User Manual
HM7100
2
About this manual
This user manual is specially designed to detail the device’s functions and features.
•
Please read this manual before using the device to ensure safe and proper use.
•
Images may differ in appearance from the actual product.
•
Content may differ from the final product and is subject to change without prior notice.
For the latest version of the manual, refer to the Samsung website,
www.samsung.com
.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
Copyright
Copyright © 2013 Samsung Electronics
This user manual is protected under international copyright laws.
No part of this user manual may be reproduced, distributed, translated, or transmitted in
any form or by any means, electronic or mechanical, including photocopying, recording, or
storing in any information storage and retrieval system, without the prior written permission
of Samsung Electronics.
Trademarks
•
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.
•
Bluetooth®is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
All other trademarks and copyrights are the property of their respective owners.
3
Table of Contents
Getting started
4 Headset layout
4 Buttons
5 Package contents
5 Charging the headset
9 Turning the headset on and off
9 Turning the indicator light on and off
10 Wearing the headset
Using the headset
11 About Bluetooth
12 Optimal usage conditions
12 Pairing and connecting the headset
14 Connecting to multiple devices
15 Reconnecting and Disconnecting
16 Call functions
18 Using voice prompts
19 Resetting the headset
Appendix
20 Specifications
21 Frequently asked questions
22 Warranty and parts replacement
4
Getting started
Headset layout
Talk button
Volume button
Secondary microphone
Charging jack
Primary microphone
Indicator light
Earpiece
Power switch
Buttons
Button Function
Power
switch
•
Slide to turn the headset on or off.
Talk
•
Press and hold for 3 seconds to enter Pairing mode.
•
Press to answer or end a call.
•
Press and hold to reject an incoming call.
•
Press and hold to put a call on hold.
•
Press and hold to switch between calls.
Volume
•
Press to adjust the volume.
•
Press and hold to turn the microphone on or off during a call.
Getting started
5
Package contents
Check the product box for the following items:
•
Headset
•
Charger
•
Portable charger
•
Ear tips
•
Quick start guide
The items supplied with the headset and any available accessories may vary
depending on the region.
Charging the headset
Charge the headset before using it for the first time or when the headset has been unused for
an extended period.
Use the Portable charger to charge the headset. You can charge the headset once with the
fully charged Portable charger.
Use only Samsung-approved chargers. Unapproved chargers can cause the battery to
explode or damage the headset.
When the battery level is low, the indicator light flashes red and the headset beeps.
If the headset turns off during a call, the call is automatically transferred to the
connected mobile device.
Getting started
6
Charging the Portable charger
Plug the small end of the charger into the charging socket on the Portable charger, and plug
the large end of the charger into an electric socket.
Charging time Approximately 2 hours
Indicator light colour
Red : Charging in progress
Blue : Charging complete
Connecting the charger improperly may cause serious damage to the Portable
charger. Any damage caused by misuse is not covered by the warranty.
•
Repeatedly charging and discharging of the headset over time cause the battery
performance to diminish. This is normal for all rechargeable batteries.
•
If the Portable charger is not charging properly, take the Portable charger and the
charger to a Samsung Service Centre.
•
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The device should remain close to the electric socket
while charging.
After fully charging, disconnect the Portable charger from the charger. First unplug the
charger from the Portable charger, and then unplug it from the electric socket.
Getting started
7
Charging the headset
1 Open the Portable charger and attach the headset.
Insert the headset into the Portable charger, until the earpiece is firmly set in place and
the earpiece is solidly braced by the charger frame. If the headset is not fixed to the
Portable charger, it might not charge properly or might fall off when the Portable charger
is opened.
Getting started
8
2 Turn on the Portable charger by sliding the Power switch on, and then close it.
You can charge the headset and the Portable charger at the same time. With the
headset attached to the Portable charger, connect the charger to the Portable
charger and turn it on.
3 When the headset is fully charged, turn the Portable charger off by sliding the Power
switch off.
You can check the charging status with the headset’s indicator light colour. The headset’s
indicator light colour is visible through the Portable charger as image below.
Charging time Approximately 2 hours
Indicator light colour
Red : Charging in progress
Blue : Charging complete
Getting started
9
Checking the battery level
Press and hold the Volume down button and the Talk button at the same time to check the
battery level. The indicator light flashes five times in one of the following colours, depending
on the battery level:
Colour Battery level
Blue Above 80%
Violet 80-20%
Red Below 20%
Turning the headset on and off
When turning on the headset for the first time, it automatically enters Pairing mode for
approximately 3 minutes.
Slide the Power switch on to turn on the headset. The indicator light flashes blue four times.
Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.
To turn off the headset, slide the Power switch off. The indicator light flashes blue and red
then turns off.
Turning the indicator light on and off
The indicator light shows the current status of the headset. If the light becomes annoying at
night, you can turn it off.
Press and hold both Volume buttons at the same time to turn the indicator light on and off.
•
The indicator light cannot be turned off in Pairing mode.
•
The indicator light is always activated when the headset is turned on or off, when a
call is received, when in Pairing mode, and when the battery level is low.
Getting started
10
Wearing the headset
Wear the headset as the image below.
Use one of the provided ear tips that fit your ear. Attach the back of the ear tip to the front of
the earpiece, with the gray ring pointed in. Rotate the ear tip left or right slightly depending
on which ear the headset will be worn on.
