Samsung DW60M6050 Series Instrucciones de montaje

DISHWASHER

REPAIR Guide

DISHWASHER

BASIC MODEL : DW60M6050 series

DW60M6040 series

MODEL NAME : DW60R7070 Series

DW60R7050 Series

DW60R7040 Series

MODEL CODE : DW60R7070BB DW6KR7071BB

DW60R7070US DW60R7070UW

DW60R7070UG DW60R7050BB

DW6KR7051BB DW60R7050SS

DW6KR7051SS DW60R7050SG

DW60R7050US DW6BR7051US

DW60R7050FS DW60R7050FW

DW60R7040BB DW6KR7041BB

DW60R7040US DW60R7040UW

DW60R7040FS DW60R7040FW

DW6*R70**U* DW6*R70**F*DW6*R70**BB DW6*R70**S*

* For End User.

IMPORTANT SAFETY NOTICE

Following the repair by a non-authorized service provider self-repair or

non-professional repair of the product Samsung is not liable for any

damage to the product any injury or any other product safety issue caused

by any attempt to repair the product which does not carefully follow these

repair and maintenance instructions. Any damage to the product caused by

an attempt to repair the product by any person other than a Samsung

certified service provider will not be covered by the warranty.

This service guide may not be reproduced in whole or

as a part in any form whatsoever without the written permission of

the SAMSUNG ELECTRONICS Company.

WARNING

Note

1. You can check where to buy replacement parts at http://samsung.com

2. Visit the part purchase site and enter the model code of your product to check the parts available

for purchase. The model code is labelled on the edge of the tub. When you open the dishwasher’s

door, you can check the model code and version on the barcode label at the left side of the tub.

3. For replacement parts make sure the part name matches that of the illustration in this manual.

- User-serviceable parts are limited to door hinge and seals other seals spray arms drain lters

interior racks and plastic peripherals such as baskets and lids.

Caution

1. The part name listed on the site may differ from that in this manual. Please make sure you choose

the right part name.

2. Be sure to wear safety gloves while making repairs.

3. Must working more than 2 people to handling heavy weight.

Tools For Removal And Reassembly _ 3

1. TOOLS FOR REMOVAL AND REASSEMBLY

Tool image

No. Tool Type Remarks

①Adjustable Wrench

②Open-end Wrench 1-7/16”

③Vice Pliers

④Others

(screwdriver, nipper, long nose pliers) Common tools for servicing

Screwdriver – Phillip, Flat, Torx T15

⑤Ear clamping tool In reassembling of the clamp-bend(ear clamp) using our

SVC part, this tool is needed.

NOTE :

Preparation for parts replacement

1. Take out the residual water inside the product. (Drain the water by operating the drain pump)

2. Close the water supply valve.

3. Turn off the power & disconnect power cable.

You must turn off the circuit breaker connected to the product.

4. Pull out the unit from the sink and lay it on the oor.

Be careful of the drain hose when pulling out the unit.

4 _ Standard Disassembly Drawings

2. STANDARD DISASSEMBLY DRAWINGS

2-1. PRECAUTION

Caution

Before servicing,

- Make sure to remove all items include baskets inside dishwasher.

- Drain the water in the dishwasher and disconnect the power supply.

- Lock the water faucet that connected with inlet hose.

- Uninstall the dishwasher from the furniture cabinet except simple work.

- Disconnect the Inlet & Drain hoses from the duct, if the hoses are too short to pull the dishwasher out of the furniture

cabinet enough.

- Make sure to remove any remaining water in the Sump and hoses by rag or vacuum.

→ There is a risk of water spill on the oor.

Standard Disassembly Drawings _ 5

2-2. GASKET BRAKE / CAP CASE BRAKE

- Gasket Brake : DD81-02726A / SVC-GASKET-BRAKE

- Cap Case Brake : DD81-02725A / SVC-CAP CASE BRAKE

Part Figure Description

GASKET

BRAKE / CAP

CASE BRAKE

[DISASSEMBLY]

1. Remove 3 screws that connect left SIDE PANEL to

front side of dishwasher.

■ Type A: DD81-02693A / 2 pcs

■ Type B: DD81-02694A / 1 pc

Warning

Be sure to remove the power plug before servicing.

NOTE :

In case of Free Standing models, there’re no

screws of type B.

2. Remove 3 screws at the back side of dishwasher.

■ Type C: DD81-02692A / 1 pc

■ Type B: DD81-02694A / 2 pcs

NOTE :

In case of Free Standing models, take off the

COVER TOP by removing 2 screws of type A.

After removing screws, pull the COVER TOP

backward rst, and take it off upward.

Guide Tub Top

3. Remove 1 screw at the left side of GUIDE TUB

TOP.

