Samsung DW80M2020US/AA Manual de usuario

 

SERVICE Manual



  

  

 

  

  

 

 

 

 

 

 

 

 

DW80M2020US







1-1. SafetyInstructionsforServiceengineers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1



2-1. Features.......................................................................5

2-2. Specications...................................................................6

2-3. ComparingSpecicationswithExistingModels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2-4. OptionsSpecications............................................................8



3-1. ToolsforRemovalandReassembly..................................................9

3-2. StandardDisassemblyDrawings...................................................10



4-1. Preparation....................................................................28

4-2. ServiceInspectionMode.........................................................32



5-1. MAINPBA....................................................................43

5-2. MAINPBA....................................................................44

5-3. PCBDiagram..................................................................45

5-4. PCBDiagram..................................................................46



6-1. WIRINGDIAGRAM.............................................................47



7-1. ModelNumberNamingRules.....................................................48

7-2. Terminology..................................................................49





 

ሪMakesuretoobservethefollowinginstructionstooperatetheproductcorrectlyandsafelyandpreventpossible

accidentsandhazardswhileservicing.

ሪTwotypesofsafetysymbols,WarningandCaution,areusedinthesafetyinstructions.

 Hazardsorunsafepracticesthatmayresultinseverepersonalinjuryordeath.

 Hazardsorunsafepracticesthatmayresultinminorpersonalinjuryorpropertydamage.





ࣃ(Whenservicingelectricalpartsorharnesses)Makesuretodisconnectthecircuit

breakerorpowercablebeforeservicing.

➢Failuretodosomayresultinariskofelectricshock.

ࣃDonotallowconsumerstoconnectseveralappliancestoasinglepoweroutletatthe

sametime.

➢Thereisariskofreduetooverheating.

ࣃWhenremovingthepowercord,makesuretoholdthepowerplugwhenpullingtheplug

fromtheoutlet.

➢Failuretodosomaydamagetheplugandresultinreorelectricshock.

ࣃWhenthedishwasherisnotbeingused,makesuretodisconnectthecircuitbreakeror

powercablefromthepoweroutlet.

➢Failuretodosomayresultinelectricshockorreduetolightning.

ࣃDonotplaceorusegasoline,thinners,alcohol,orotherammableorexplosive

substancesnearthedishwasher.

➢Thereisariskofexplosionandrecausedfromelectricsparks.





ࣃCheckifthepowercableisdamaged,attened,cutorotherwisedegraded.

➢Iffaulty,replaceitimmediately.

Failuretodosomayresultinelectricshockorre.

ࣃCompletelyremoveanydustorforeignmaterialfromthehousing,wiringandconnection

parts.

➢Thiswillpreventariskofreduetoarcingandshortcircuitsinadvance.

ࣃWhenconnectingwires,makesuretoconnectthemusingthecorrectconnectorsand

checkthattheyarecompletelyconnected.

➢Iftapeisusedinsteadoftheconnectors,itmaycausereduetoarcing.

ࣃMakesuretodisconnectthePBApowerterminalsbeforestartingtheservice.

➢Failingtodosomayresultinahighvoltageelectricshock.

ࣃWhenreplacingtheheater,makesuretofastenthenutafterensuringthatitisinserted

intothebracket-heater.

➢Ifthenutisnotfastenedcorrectly,itcancauseawaterleak.



ࣃCheckforanywaterleakage.

➢Performatestusingthestandard(normal)cycleandcheckwhetherthereisany

waterleakagethroughtheoorsectionorthepipes.

ࣃDonotallowconsumerstorepairorserviceanypartofthedishwasherthemselves.

➢Thismayresultinpersonalinjuryandshortentheproductlife.

ࣃIfitseemsthatgroundingisneededduetowaterormoisture,makesuretorun

groundingwires.

➢Failuretodosomayresultinelectricshockduetoelectricleakage.







ࣃDonotsprinklewaterontothedishwasherdirectlywhencleaningit.

➢Thismayresultinelectricshockorre,andmayshortentheproductlife.

ࣃDonotplaceanycontainerswithwateronthedishwasher.

➢Ifthewaterisspilled,itmayresultinelectricshockorre.

Thiswillalsoshortentheproductlife.

ࣃDonotinstallthedishwasherinalocationexposedtosnoworrain.

➢Thismayresultinelectricshockorre,andshortentheproductlife.

ࣃDonotpressacontrolbuttonusingasharptoolorobject.

