Control 23

Connection Using an IR Stereo Cable

(sold separately) 26

Before Installing the Product (Installation

Guide) 27

Tilting Angle and Rotation 27

Ventilation 27

Dimensions 28

Installing the Wall Mount 29

Preparing before installing Wall-Mount 29

Installing the Wall Mount Kit 29

Wall Mount Kit Specifications (VESA) 30

Remote Control (RS232C) 31

Cable Connection 31

Connection 34

Control Codes 35

Connecting and Using a Source

Device

Before Connecting 44

Pre-connection Checkpoints 44

Connecting to a PC 45

Connection using the D-SUB cable

(Analogue type) 45

Connection using a DVI cable (Digital type) 46

Connection Using an HDMI-DVI Cable 46

Connection Using an HDMI Cable 47

Connection Using an DP Cable 47

Changing the Resolution 48

Changing the Resolution on Windows XP 48

Changing the Resolution on Windows Vista 48

Changing the Resolution on Windows 7 49

Changing the Resolution on Windows 8 49

Connecting an External Monitor 50

Connecting to a Video Device 51

Connection Using the AV Cable 51

Connection Using the component Cable 52

Connection Using an HDMI-DVI Cable 52

Connection Using an HDMI Cable 53

Connecting to an Audio System 54

Connecting the network box

(Sold separately) 55

MagicInfo 55

Plug In Module 58

Changing the Input source 59

Source 59

Using MDC

Configuring Settings for Multi Control 61

Configuring settings for Multi Control 61

MDC Programme Installation/Uninstallation 63

Installation 63

Uninstallation 63

What is MDC? 64

Connecting to MDC 64

Connection Management 67

User Login 68

Auto Set ID 69

Cloning 70

Command Retry 71

Getting Started with MDC 72

Main Screen Layout 73

Menus 73

Table of contents

Screen Adjustment 75

Advanced features 78

Sound Adjustment 80

System Setup 80

Tool Settings 89

Other Functions 92

Group Management 93

Schedule Management 95

Troubleshooting Guide 97

Screen Adjustment

Picture Mode 99

If the input source is PC, DVI or DisplayPort 99

If the input source is AV, Component, HDMI1,

HDMI2 99

Backlight / Contrast / Brightness / Sharpness /

Colour / Tint (G/R) 100

Screen Adjustment 101

Picture Size 101

Position 103

Zoom/Position 103

4:3 Screen Size 104

PC Screen Adjustment 104

Resolution Select 105

Auto Adjustment 105

Rotation 106

Aspect Ratio 106

Advanced Settings 107

Dynamic Contrast 108

Black Tone 108

Flesh Tone 108

RGB Only Mode 108

Colour Space 108

White Balance 109

10p White Balance 109

Gamma 109

Expert Pattern 110

Motion Lighting 110

Picture Options 111

Colour Tone 112

Colour Temp. 112

Digital Noise Filter 112

MPEG Noise Filter 112

HDMI Black Level 113

Film Mode 113

Motion Plus 113

Dynamic Backlight 114

Reset Picture 114

Sound Adjustment

Sound Mode 115

Sound Effect 116

Speaker Settings 117

Reset Sound 118

Network

Network Settings 119

Connecting to a Wired Network 119

Wired Network Settings 121

Connecting to a Wireless Network 123

Wireless Network Setting 124

WPS(PBC) 127

Network Status 128

Wi-Fi Direct 129

Soft AP 130

AllShare Settings 131

Device Name 131

System

Multi Control 132

Configuring settings for Multi Control 132

Time 133

Clock Set 133

Sleep Timer 133

On Timer 134

Off Timer 135

Holiday Management 135

Menu Language 136

Rotate menu 137

Table of contents

Eco Solution 138

Energy Saving 138

Eco Sensor 138

No Signal Power Off 138

Auto Power Off 138

Security 139

Safety Lock 139

Button Lock 139

Change PIN 139

PIP 140

Auto Protection Time 141

Screen Burn Protection 142

Pixel Shift 142

Timer 143

Immediate display 144

Side Grey 144

Ticker 145

Video Wall 146

Format 146

Horizontal 146

Vertical 147

Screen Position 147

Source AutoSwitch Settings 148

Source AutoSwitch 148

Primary Source Recovery 148

Primary Source 148

Secondary Source 148

General 149

Max. Power Saving 149

Game Mode 149

BD Wise 149

Menu Transparency 149

Sound Feedback 150

Auto Power 150

Standby Control 150

Lamp Schedule 151

OSD Display 151

Power On Adjustment 151

Temperature Control 151

Anynet+ (HDMI-CEC) 152

Auto Turn Off 153

Troubleshooting for Anynet+ 154

DivX® Video On Demand 156

Play Mode 156

Magic Clone 157

Reset System 157

Reset All 158

PC module power 158

Synced power-on 158

Synced power-off 158

Support

Software Update 159

By USB 159

Contact Samsung 160

Contents Home 161

MagicInfo Lite 161

MagicInfo Premium S 161

MagicInfo Videowall S 161

AllShare Play 162

Source 162

AllShare Play

What is AllShare Play? 163

Read the following before using AllShare Play with

a USB device 163

Using a USB device 165

Connecting to a PC over a network 166

Using the AllShare Play features 167

Using the Basic AllShare Play Features 168

Sorting the file lists 168

Playing Selected Files 169

Copying Files 169

Creating a Playlist 169

My list 170

My list options 170

Videos 171

Table of contents

Playing a Video 171

Photos 172

Viewing a Photo (or Slide Show) 172

Music 173

Playing Music 173

Videos / Photos / Music Play Option menu 174

Supported Subtitle and AllShare Play file

formats 176

Subtitle 176

Supported image resolutions 176

Supported music file formats 177

Supported Video Formats 177

MagicInfo Lite

File Formats Compatible with MagicInfo Lite

