User Manual

Getting started

3 About this manual

7 Layout

12 Turning the computer on

and off

14 Unlocking the screen

14 Windows

Basics

17 Touch screen (optional)

22 Keyboard

24 Touchpad

27 Memory card

30 External display

32 Wireless LAN

34 Using the security slot

Applications

35 Using applications

36 Samsung Settings

37 Samsung Update

38 Online Support (S Service)

39 Samsung PC Help

(Self-help application)

Settings & Upgrade

40 LCD brightness

42 Volume

43 BIOS (Setup utility)

49 Battery

Troubleshooting

52 Samsung Recovery

58 Windows recovery

function

58 Q&A

Appendix

62 Product specifications

63 Ergonomic tips

67 Powering your device

69 Safety precautions

82 Important safety

information

85 Replacement parts and

accessories

88 Regulatory compliance

statements

107 WEEE symbol information

109 Samsung package Take-

Back program

Table of contents

Getting started

About this manual

•

This user manual is specially designed to detail the computer’s

functions and features.

•

The user manual supplied with the computer may vary

depending on the model.

•

Please read this manual before using the computer to ensure

safe and proper use.

•

Optional accessories, some devices, and software referred to

in this manual may not be provided or may not be subject to

upgrades. Note that the computer environment referred in

the user manual may not be the same as your environment.

•

Descriptions are based on the computer’s default settings

and the Windows 10 operating system. Available features and

additional services may vary depending on the computer or

operating system.

•

This user manual describes procedures for using the

touchpad, mouse and touch screen. Instructions for using the

touch screen are for models with the touch screen feature.

•

Images and screenshots are those of the representative model

of the series and may differ in appearance from the actual

product.

•

Content may differ from the final product and is subject to

change without prior notice. For the latest version of the

manual, refer to the Samsung website, www.samsung.com.

Getting started

This manual is protected under international copyright laws.

No part of this manual may be reproduced, distributed, translated,

or transmitted in any form or by any means, electronic or

mechanical, including photocopying, recording, or storing in any

information storage and retrieval system, without the prior written

permission of Samsung Electronics.

Computer specifications or the contents of this manual may

be changed without prior notice due to an upgrade of the

computer’s functions.

Instructional icons and expressions

Warning

: situations that could cause injury to yourself or

others

Caution

: situations that could cause damage to the

computer or other equipment

Note

: notes, usage tips, or additional information

The path you should follow to carry out an instruction. For

example,“select

Settings

→

Devices

”indicates that you

should select

Settings

and then

Devices

Select Click the mouse or tap the touchpad or touch screen.

Getting started

•

HDMI, the HDMI logo, and

the term High Definition

Multimedia Interface are

trademarks or registered

trademarks of HDMI Licensing

LLC.

•

All other trademarks and copyrights are the property of their

respective owners.

As an ENERGY STAR®Partner,

Samsung has determined that this

product meets the ENERGY STAR®

guidelines for energy efficiency.

•

The ENERGY STAR Program has reduced greenhouse gas

emissions and saved energy through voluntary labeling.

•

Power management setting of this product has been enabled

by default, and has various timing settings from 1 minute to

5 hours.

•

The product can wake with a button press on the chassis from

sleep mode.

Trademarks

•

Samsung and the Samsung logo are trademarks or registered

trademarks of Samsung Electronics.

•

Intel and Core are trademarks or registered trademarks of the

Intel Corporation.

•

Microsoft, MS-DOS, and Windows are trademarks or registered

trademarks of the Microsoft Corporation.

•

Bluetooth®is a registered trademark of Bluetooth SIG, Inc.

worldwide.

•

Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi

CERTIFIED™, and the Wi-Fi logo are registered trademarks of

the Wi-Fi Alliance.

Getting started

Product capacity representation

Storage capacity representation

The capacity of the storage device (HDD, SSD) of the manufacturer

is calculated assuming that 1 KB = 1,000 Bytes.

However, the operating system (Windows) calculates the storage

device capacity assuming that 1 KB = 1,024 Bytes. Therefore, the

available capacity of the HDD in Windows is smaller than the

actual capacity due to the difference in capacity calculation. For

example, for an 80 GB HDD, Windows calculates the capacity as

74.5 GB, (80x1,000x1,000x1,000) Bytes/(1,024x1,024x1,024) Bytes

= 74.505 GB.

In addition, the capacity representation in Windows may be even

smaller because some programs, such as Samsung Recovery, may

reside in a hidden area of the HDD.

Memory capacity representation

The available memory capacity in Windows is less than the actual

capacity of memory. This is because some memory is required for

regular system operations.

For example, for 1 GB (= 1,024 MB) memory installed, Windows

may report the capacity as 1,022 MB or less.

Data precautions

Samsung Electronics shall not be liable for any data loss. Please

take care to avoid losing any important data and back up your

data to prevent any such data loss.

