Samsung AWEP570PBECSTA Manual de usuario
World Wide Web
http://www.samsungmobileusa.com
Printed in Korea
Code No.: GH68-28506A
NA. 03/2010. Rev. 1.0
English...................................................................................1
Español................................................................................21
English
1
Contents
Getting started
Your headset overview ......................................................................... 3
Button functions.................................................................................... 4
Charging the headset ........................................................................... 4
Wearing the headset ............................................................................ 8
Using your headset
Turning the headset on or off................................................................ 9
Pairing and connecting the headset ................................................... 10
Using call functions............................................................................. 12
Appendix
Frequently asked questions................................................................ 14
Certication and Safety approvals...................................................... 16
UL certied travel adapter .................................................................. 17
Warranty and parts replacement ........................................................ 18
Specications ..................................................................................... 19
English
2
Take the time to read through this user manual before using WEP570 Bluetooth
Headset.
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc. worldwide—
Bluetooth QD ID: B015914
More information about Bluetooth is available at www.bluetooth.com.
Safety precautions
Never disassemble or modify your headset for any reason. Doing this may
cause the headset to malfunction or become combustible. Bring the headset to
an authorized service center to repair it or replace the battery.
When using your headset while driving, follow local regulations in the country or
region you are in.
Avoid storage at high temperatures (above 50 °C/122 °F), such as in a hot
vehicle or in direct sunlight, as this can damage performance and reduce
battery life.
Do not expose the headset or any of its supplied parts to rain or other liquids.
At very high volumes, prolonged listening to the headset can damage your hearing.
•
•
•
•
English
3
Getting started
This section explains the proper use of your Bluetooth headset.
Your headset overview
Power switch
Volume button
Indicator light
Ear hook
Charging contact
Talk button
Charger jack
Earpiece
Microphone
Make sure you have the following items with your headset:
Travel adapter, Car cradle, User manual, Earpiece cover, Ear hook.
The items supplied with your headset may vary depending on your region.
4
Button functions
Button Function
Power Slide the switch to turn the headset on or off.
Talk
Press to make or answer a call.
Press to end a call.
Press and hold to enter Pairing mode.
•
•
•
Volume Press to adjust the volume.
During a call, press and hold to mute the microphone.
•
•
Charging the headset
This headset has a rechargeable internal battery which is non-removable. Ensure
that you fully charge the battery before using the headset for the rst time.
English
5
The battery will gradually wear out while charging or discharging because it is a
consumable part.
The headset is not able to operate while charging. Try connecting after charging is
completed.
When charging the headset in very hot temperatures, the red indicator light ashes
and charging will stop. This is a normal event to protect the headset from damage.
Unplug the travel adapter from the headset. You can charge the headset normally
below 50°C/122°F (±5°C/9°F)
•
•
•
Charging the headset using the travel adapter
1Plug the small end of the travel adapter into the charger jack.
6
2Plug the large end of the travel adapter into a power outlet.
During charging, the indicator light will turn red. If charging does not begin,
unplug the travel adapter and plug it in again.
3 When the headset is fully charged, the indicator light changes to blue. Unplug
the travel adapter from the power outlet and the headset.
Use only a Samsung-approved travel adapter. Unauthorized travel adapters may
cause an explosion or damage to the headset.
Charging the headset using the car cradle
1Plug the headset into the car cradle.
Make sure the direction of the headset is as shown in the gure when plugging
the headset into the cradle. If inserted in the incorrect direction, your headset
will not be charged and may be damaged.
To the car cigarette
lighter socket
English
7
2Plug the car cradle’s cigar jack into your car’s cigarette lighter socket.
During charging, the indicator light will turn red. If charging does not begin,
unplug the car cradle and the headset and plug them in again.
3 When the headset is fully charged, the indicator light changes to blue. Unplug the
car cradle from the lighter socket and unplug the headset from the car cradle.
You can also charge other devices using the car cradle. Connect the device to the
USB port on the car cradle with a USB cable.
If you connect a device that does not comply with the USB standard, charging may
not work properly.
•
•
Checking the battery level
At the same time, press and hold the Volume down button and the Talk button.
Depending on the battery level, the indicator light ashes 5 times in one of the
following colors:
Battery level Indicator light color
Above 80% Blue
80 ~ 20% Violet
Below 20% Red
