Samsung SCC-B1331P Manual de usuario

ENG

DIGITAL COLOR CAMERA

user manual

SCC-B1331(P)

SCC-B1031P

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsungsecurity.com

ENG RUS

POL

CZE

TUR

2– DIGITAL COLOR CAMERA

Safety information

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER. NO USER SERVICEABLE PARTS

INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL..

This symbol indicates high voltage is present inside. It is dangerous to make any kind of

contact with any inside part of this product.

This symbol alerts you that important literature concerning operation and maintenance

has been included with this product.

WARNING

To prevent damage which may result in ﬁre or electric shock hazard, do not expose this appliance

to rain or moisture.

WARNING

Be sure to use only the standard adapter that is speciﬁed in the speciﬁcation sheet. Using any

other adapter could cause ﬁre, electrical shock, or damage to the product

Incorrectly connecting the power supply or replacing battery may cause explosion, ﬁre, electric

shock, or damage to the product.

Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause

abnormal heat generation or ﬁre.

Securely plug the power cord into the power receptacle. Insecure connection may cause ﬁre.

When installing the camera, fasten it securely and ﬁrmly. A falling camera may cause personal

injury.

Do not place conductive objects (e.g. screwdrivers, coins, metal things, etc.) or containers ﬁlled

with water on top of the camera. Doing so may cause personal injury due to ﬁre, electric shock,

or falling objects.

Do not install the unit in humid, dusty, or sooty locations. Doing so may cause ﬁre or electric

shock.

If any unusual smells or smoke come from the unit, stop using the product. In such case,

immediately disconnect the power source and contact the service center. Continued use in such

a condition may cause ﬁre or electric shock.

If this product fails to operate normally, contact the nearest service center. Never disassemble

or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized

modiﬁcations or attempted repair.)

•

CAUT

10.

English – 3

ENG

Safety information

d of

nce

uch

zed

When cleaning, do not spray water directly onto parts of the product. Doing so may cause ﬁre or

electric shock.

CAUTION

Do not drop objects on the product or apply strong shock to it. Keep away from a location

subject to excessive vibrationor magnetic interference.

Do not install in a location subject to high temperature (over 50°C), low temperature (below -

10°C), or high humidity. Doing so may cause ﬁre or electric shock.

If you want to relocate the already installed product, be sure to turn off the power and then move

or reinstall it.

Remove the power plug from the outlet when then there is a lightning. Neglecting to do so may

cause ﬁre or damage to the product.

Keep out of direct sunlight and heat radiation sources. It may cause ﬁre.

Install it in a place with good ventilation.

Avoid aiming the camera directly towards extremely bright objects such as sun, as this may

damage the CCD image sensor.

Apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids, such as

vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay readily operable at any time.

10.

4– DIGITAL COLOR CAMERA

Important Safety Instructions

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat registers, or other apparatus (including

ampliﬁers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong is provided for your safety. If the provided plug does not ﬁt into your outlet, consult

an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories speciﬁed by the manufacturer.

Use only with cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or

sold with the apparatus.

Unplug this apparatus when a card is used. Use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been

damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or

has been dropped.

10.

11.

12.

13.

14.

English – 5

ENG

Contents

Introduction

Features 6

PRODUCT & ACCESSORIES 7

Part Names and Functions 8

Installation

Connecting the Auto Iris Lens Connector 11

Mounting the lens 11

Connecting cables and checking operation 12

How to use OSD Menu

Using Icons in the Menu 13

Main Menu 13

Proﬁle 14

Camera Setup 16

Intelligence 21

Privacy zone Setup

Other Set 23

System Information 23

Language 23

Speciﬁcations

Speciﬁcations 25

wide

sult

have

y, or

6– DIGITAL COLOR CAMERA

Introduction

FEATURES

High Resolution

This camera has realized high resolution of 600 lines using the top-notch full digital image processing and

special algorithm technologies.