➢Thismayresultinelectricshockordamagetotheproduct.



ࣃWhenconnectingawiringharness,makesuretosealitcompletelysonoliquidcanenter.

➢Makesurethattheconnectionsaresecuringbyslightlypullingonthem.

ࣃCheckifthereisanyevidencethatliquidhasenteredelectriccomponentsor

connections.

➢Ifanyliquidhasenteredintoapart,replaceitorcompletelyremoveanyremaining

moisturefromit.

ࣃIfyouneedtoplacethedishwasheronitsbackforservicingpurposes,placeasupport(s)

ontheoorandlayitdowncarefullysothebackisontheoor.

➢Donotlayitdownonitsfrontorside.Thismayresultinscratchestothesurfaceor

damagetotheparts.





ࣃChecktheassembledstatusoftheparts.

➢Theymustbethesameasbeforeservicing.

ࣃCheckwhethertheproductislevelwiththeoorandsecuredtothecabinetandunder

thecounter.

➢Vibrationscanshortenthelifeoftheproduct.



 

 

  

Extralargecapacity        

Thespacehasbeenmaximizedtoaccommodate14   

Increasedconvenience

Thesmartautocycledeterminesthelevelofsoilonthedishesandinitiates

theoptimalcycleforcleaning.

Usethisfeaturetosavewater,energy,andtime.

 

Elegantdesignwithdigitaltouch

sensors

Digitaltouchsensorsareusedinthecontrolpanelformoresimpleoperation,

withatouchofelegance.

place-setting dish.



 





Powersupply 120V,60HzAConly

Waterpressure 20~120psi(140~830kPa)

Washmethod Rotatingnozzlespraytype

Drymethod

Power Heater:840 W 

WashMotor:50  W

Waterconsumption 2.8-6gal(10.8-22.5ℓ), NormalCycle



ㆍCapacity:14placesettings.

ㆍControlpaneldesign.

-Top control type + Touchoperation.

ㆍDimension(WxDxH):233/4x245/8x333/4in(604x625x856mm)



ㆍFlexibleStyle:InclinedRackSystem,HeightadjustableUpperBasket(manual).

ㆍUpgradedKitchen:Pleasantkitchenenvironment,Simple&Moderndesign.

ㆍSmartControl:SoilsensingProgramming   

(Excluding Handle)

858

Open heated dry



The floater is an important component for dishwasher operation.

Please do not tamper with floater.

Accessory parts -User/Installation manual,Installation Kit.

Specification

Brand Samsung Whirlpool Frigidaire GE

Model No. DW3000MM

(DW80M2020US) WDF520PADM FFID2423RS GDF520PSJSS


Design

CMF / Material STS STS STS STS

Control Fully Integrated, Top

control, Touch control Front Control Fully Integrated, Top

control Front Control

Handle Design Bar Pocket Bar Pocket

Feature

P/S14141215

Cleaning Rotary Rotary Rotary Rotary

Drying Vent, Open Heated dry Vent, Open Heated dry Open Heated dry Vent, Open Heated dry

Cycles4444

Options

(Delay start, Sanitize,

Hi-Temp Wash)

(Delay start, Heated dry,

Hi-Temp Wash)

(Delay start, Heated dry,

Hi-Temp Wash)

(Delay start, Heated dry,

Steam cleaning)

Racking system 2 PP Rack 2 Vinyl Rack 2 Nylon Rack 2 Rack

Filter/Disposer Filter Filter Filter Filter

Noise Level 55dB 55dB 55dB 54dB

Leak Protection Available Not Available Not Available Not Available

Energy Energy Star (249KWh) Energy Star (260KWh) 286kWh Energy Star (270KWh)

Features and Specications _ 7

2-3. COMPARING SPECIFICATIONS WITH ExISTING MODELS



 

    

▲

Bracketinstall

Fortopmount

ForKickplate

▼

▲

Assy-InstallKit:

2Bracket-install

2screwsfortopmounting

   

2screwsforkickplate

Provided

Withthe

Dishwasher

UserManual 1

InstallGuide 1

90°Elbow(3/8”) - 1

Sold

separately

WaterSupplyLine

(FlexibleSTSsupplylineis

recommend)

- 1

AirGap - 1

RubberConnector -1

StrainRelief -1



Bracket

For

▲

Cable 

tie 

Fordrain hose1

1clamp for drainhose1&2

1cable tie  

drain hose1
