Samsung UF-130DX Manual de usuario

Samsung Digital PresenterSamsung Digital Presenter

(UF-130DX/ST)(UF-130DX/ST)

HIGH RESOLUTION DIGITAL PRESENTER

RS-232C REFERENCE

HIGH RESOLUTION DIGITAL PRESENTER

RS-232C REFERENCE

Before attempting to operate this product, Please read the instructions carefully.

www.samsungpresenter.com

Before attempting to operate this product, Please read the instructions carefully.

www.samsungpresenter.com

RS232C Command Code (UF-130DX/ST)

- BaudRate: 9600bps

- Parity Bit: No Parity

- Stop Bit Length: 1-bit

- Character Length: 8-bit

- Start Code: 0xB0

- Stop Code: 0xBF

- Command Code: 4-byte

What the 2nd-Rx-data ("ACK data") is not 0x80

means that the system is doing other operation.

(Check up page 6)

With the command "Message-Status", you can

check up current status of the system and send

the user command. (AWC, etc)

UF-130DX/ST RS232C PC-side FlowChart

RS232C Command Code (UF-130DX/ST)

PC Transmit Data to MICOM PC Receive Data from MICOM

Command

1st 2nd 3rd 4th 1st 2nd 3rd 4th

Remark

AWC 0x01 0x00 0x05 0x00 0x01

“ACK data”

0x05 0x00

AF 0x02 0x00 0x05 0x00 0x02

“ACK data”

0x05 0x00

Lamp ON 0x00 0x05 0x00

“ACK data”

0x05 0x00

Lamp OFF

0x03

0x00 0x0A 0x00

0x03

“ACK data”

0x0A 0x00

Internal 0x00 0x05 0x00

“ACK data”

0x05 0x00

External

0x04

0x00 0x0A 0x00

0x04

“ACK data”

0x0A 0x00

Aperture ON 0x00 0x05 0x00

“ACK data”

0x05 0x00

Aperture OFF

0x09

0x00 0x0A 0x00

0x09

“ACK data”

0x0A 0x00

Power On 0x00 0x05 0x00

“ACK data”

0x05 0x00

Power OFF

0x0F

0x00 0x0A 0x00

0x0F

“ACK data”

0x0A 0x00

Rotate OFF 0x00 0x05 0x00

“ACK data”

0x05 0x00

Rotate 90° 0x00 0x08 0x00

“ACK data”

0x08 0x00

Rotate 180° 0x00 0x0A 0x00

“ACK data”

0x0A 0x00

Rotate 270°

0x11

0x00 0x0D 0x00

0x11

“ACK data”

0x0D 0x00

RS232C Command Code (UF-130DX/ST)

PC Transmit Data to MICOM PC Receive Data from MICOM

Command

1st 2nd 3rd 4th 1st 2nd 3rd 4th

Remark

Freeze ON 0x00 0x05 0x00

“ACK data”

0x05 0x00

Freeze OFF

0x12

0x00 0x0A 0x00

0x12

“ACK data”

0x0A 0x00

Preset Save 0x17 0x00 Number 0x00 0x17

“ACK data”

Number 0 x 00

Preset Exe 0x18 0x00 Number 0x00 0x18

“ACK data”

Number 0 x 00

Range : “1~4”

Iris Up 0x00 0x05 0x00

“ACK data”

0x05 0x00

Iris Down

0x21

0x00 0x0A 0x00

0x21

“ACK data”

0x0A 0x00

Red Up 0x00 0x05 0x00

“ACK data”

0x05 0x00

Red Down

0x23

0x00 0x0A 0x00

0x23

“ACK data”

0x0A 0x00

Blue Up 0x00 0x05 0x00

“ACK data”

0x05 0x00

Blue Down

0x24

0x00 0x0A 0x00

0x24

“ACK data”

0x0A 0x00

Overlay(PIP) 0x48 0x00 0x05 0x00 0x48

“ACK data”

0x05 0x00

<Note1> Transmitting number "9" in image divide command, the system executes 3X3 multi-screen mode.

<Note 2> Overlay(PIP) function is for UF-130DX only.