Intelligent Motion Detection & Tracking

This is an intelligent function that automatically detects a motion of an object. You can set a virtual fence so it

sounds an alert if an object passes / enters /exits the virtual fence or virtual area.

XDR (eXtended Dynamic Range)

Actively controls the gamma compensation in the way it operates the ambient luminance contrast in a

certain pixel unit to determine the optimal visibility.

High Sensitivity

It implements images of high sensitivity using the up-to-date SONY Super-HAD Progressive CCD.

Low Illumination

It uses the digital signal technologies such as low illumination and Day/Night functions that make your camera

identify objects even in the worst environment.

Superior Backlight Adjustment

When an object has a bright illumination or sunlight behind it, this camera automatically improves the

shaded object picture quality.

Digital Power Synchronization

The full digital Line Lock function directly adjusts the vertical camera synchronization to enhance the

operationability and reliability of this camera.

Output Signal Setting

You can set the following Video output signals: Image reversion (Horizontal, Vertical, or both), Privacy,

Horizontal/Vertical proﬁling, and digital zooming.

OSD(On Screen Display) Menu

OSD menu is provided to display the status of camera and to conﬁgure the functions interactively.

❖

•

❖

•

❖

•

❖

•

❖

•

❖

•

❖

•

❖

•

❖

•

PRO

P❖

•

Came

•

English – 7

ENG

Introduction

and

PRODUCT & ACCESSORIES

Product & Accessories❖

Accessories

•

Camera

Camera Holder(Mount) Auto Iris

Lens Connector

User’s Manual

Main Product

•

C Mount Adapter

POWER (SCC-B1031P)

8– DIGITAL COLOR CAMERA

Introduction

PART NAMES AND FUNCTIONS

Side View❖

Auto Iris Lens Connector

This groove is used for screwing the mount adapter, a part of the bracket where the camera will be installed.

Auto Iris Lens Control Cable

This cable transmits the power and signals from the camera for controlling the Auto Iris Lens.

Mount Adapter Fixing Grooves

These grooves are used when ﬁxing screws of the mount adapter connected to the bracket when installing

the camera on it.

•

Note :

When the camera lens becomes dirty, softly clean it with a lens tissue or a cloth soaked in pure ethanol.



–

Mount Adapter

Fixing Grooves

Camera Lens

Auto Iris Lens

Connector

Auto Iris Lens

Control Cable

R❖

English – 9

ENG

Introduction

alled.

ing

Rear Panel❖

<AC220V~240V(SCC-B1031P)>

10 – DIGITAL COLOR CAMERA

Introduction

nInput/Output Connector

This connector has input and output ports for

and alarm output signals.

No. Function Description

1 ALARM OUT

Alarm out port for motion detection. (Open collector type)

2 GND Grounding Port.

3 TRIGGER IN

Displays the current still image when it receives the Trigger signal.

(Normal Open Type)

4 SHUTTER (S0) This is a port for selecting an external high speed shutter mode.

If connected in LOW (0V), it will become ON inside.

5 SHUTTER (S1)

This is a port for selecting an external high speed shutter mode.

If connected in LOW (0V), it will become ON inside.

6 SHUTTER (S2)

This is a port for selecting an external high speed shutter mode.

If connected in LOW (0V), it will become ON inside.

7 5V OUT

Power supply port for RS-485 JIG. Use within typical DC +5V 100mA

oSETUP Switch

This switch is used to set the function or property. When this switch is pressed for at least 2 seconds, the

MAIN MENU appears.

(Left/Right)

: By pressing this switch left or right, you can move left or right on the menu or change the

displayed value.

(Up/Down) :

By pressing this switch up or down, you can move up or down on the menu.

: When you press this switch in the menu, the selected function is conﬁrmed. To enter a submenu, press

this button.

pPower Display LED

When the power is normally connected, the red LED lights.

qVideo OUT Port

This is connected to the Video Input Port of the monitor and it outputs the Video signals.

rGND

This is a grounding port.

sPower Connection Port

This is connected to the Power cable.

Conn

the A



–
