Samsung AD68-05243A Manual de instrucciones

ENG / SPA / FRE

Quick Start Manual

Guide de prise en main repide

WB5500

Health and safety informationContents

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach of

small children and animals. Small parts may cause choking

or serious injury if swallowed. Moving parts and accessories

may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1m/3 ft)

to people or animals. Using the ﬂash too close to your

subject’s eyes can cause temporary or permanent damage.

Health and safety

information……………………… 2

Camera layout ………………… 4

Setting up your camera ……… 5

Unpacking ………………………… 5

Inserting the battery and memory

card ………………………………… 6

Charging the battery ……………… 6

Turning on your camera ………… 7

Selecting options ………………… 7

Capturing photos or videos … 8

Playing ﬁles …………………… 9

Transferring ﬁles to a PC

(Windows) ……………………… 10

Speciﬁcations ………………… 11

107

104

English

Exercise caution when connecting cables or adapters

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

Do not insert foreign objects into any of your camera’s

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

Protect batteries, chargers, and memory cards from

damage

Avoid exposing batteries or memory cards to very

cold or very hot temperatures (below 0° C/32° F or

above 40° C/104° F). Extreme temperatures can

reduce the charging capacity of your batteries and

can cause memory cards to malfunction.

Prevent memory cards from making contact with

liquids, dirt, or foreign substances. If dirty, wipe the

memory card clean with a soft cloth before inserting

in your camera.

•

Handle and dispose of batteries and chargers with

care

Use only Samsung-approved batteries and chargers.

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

Never place batteries or cameras on or in heating

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

Cautions

Handle and store your camera carefully and sensibly

Do not allow your camera to get wet—liquids can

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

Avoid using or storing your camera in dusty, dirty,

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

•

Camera layout

Shutter button

Zoom W Lever (Thumbnail)

Zoom T Lever (Digital zoom)

Built-in ﬂash

Diopter adjustment lever

Hook for neck strap

Speaker

HDMI port

USB and A/V port

Lens

Flash pop-up button

Microphone

AF Lamp/Self-timer lamp

ㄴ

Mode Dial

POWER button

ㄴ

Hook for neck strap

AE lock/image protection button

Exposure compensation button

OK/AF point button

ㄴ

Fn / Delete button

ㄴ

Smart dial

ㄴ

Play mode button

MENU button

EVF/LCD button

Video shooting button

LCD monitor

Electronic Viewﬁnder (EVF)

English

Setting up your camera

Unpacking

Camera AC adapter / USB cable Rechargeable battery

Neck strap Lens cap /

Lens cap strap

Software CD

Quick Start Manual

SD/SDHC

memory card AV cable

Battery charger HDMI cable

Sold Separately

Inserting the battery and memory card Charging the battery

▼

Removing the battery

With the gold-colored

contacts facing up

With the

Samsung logo

facing up

Push gently until the card

disengages from the camera and

then pull it out of the slot.

▼

Removing the memroy card

Be sure to charge the battery before using the camera.

Indicator light

Red: Charging

Green: Fully charged

▪

Setting up your camera

English

Press [POWER].

The intial setup

screen appears.

Press [t] to select

Language.

Press [

] or [

]

to select a language and press [

Press [D] or [M] to select Time Zone and

press [t].

Press [F] or [t] to select an item.

Press [D] or [M] to select Date & Time and

press [t].

Press [F] or [t] to select an item.

Press [D] or [M] to change the number or

select another date format and press [o].

▪

In Shooting mode, press [m].

Use the navigation buttons to scroll to an

option or menu.

Back

White Balance

Move

To move left or right, press [F] or [t].

To move up or down, press [D] or [M].

Press [o] to conﬁrm the highlighted option or

menu.

Press [m] again to go back to the previous

menu.

▪

Turning on your camera Selecting options

Exit Change

Language

Time Zone

Date & Time

: English

: London

: 2010/03/01

Taking a photo

Rotate the mode dial to p.

Align your subject in the frame.

Press [Shutter] halfway down to focus

automatically.

A green frame means the subject in focus.

Press [Shutter] all the way down to take the

photo.

▪

Recording a video

Rotate the mode dial to v.

Align your subject in the frame.

Press [Shutter].

Press [Shutter] again to stop the recording.

Note

Number of photos by resolution (for 1 GB SD)

Resolution

4288 x 3216 29 33 116 191 285

4288 x 2848

- -

131 215 321

4288 x 2416

- -

154 252 375

3264 x 2448

- -

199 324 479

2592 x 1944

- -

311 502 733

2048 x 1536

- -

487 779 1113

1920 x 1080

- -

716 1113 1558

1024 x 768

- -

1640 2397 3116

These ﬁgures are measured under Samsung’s standard

conditions and may vary depending on shooting conditions

and camera settings.

Capturing photos or videos

English

Playing ﬁles

Viewing photos

Press [P].

Press [F] or [t] to scroll through ﬁles.

Press and hold to view ﬁles quickly.

▪

Viewing videos

Press [P].

Press [o].

Pause

Use the following buttons to control playback.

[F] Scan backward

[o] Pause or resume playback

[t] Scan forward

[Zoom W/T Lever]

left or right Adjust the volume level

1110

Transferring ﬁles to a PC (Windows)

Insert the installation CD in a CD-ROM drive

and follow the onscreen instructions.

Connect the camera to the PC with the USB

cable.

Turn on the camera.

On your PC, select My Computer →

Removable Disk →DCIM →100PHOTO.

Select the ﬁles you want and drag or save them

to the PC.

Disconnecting safely (for Windows XP)

Click



Click
