Samsung S630 - Digital Camera - Compact Manual de usuario

CONTENTS

ⅠⅠ. SPECIFICATION

1. CAMERA SPECIFICATION …………………………………………………………………………………… 4

2. SYSTEM REQUIREMENTS …………………………………………………………………………………… 7

3. LCD monitor indicator …………………………………………………………………………………………… 8

4. CONNECTION DIAGRAM …………………………………………………………………………………… 11

5. IDENTIFICATION OF FEATURES …………………………………………………………………………… 12

ⅡⅡ

..

EEXXPPLLOODDEEDD

VVIIEEWW

AANNDD

PPAARRTTSS

LLIISSTT

1. MAIN ASSEMBLY……………………………………………………………………………………………… 14

2. BODY ASSEMBLY …………………………………………………………………………………………… 16

3. BARREL ASSEMBLY ………………………………………………………………………………………… 20

4. BARREL ASSEMBLY ………………………………………………………………………………………… 24

5. FRONT COVER ASSEMBLY ………………………………………………………………………………… 26

6. MIDDLE COVER ASSEMBLY ………………………………………………………………………………… 28

7. BACK COVER ASSEMBLY …………………………………………………………………………………… 30

8. PACKING ITEM………………………………………………………………………………………………… 32

ⅢⅢ

. ADJUSTMENT

1. FIRMWARE …………………………………………………………………………………………………… 36

2. ADJUSTMENT CAUTION …………………………………………………………………………………… 47

ⅣⅣ. PATTERN DIAGRAM

1. PARTS ARRANGEMENT FOR EACH PCB ASS’Y

1) MAIN_TOP_S3-63

…………………………………………………………………………………………… 73

2) MAIN_BOTTOM_S3-63

………………………………………………………………………………………… 74

3) CCD_TOP_S3-63

……………………………………………………………………………………………… 75

4) CCD_BOTTOM_S3-63

………………………………………………………………………………………… 76

5) MAIN_BOTTOM_S3-73

………………………………………………………………………………………… 77

6) MAIN_BOTTOM_S3-73

………………………………………………………………………………………… 78

7) CCD_TOP_S3-73

……………………………………………………………………………………………… 79

8) CCD_BOTTOM_S3-73

………………………………………………………………………………………… 80

9) STROBO_TOP_S3-63/S3-73

…………………………………………………………………………………… 81

10) STROBO_BOTTOM_S3-63/S3-73

…………………………………………………………………………… 82

11) MODE_TOP_S3-63/S3-73

…………………………………………………………………………………… 83

12) MODE_BOTTOM_S3-63/S3-73

……………………………………………………………………………… 84

ⅤⅤ

..

CCIIRRCCUUIITT

DDIIAAGGRRAAMM

1) MAIN_S3-63

…………………………………………………………………………………………………… 85

2) MAIN_DDR_S3-63

……………………………………………………………………………………………… 86

3) MAIN_CCD_S3-63

……………………………………………………………………………………………… 87

4) MAIN_I/O LCD_S3-63

…………………………………………………………………………………………… 88

5) MAIN_KEY_S3-63

……………………………………………………………………………………………… 89

6) MAIN_LENS(MOTOR)_S3-63

…………………………………………………………………………………… 90

7) MAIN_POWER_S3-63

………………………………………………………………………………………… 91

8) MAIN_STROBO_S3-63

………………………………………………………………………………………… 92

9) MAIN_S3-73

…………………………………………………………………………………………………… 93

10) MAIN_DDR_S3-73

…………………………………………………………………………………………… 94

11) MAIN_CCD_S3-73

…………………………………………………………………………………………… 95

12) MAIN_I/O LCD_S3-73

………………………………………………………………………………………… 96

13) MAIN_KEY_S3-73

…………………………………………………………………………………………… 97

14) MAIN_LENS(MOTOR)_S3-73

………………………………………………………………………………… 98

15) MAIN_POWER_S3-73

………………………………………………………………………………………… 99

16) MAIN_STROBO_S3-73

……………………………………………………………………………………… 100

17) STROBO_S3-63/S3-73

……………………………………………………………………………………… 101

18) MODE_KEY_S3-63/S3-73

…………………………………………………………………………………… 102

ⅥⅥ..

