Samsung Galaxy Note Guía

TABLE OF CONTENTS

INTRODUCTION 3

Support 3

Service 4

YOUR DEVICE 5

Front and Back Features 5

Side Features 6

S Pen 7

Battery Installation/Removal 10

Turning Your Device On or Off 18

Locking and Unlocking Your Device 19

Extending Your Battery Life 19

Home Screen 21

DEVICE FUNCTIONS 25

Creating a New Google Account 25

Signing into Your Google Account 26

Voicemail 27

Visual Voicemail 28

Calling Features 30

Contacts 33

TABLE OF CONTENTS

INTRODUCTION

TABLE OF CONTENTS

Bluetooth 36

Wi-Fi 38

Mobile HotSpot 39

USB Tethering 41

Web Browsing 43

Setting Up Email 45

Messaging 48

Safety Tips 51

Emergency Dialing 52

Accessories 53

Additional Information 55

NOTES 58

INTRODUCTION

SUPPORT

This guide provides you with the information you

need to get started. For more information and

additional support, please visit www.t-mobile.com/

support where you can:

●Register at my.t-mobile.com to check your

minutes, pay your bill, upgrade your phone, and

change your rate plan.

●Review your device’s User Manual and

troubleshooting FAQs.

●View the latest troubleshooting solutions in the

Support Forums or ask a question of your own.

You can also access account and device

information from:

1. From the Home screen, tap

(Applications) g(Access T-Mobile).

2. Choose from an available category such as:

My Account, Billing, Plans & Services, or

Other T-Mobile Links.

10 11

7891

YOUR DEVICE

INTRODUCTION

FRONT AND BACK FEATURES

1. MICROPHONE

2. MENU KEY

3. HOME KEY

4. BACK KEY

5. SEARCH KEY

6. DISPLAY

7. FRONT-FACING

CAMERA

8. SENSORS

9. EARPIECE

10. CAMERA LENS

11. FLASH

YOUR DEVICE

SERVICE

If you are a new T-Mobile®customer and your

service has not yet been activated, call Customer

Care at 1-800-937-8997 and a T-Mobile Activations

representative will assist you.

You will need the following information when

activating service:

●Your Service Agreement and the agent code on

your Agreement

●Your name, home address, home phone number,

and billing address

NOTE: For business and government accounts, please provide the

name of the organization, the address, and the tax ID.

●Your Social Security number, current driver’s

license number, and date of birth for credit check

purposes

●Your choice of T-Mobile rate plan and services

(see www.t-mobile.com for the latest plan

information)

●SIM serial number and IMEI number (located on

the box barcode label)

NOTE: By activating service, you acknowledge that you have read,

understand, and agree to be bound by each of T-Mobile’s

Terms and Conditions, and your Service Agreement.

1. PEN BUTTON

2. STYLUS TIP

YOUR DEVICE

SIDE FEATURES

1. HEADSET CONNECTOR

2. POWER/LOCK KEY

3. EXTERNAL SPEAKER

4. S-PEN

5. CHARGING PORT

6. VOLUME KEY

S PEN

The S Pen™ is a stylus that assists you in

performing different functions. By using the Pen

button, you can minimize having to switch between

touch and pen input.

YOUR DEVICE

Removing the S Pen from your Phone

The S Pen is stored within your device to make it

easier to keep track of.

To remove the S Pen:

1. Use your fingernail or a sharp object to pull

the end of the S Pen out of the phone (1).

2. Pull the S Pen out from the device (2).

Using the S Pen

There are several different functions you can

perform by using the S Pen.

Back Button Function

To move to a previous screen:

1. Grasp the pen and press the Pen button.

2. In a single motion, touch on the screen for

one second then drag the screen to the left.

The previous screen is displayed. Holding it

for 2 seconds takes a screen shot.

Menu Button Function

To display the menu from any screen:

1. Grasp the pen and press the Pen button.

2. In a single motion, touch on the screen and

then drag the pen upward. The menu is

displayed.

Screen Capture

To take a screen capture of any screen:

1. Grasp the pen and press the Pen button.

2. Touch and hold the S Pen anywhere on the

screen. Files are saved in the My files g

Pictures gScreenshots folder and

(Screen capture) appears in the Notifications

area of the screen to indicate a screen

capture has been taken.

YOUR DEVICE

BATTERY INSTALLATION/REMOVAL

Your device is powered by a rechargeable, standard

Li-Ion battery. The battery, SIM card and SD card

are installed under the battery cover.

NOTE: Although the battery comes partially charged, you must fully

charge this battery before using your device for the first time.

WARNING: Use only Samsung-approved charging devices and

batteries. Samsung accessories are designed to

maximize battery life. Using other accessories may

invalidate your warranty and may cause damage.

IMPORTANT: Before removing or replacing the battery, make sure

the device is switched off. To turn the device off, hold

down the key until the Device options

screen displays, then tap Power off.

Removing the Battery Cover

1. Hold the device firmly and locate the cover

release latch.

2. Place your fingernail in the opening and

firmly “pop” the cover off the device (1)

(similar to a soda can).

3. Lift the cover up (2) and away from the

device (3).