■ Screw: DD81-02694A / 1 pc

6 _ Standard Disassembly Drawings

Part Figure Description

GASKET

BRAKE / CAP

CASE BRAKE

4. Take off the left SIDE PANEL.

Warning

Do not this work without safety gloves. It can cause

injury from sharp edge.

5. Take off the CAP CASE BRAKE by rotating to

counter-clockwise direction with long-nose pliers.

Caution

It can be broken easily when you use iron part of

the pliers. Take off the cap using handle part to

prevent damage.

Cap Case brake Gasket brake

6. Remove the GASKET BRAKE from the CASE

BRAKE assembly.

[ASSEMBLY]

1. Put the GASKET BRAKE on the CASE BRAKE,

and fasten the CAP CASE BRAKE by rotating to

clockwise direction with long-nose pliers.

Caution

It can be broken easily when you use iron part of

the pliers. Take off the cap using handle part to

prevent damage.

Caution

Pay attention to assemble the seal correctly.

It can cause the water leakage when it’s

assembled wrong.

2. Assemble the left SIDE PANEL with the screws.

Caution

Fasten the screws that was assembled to origin

location. Don’t assemble to other locations.

Warning

Do not this work without safety gloves. It can cause

injury from sharp edge.

Standard Disassembly Drawings _ 7

2-3. COVER TOP

- Cover Top : DD81-02552C / SVC-COVER TOP (DW6*R70**FS)

DD81-02552D / SVC-COVER TOP (DW6*R70**FW)

Part Figure Description

COVER TOP

(Only for Free

standing models /

DW6*R70**F*)

[DISASSEMBLY]

1. Release 2 screws.

■ Screws: DD81-02692A / 2 pcs

Warning

Be sure to remove the power plug before servicing.

2. Pull the COVER TOP backward to release hooks,

and take it off upward.

Hook Of Cover Top

Guide Of Cover Top

Tub Frame

[ASSEMBLY]

1. Put the COVER TOP on the top of dishwasher, and

push it forward to assembly.

NOTE :

Pay attention to lock the hooks(COVER TOP) to

TUB FRAME.

2. Fasten 2 screws.

■ Screws: DD81-02692A / 2 pcs

8 _ Standard Disassembly Drawings

2-4. SIDE PANEL / GUIDE TUB TOP / COVER TUB REAR

- Side Panel : DD81-02880A, DD81-02881A / SVC-HOUSING-LEFT, RIGHT (DW6*R70**FS)

DD81-02880C, DD81-02881C / SVC-HOUSING-LEFT, RIGHT (DW6*R70**FW)

- Guide Tub Top : DD81-02733A / SVC-GUIDE TUB TOP

- Cover Tub Rear : DD81-02734A / SVC-COVER TUB REAR

Part Figure Description

SIDE PANEL/

GUIDE TUB TOP/

COVER TUB

REAR

(DW6*R70**F*)

[DISASSEMBLY]

1. Release 2 screws.

■ Screws: DD81-02692A / 2 pcs

Warning

Be sure to remove the power plug before servicing.

2. Pull the COVER TOP backward to release hooks,

and take it off upward.

Cover Tub Rear

Guide Tub Top

3. Release Screws.

■ Front side : Type A: DD81-02693A / 4 pcs

■ Rear side : Type B: DD81-02694A / 4 pcs

■ Top side : Type B: DD81-02694A / 2 pcs

Standard Disassembly Drawings _ 9

Part Figure Description

SIDE PANEL/

GUIDE TUB TOP/

COVER TUB

REAR

(DW6*R70**F*)

Not to get

stuck

Could be dented

Hook

4. Take the SIDE PANEL off a little, just enough not to

get stuck to TUB FRAME.

Warning

Do not this work without safety gloves. It can cause

injury from sharp edge.

Caution

Be careful not to be dented SIDE PANEL because

of hook.

Side Panel Left Side Panel Right

Guide Tub Top

Cover Tub Rear

5. Pull the SIDE PANEL off from the COVER PLINTH.

GUIDE TUB TOP and COVER TUB REAR are

disassembled together.

[ASSEMBLY]

1. Assemble the GUIDE TUB TOP and COVER TUB

REAR to back of dishwasher.

Caution

They are not xed without SIDE PANEL.

Recommend to work by 2 people.

10 _ Standard Disassembly Drawings

Part Figure Description

SIDE PANEL/

GUIDE TUB TOP/

COVER TUB

REAR

(DW6*R70**F*)

2. Put the hook of SIDE PANEL into the COVER

PLINTH.

Warning

Do not this work without safety gloves. It can cause

injury from sharp edge.

On The Tub

Frame On The Guide

Tub Top

Could be dented

Hook

3. Assemble the SIDE PANEL left & right to each side.

Caution

Be careful not to be dented SIDE PANEL because

of hook.

Front

Top

Rear

4. Make sure to t the SIDE PANEL correctly.