SSEERRVVIICCEE

IINNFFOORRMMAATTIIOONN

……………………………………………………………………………………103

Image Sensor

- Type : 1/2.5" CCD

- Effective Pixel : ·S730-Approx. 7.2 Mega-pixel

·S630-Approx. 6.0 Mega-pixel

- Total Pixel : ·S730-Approx. 7.4 Mega-pixel

·S630-Approx. 6.1 Mega-pixel

Lens - Focal Length : SHD Lens f = 5.8 ~ 17.4mm (35mm film equivalent : 35~105mm)

- F No. : F2.8~F7.1 (wide), F4.9~F12.4 (Tele)

- Digital Zoom :·Still Image mode : 1.0X ~ 5.0X

·Play mode : S730: 1.0X ~ 12.0X (depends on image size)

S630: 1.0X ~ 11.0X (depends on image size)

LCD Monitor

- 2.5" color TFT LCD (S730:230K dots, S630:150K dots)

Focusing - Type : TTL auto focus

- Range

Shutter - Shutter Speed : 1 ~ 1/1,500 sec. (Manual : 8 ~ 1/1,500 sec.)

Exposure - Control : Program AE

- Metering : Multi, Spot

- Compensation : ±2EV(1/3EV steps)

- ISO Equivalent : S730-Auto, 80, 100, 200, 400, 800, 1000

S630-Auto, 80, 100, 200, 400

Flash - Modes : Auto, Auto & Red-eye reduction, Fill-in flash, Slow sync, Flash off

- Range : Wide : 0.2m ~ 3.0m

Tel e : 0.4m ~ 2.5m (ISO AUTO)

- Recharging Time : Approx. 5 sec.

Sharpness - Soft+, Soft, Normal, Vivid, Vivid+

Color Effect - Normal, B&W, Sepia, Red, Green, Blue, Negative, User Set

White Balance

- Auto, Daylight, Cloudy, Fluorescent_H, Fluorescent_L, Tungsten, Custom

Voice Recording

- Voice Recording (max.10 hour)

- Voice Memo in Still Image (max. 10 sec.)

Date Imprinting

- Date, Date & Time, Off (user selectable)

Ⅰ.SPECIFICATION

1. CAMERA SPECIFICATION

Normal Macro Auto Macro

Wide 80cm ~ infinity 5 ~ 80cm 40cm ~ infinity

Tele 40 ~ 80cm 40cm ~ infinity

Shooting - Still Image : ·Modes : Auto, Program, ASR, M, Scene

·Scene : Night, Portrait, Landscape, Text, Children, Close-up, Sunset, Dawn,

Backlight, Fireworks, Beach & Snow

·Shooting : Single, Continuous, AEB, Wise Shot (S730 only)

·Self-timer : 2 sec.,10 sec., Double (10 sec., 2 sec.)

- Movie Clip : ·With Audio or without Audio

(user selectable, recording time : memory capacity dependent)

※The maximum file size of continuous movie clip is 2GB.

·Size : 640X480, 320X240

·Frame rate : 30 fps, 15 fps

·Optical zoom: Max. 3X

Storage - Media : ·Internal memory : Approx.16MB flash memory

·External memory : SDHC / MMC / SD card (Up to 4GB Guaranteed)

- File Format : ·Still Image : JPEG (DCF), EXIF 2.2, DPOF 1.1, PictBridge 1.0

·Movie Clip : AVI (MJPEG)

·Audio : WAV

- Image Size

·S730

·S630

- Capacity (256 MB MMC)

·S730

·S630

※These figures are measured under Samsung’s standard conditions and may vary depending on

shooting conditions and camera settings.