Operating system and software support

If you change the product’s factory OS (Operating System) to

another OS or if you install software which is not supported by the

product’s original factory OS, you will not receive any technical

support, product exchange or refund, and a fee will be charged

when requesting a service.

Please use your computer with the original factory OS. If you

install an OS other than the factory OS, data may be deleted or the

computer may not start.

Recommended screen resolutions

It is recommended to set the resolution of your display based on

standard Windows settings.

If you set a high resolution, such as QHD+ (3200x1800), it may not

correctly display some applications.

Getting started

Front view

Layout

•

Features or options may differ depending on the model.

•

The items marked as optional may not be provided or

may be provided in different locations.

•

Since some space on the SSD is reserved for system

recovery and operations, the available space on the SSD

may be less than the actual capacity.

Getting started

Number/Name Description

Keyboard

•

Enter text or control computer

functions.

Operating status

LED

•

Shows the operating status of the

computer.

–

Red

: Charging

–

Green

: Fully charged

–

Blue

: Turned on

Illumination

sensor

•

The sensor detects the ambient

light.

•

If the ambient light level becomes

too low, the keyboard’s backlight

will automatically turn on.

•

If there is sufficient ambient

lighting, the keyboard’s backlight

will automatically turn off.

•

Do not block the sensor.

Number/Name Description

Camera indicator

light

•

This indicates the camera

operating status.

Camera

•

Using this camera, you can take

still pictures and record video.

LCD/Touch screen

(optional)

•

The screen’s images are displayed

here.

•

Recognizes touch interactions

(Only for touch screen models).

Power button

•

Turns the computer on and off.

Touchpad

•

Moves the cursor and selects

options.

•

Functions as a mouse.

Getting started

Number/Name Description

Memory card slot

•

Insert a memory card into the slot.

Microphone

•

You can use the built-in

microphone.

USB 3.0 port

•

Connect various peripheral

devices, such as a mouse, camera,

or keyboard.

Chargeable USB

3.0 port

•

The USB port can be used to

connect and charge a USB device.

Security slot

•

Secure the computer by

connecting an optional lock and

cable to it.

Right view

1 2 23 4 5

About the chargeable USB port

•

It may take longer to charge the battery when charging a USB

device.

•

The battery power level may be reduced when charging a USB

device while the computer is powered by the battery.

•

The charging status of the USB device is not displayed on the

computer.

•

To turn on the charging function while the computer is

turned off, open the

Samsung Settings

application and select

Convenience

→

USB charging in sleep mode

→

•

This feature may not be available on some USB devices.

Getting started

Number/Name Description

DC jack

•

This jack connects to the AC

adapter to supply power to the

computer.

HDMI port

•

Used to connect an HDMI cable

to an external device.

USB 3.0 port

•

Connect various peripheral

devices, such as a mouse, camera,

or keyboard.

USB-C™port

•

The USB-C™port can be used to

connect and charge a USB-C™

device.

Earpiece/Headset

jack

•

Connect an earpiece or a headset

to the computer to listen to

audio.

Left view

1 2 3 4 5

About the USB-C™port

•

It may take longer to charge the battery when charging a USB

device.

•

The battery power level may be reduced when charging a USB

device while the computer is powered by the battery.

•

The charging status of the USB device is not displayed on the

computer.

•

This feature may not be available on some USB devices.

•

Charging speeds may be slower when the computer’s battery

is low or the AC adapter is not connected.

•

USB devices cannot be charged when the computer is off.

Tabla de contenidos

Otros manuales de Computadora portátil de Samsung

Samsung

Samsung Chromebook Plus Manual de usuario

Samsung

Samsung NP-RV518E Manual de usuario

Samsung

Samsung R517 Manual de usuario

Samsung

Samsung NP-Q1 User Manual (Vista) Manual de funcionamiento

Samsung

Samsung X15Plus Manual de usuario

Samsung

Samsung NP-P480-JA04US Manual de usuario

Samsung

Samsung NP900X3 Manual de usuario

Samsung

Samsung HABANA-C NT-R45 Series Manual de usuario

Samsung

Samsung R60 NP-R60FY series Manual de usuario

Samsung

Samsung ATIV Book2 270E5V Manual de usuario

Samsung

Samsung NP900X4DMS1US Manual de usuario

Samsung

Samsung NP940X3M Manual de usuario

Samsung

Samsung Galaxy Book3 360 Manual de usuario

Samsung

Samsung NP-M50 Manual de usuario

Samsung

Samsung NP930MBE-K01US Manual de usuario

Samsung

Samsung NX30 Manual de usuario

Samsung

Samsung X460 Manual de usuario

Samsung

Samsung NP-X22 Manual de usuario

Samsung

Samsung R410 Manual de usuario

Samsung

Samsung Galaxy Book Pro Manual de usuario

Samsung

Samsung SM-W767 Manual de usuario

Samsung

Samsung NP700Z5AH Manual de usuario

Samsung

Samsung OSLO R70 Series Manual de usuario

Samsung

Samsung NM30 Manual de usuario

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