player 179

Read before using MagicInfo Lite player 179

Approving a connected device from the

server 184

MagicInfo Lite 186

MagicInfo Lite player 186

Local Schedule Manager 189

Content manager 196

Settings 198

When Content is Running 200

MagicInfo Premium S

File Formats Compatible with MagicInfo

Premium S Player 202

Read before using MagicInfo Premium S Player 202

Approving a connected device from the

server 208

MagicInfo Premium S 210

MagicInfo Premium S Player 210

Local Schedule Manager 213

Template Manager 220

Content manager 223

Settings 225

When Content is Running 227

MagicInfo Videowall S

File Formats Compatible with MagicInfo

Videowall S Player 229

Read before using MagicInfo Videowall S Player 229

MagicInfo Videowall S 232

Settings 232

When Content is Running 233

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Centre 234

Testing the Product 234

Checking the Resolution and Frequency 234

Check the followings. 235

Q & A 245

Specifications

General 247

PowerSaver 250

Preset Timing Modes 251

Appendix

Contact SAMSUNG WORLD WIDE 253

Responsibility for the Pay Service

(Cost to Customers) 262

Not a product defect 262

A Product damage caused by customer's fault 262

Others 262

WEEE 263

Correct Disposal of This Product (Waste Electrical &

Electronic Equipment) 263

Correct disposal of batteries in this product 263

Optimum Picture Quality and Afterimage Burn-

in Prevention 264

Optimum Picture Quality 264

Prevention of Afterimage Burn-in 265

Licence 267

Terminology 268

Table of contents

Before Using the Product

Chapter 01

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

•An administration fee may be charged if either

-(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

-(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

•The amount of such administration charge will be advised to you before any work or home visit is carried out.

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

•Do not use detergents that contain alcohol, solvent or

surface-active agents.

•Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

Due to the characteristics of high-glossy products, using a UV humidifier nearby may create

whitecoloured stains on the product.

―Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be

charged).

Electricity and Safety

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•An electric shock or fire may result.

Do not use multiple products with a single power socket.

•Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock

may result.

Insert the power plug all the way in so it is not loose.

•An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

•An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the

power cord under a heavy object.

•Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with

a dry cloth.

•A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not

use the power cord with other products.

•A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•The power cord must be disconnected to cut off power to the product

when an issue occurs.

•Note that the product is not completely powered down by using only

the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

•An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF

THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•A fire may result.

Have a technician install the wall-mount hanger.

•Installation by an unqualified person can result in an injury.

•Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or

closet.

•An increased internal temperature may cause a fire.

Install the product at least 10cm away from the wall to allow ventilation.

•An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•Children may suffocate.

Otros manuales para MD65C

Tabla de contenidos

Otros manuales de Monitor de Samsung

Samsung

Samsung SyncMaster 2043WM Manual de usuario

Samsung

Samsung S19D340HY Manual de usuario

Samsung

Samsung Samsung 900S Manual de usuario

Samsung

Samsung Odyssey G9 Series Manual de usuario

Samsung

Samsung RM49H Manual de usuario

Samsung

Samsung SyncMaster 570S Manual de usuario

Samsung

Samsung SyncMaster 960HD Manual de usuario

Samsung

Samsung 740N - SyncMaster - 17" LCD Monitor Guía de instalación

Samsung

Samsung SyncMaster 152 V Manual de usuario

Samsung

Samsung 400DX-2 - 40IN LCD 1920X1080 3000:1 VGA Dvi Manual de usuario

Samsung

Samsung SyncMaster 755DFG Manual de usuario

Samsung

Samsung SyncMaster 913BM Manual de usuario

Samsung

Samsung SyncMaster 753Ms Manual de usuario

Samsung

Samsung 790DF Manual de usuario

Samsung

Samsung SyncMaster B2330H Guía del usuario

Samsung

Samsung SyncMaster 172N Manual de usuario

Samsung

Samsung 400MXN - SyncMaster - 40" LCD Flat Panel... Manual de usuario

Samsung

Samsung 740BX - SyncMaster - 17" LCD Monitor Manual de usuario

Samsung

Samsung DM32D Manual de usuario

Samsung

Samsung SyncMaster 510N Manual de usuario

Samsung

Samsung SyncMaster 56B Manual de usuario

Samsung

Samsung SyncMaster 733N Manual de usuario

Samsung

Samsung SyncMaster S22A460B Manual de usuario

Samsung

Samsung 204B - SyncMaster - 20.1" LCD Monitor Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