Ⅰ.SPECIFICATION

3072X2304 3072X2048 3072X1728 2592X1944 2048X1536 1024X768

2816X2112 2784X1856 2816X1584 2048X1536 1024X768

Super Fine 67 80 95 95 150 558

Fine 128 157 183 183 284 710

Normal 197 223 269 269 400 822

Super Fine 80 95 124 150 558

Fine 157 183 233 284 710

Normal 223 269 306 400 822

Ⅰ.SPECIFICATION

““E””

Button - Effect : Color, Image Adjust, Fun (Highlight, Composite ,Photo Frame)

- Editing : Resize, Rotate, Color, Special Color, Image Adjust (Brightness, Contrast, Saturation, Add

Noise), Fun (Cartoon, Highlight, Composite, Photo Frame, Sticker)

Image Play - Single image, Thumbnails, Slide show, Movie Clip

Interface - Digital output connector : USB 2.0 High Speed

- Audio : Mono

- Video output : NTSC, PAL (user selectable)

Power Source

- Primary Battery : 2 x AA Alkaline

- Rechargeable battery (0ptional) : SNB-2512B KIT (2xAA 2500mAh Ni-MH Battery & Charger)

※Included battery may vary depending on sales region.

Dimensions (WxHxD)

- 99.8x 62.8x25.7mm (excluding protrusions)

Weight - Approx. 136g (without batteries and card)

Operating Temperature

- 0 ~ 40°C

Operating Humidity

- 5 ~ 85%

Software - Camera Driver : Storage Driver : (Windows98/98SE/2000/ME/XP, Mac OS 9.2 ~ 10.3)

- Special Features : Digimax Master, Adobe Reader

For Windows For Macintosh

Ⅰ.SPECIFICATION

2. System Requirements

PC with processor better than Pentium II 450MHz

(Pentium 700MHz recommended)

Minimum 64MB RAM

200MB of available hard disk space

Windows 98/98SE/2000/ME/XP

USB port

CD-ROM drive

1024x768 pixels, 16bit color display compatible

monitor (24bit color display recommended)

MicroSoft DirectX 9.0C

Power Mac G3 or later

Mac OS 9.2~10.3

Minimum 64MB RAM

110MB of available hard-disk space

USB port

CD-ROM drive

Ⅰ.SPECIFICATION

②

③

④

⑤

⑥

⑦

⑧ ⑨ ⑩

①   ⑲⑳

⑪

⑫

⑬

⑭

⑮

⑯

⑰

⑱

3. LCD monitor indicator

■Recording mode

[ Image & Full Status ]

Ⅰ.SPECIFICATION

No. Description Icons

2Aperture Value/ Shutter Speed F2.8, 1/30

3Flash/ Without Sound

4Self-timer

5Macro

6Contrast

7Sharpness

8 Auto focus frame

9 Camera shake warning

10 Date/ Time 2007/01/01 01:00 PM

11 Exposure compensation

12 White Balance

15 Metering

16 Image quality

18 Battery

20 Voice memo

Number of available shots remaining 6

Movie / Voice recording time 00:00:00

22 Card inserted indicator

Recordingmode

Optical/ Digital Zoom bar

/ Digital Zoom rate

ISO

Continuous shot

Image size

S730

S630

S730

S630

S730

S630

No. Description Icon

Play mode icon

Voice Memo

Protect

DPOF

Recording date

2007/01/01

Image size

3072X2304 ~ 256X192

Flash

ON/OFF

Shutter speed

1 ~ 1/1500

Aperture value

F2.8 ~ F12.4

ISO

80 ~ 1000

Battery

Folder name & File name

100-0031

Memory card indicator

Ⅰ.SPECIFICATION

■Play mode

ISO

FLASH

SIZE

DATE

F2.8

1/250

OFF

3072X2304

2007/01/01

②

①

③

④⑩

⑪

⑫⑬

⑨

⑧

⑥

⑤

⑦