RS232C Command Code (UF-130DX/ST)

PC Transmit Data to MICOM PC Receive Data from MICOM

Command

1st 2nd 3rd 4th 1st 2nd 3rd 4th

Remark

Focus Far 0x00 0x05 0x00

“ACK data”

0x05 0x00

Focus Near

0x25

0x00 0x0A 0x00

0x25

“ACK data”

0x0A 0x00

Zoom Tele 0x00 0x05 0x00

“ACK data”

0x05 0x00

Zoom Wide

0x26

0x00 0x0A 0x00

0x26

“ACK data”

0x0A 0x00

Range : “1~120”

Iris Target 0x41 0x00 0x00

“data”

0x41

“ACK data”

0x00

“data”

Range : “1~120”

Red Target 0x43 0x00 0x00

“data”

0x43

“ACK data”

0x00

“data”

Range : “1~200”

Blue Target 0x44 0x00 0x00

“data”

0x44

“ACK data”

0x00

“data”

Range : “1~200”

Focus Target 0x45 0x00

“MSB data” “LSB data”

0x45

“ACK data” “MSB data” “LSB data”

(1)

Range : “0~2225”

Zoom Target 0x46 0x00

“MSB data” “LSB data”

0x46

“ACK data” “MSB data” “LSB data”

Range : “0~1916”

0x00

“zoom data” “zoom LSB” “ACK data” “zoom data” “zoom LSB”

Focus/Zoom

Concurrent Target

0x47

“focus data” “focus LSB”

0x47

“ACK data” “focus data” “focus LSB”

(1)

Focus : “0~2225”

Zoom : “0~1916”

(1)Drive Stop 0x2F 0x00 0x05 0x00 0x2D

“ACK data”

0x05 0x00

<Note1> Depending of the zoom amount, the range of focus data will be changed. You can figure it out

to see page 6. ("Focus-Status[Max]", "Focus-Status[Min]")

<Note2> Above 10 Command (Iris up/down ,Red up/down, Blue up/down, Focus far/near, Zoom

tele/wide) will go to all the way once you execute it.

"Drive Stop" can stop those command in certain point that you want.

RS232C Command Code (UF-130DX/ST)

PC Transmit Data to MICOM PC Receive Data from MICOM

Command

1st 2nd 3rd 4th 1st 2nd 3rd 4th

Remark

Set-Status(Normal) 0x61 0x00 0x00 0x00 0x61

“ACK data”

Status(MSB) Status(LSB)

Bit definition of Status

represents Page 7,8

Iris-Status 0x65 0x00 0x00 0x00 0x65

“ACK data”

0x00 Status

Range : “1~120”

Red-Status 0x67 0x00 0x00 0x00 0x67

“ACK data”

0x00 Status

Range : “1~200”

Blue-Status 0x68 0x00 0x00 0x00 0x68

“ACK data”

0x00 Status

Range : “1~200”

Zoom-Status 0x69 0x00 0x00 0x00 0x69

“ACK data”

Status(MSB) Status(LSB)

Range : “0~1916”

Focus-Status 0x6A 0x00 0x00 0x00 0x6A

“ACK data”

Status(MSB) Status(LSB)

Range : “0~2225”

(1)Focus-Status[Max] 0x00 0x05 0x00

“ACK data”

Status(MSB) Status(LSB)

Range : “648~2225”

(1)Focus-Status[Min]

0x6B

0x00 0x0A 0x00

0x6B

“ACK data”

Status(MSB) Status(LSB)

Range : “0~1383”

<Note1> This command returns focus maximum/minimum data at current zoom position.

RS232C Command Code (UF-130DX/ST)

◎Bit Definition of “ACK data”

<Note1> 'Set is executing command by OS' bit is for UF-130DX only.

(0,0,0,0,1): Set is executing command by panel-key

(0,0,0,1,0): Set is executing command by remocon

(0,0,1,0,0): Set is executing command by RS232C

(0,1,0,0,0): Set is executing command by USB

(1,0,0,0,0): Set is executing command by OS

System Boot Completion ("0": Booting, "1": OK)

Acknowledgement Bit ("0": no-ACK, "1": ACK)

RS232C Command Code (UF-130DX/ST)

◎Status Bit Definition by Set-Status Command

- LSB 8bit

- MSB 8bit

<Note 1> Disable/Enable Control bit is for UF-130DX only.

(0,0): Image Rotate OFF (0,1): Image Rotate 90˚

(1,0): Image Rotate 180˚ (1,1): Image Rotate 270˚

(0): Aperture ON (1): Aperture OFF

(0): DX Model (1): ST Model

(0): Disable Control (1): Enable Control

(0): Image Freeze OFF (1): Image Freeze ON

Single or Dual-DVI output resolution

(0,1): SXGA (1,0): XGA (1,1): HD[1280x720p]

(0): Lamp OFF (1): Lamp ON

(0): Internal Input (1): External Input

(0): System Power OFF (1): System Power ON

(0,0): Single others: Dual-VGA output resolution

(0,1): SXGA (1,0): XGA (1,1): HD[1280x720p]

RS232C Command Code (UF-130DX/ST)

Memo

RS232C Command Code (UF-130DX/ST)

Memo