4. Slide the battery into the compartment so

that the tabs on the end align with the slots

at the bottom of the phone, making sure the

connectors align.

YOUR DEVICE

Replacing the Battery Cover:

1. Place the battery cover onto the back bottom

of the phone (1) and press down (2).

2. Press all along the edge of the back cover

until you have a secure seal (3).

Installing the Battery

1. Slide the battery into the compartment (1) so

that the tabs on the end align with the slots

at the bottom of the phone, making sure the

connectors align.

2. Gently press down to secure the battery (2).

Removing the Battery

XGrip the battery at the top end (3) and lift it

up and out of the battery compartment (4).

Installing the microSD Memory Card

Your device supports an optional (external)

microSD™ or microSDHC™ memory card for

storage of media such as music, pictures, video

and other ﬁles.

NOTE: microSD memory cards include capacities of up to 2GB.

microSDHC™ memory card types can range from 4GB to

up to 32GB.

WARNING: Applications, personal settings and other stored data

may be lost or may not function properly if the memory

card is removed.

1. Remove the battery cover.

2. Locate the microSD card slot on the inside of

the phone.

3. Orient the card with the gold strips facing down.

4. Firmly press the card into the slot and make

sure that it catches with the push-click insert.

Correct

Incorrect

Installing and Removing the SIM Card

IMPORTANT: Before removing or replacing the SIM card, make

sure the device is switched off. To turn the device

off, hold down the key until the Device

options screen displays, then tap Power off.

To install the SIM card:

1. Carefully slide the SIM card into the SIM card

socket until the card clicks into place.

2. Make sure that the card’s gold contacts face

into the device and that the upper-left angled

corner of the card is positioned as shown.

Correct

Incorrect

YOUR DEVICE

CHARGING HEAD

YOUR DEVICE

Charging the Battery

Your device comes with a USB cable and charging

head to rapidly charge your phone from any

120/220 VAC outlet.

IMPORTANT: Verify that the battery is installed prior to connecting

the wall charger. If both the wall charger is connected

and the battery is not installed, the handset will power

cycle continuously and prevent proper operation.

Failure to unplug the wall charger before you

remove the battery, can cause the device to become

damaged.

1. Connect the USB cable to the charging head.

2. Plug the charging head into a standard AC

power outlet.

Correct

Incorrect

3. Insert the USB cable into the device’s

Charger/Accessory jack.

Correct

Incorrect

4. If using a wall charger, plug the charging

head into a standard AC power outlet. If using

a computer, remove the charging head and

plug the USB cable into computer’s USB port.

NOTE: For the most efficient charging, consumers should use the

charger included in the box.

YOUR DEVICE

TURNING YOUR DEVICE ON OR OFF

Powering On Your Device

XPress and hold (Power/Lock)

until the device turns on. It searches for your

network and after finding it, you can make or

receive calls.

Powering Off Your Device

1. Press and hold the (Power/Lock)

until the Device options screen appears.

2. Tap (Power Off).

Restarting Your Device

1. Press and hold the (Power/Lock)

until the Device options screen appears.

2. Tap (Restart).

LOCKING AND UNLOCKING YOUR DEVICE

By default, the device screen locks when the

backlight turns off.

To unlock your device from the lock screen:

XWith your device turned on, press

(Power/Lock) to wake the display and sliding

your finger across the screen in any direction.

To lock your device screen:

XPress (Power/Lock). The screen

goes black.

EXTENDING YOUR BATTERY LIFE

Active applications, light levels, Bluetooth usage,

and GPS functionality all act to drain your battery.

The following is a list of helpful tips that can help

conserve your battery power:

●Reduce your backlight on time.

●Turn Bluetooth®off when not in use.

●Turn Wi-Fi®off when not in use.

●Deactivate the GPS when not needed. Most

applications using this function will periodically

query the GPS satellites for your current location;

each query drains your battery.

Otros manuales para Galaxy Note

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Teléfono móvil de Samsung

Samsung

Samsung SGH-D840 Manual de usuario

Samsung

Samsung GALAXY S5 Manual de funcionamiento

Samsung

Samsung GT-S3370L Manual de usuario

Samsung

Samsung Acclaim Manual de usuario

Samsung

Samsung SM-M205F Manual de usuario

Samsung

Samsung SM-A045M Manual de usuario

Samsung

Samsung Wave Y GT-S5380D Manual de usuario

Samsung

Samsung Rant SPH-m540 Manual de usuario

Samsung

Samsung SM-A320FL Manual de usuario

Samsung

Samsung Galaxy S4 Manual de usuario

Samsung

Samsung SCH-n330 Series Manual de usuario

Samsung

Samsung SM-A025V-UM Manual de usuario

Samsung

Samsung GT-M7600L Manual de usuario

Samsung

Samsung Galaxy Note 10 Lite Manual de usuario

Samsung

Samsung Galaxy S II GT-I9100 Manual de usuario

Samsung

Samsung SCH-R530X Manual de usuario

Samsung

Samsung SGH-J160L Manual de usuario

Samsung

Samsung Galaxy Note 3 Manual de usuario

Samsung

Samsung Galaxy S6 Edge Manual de usuario

Samsung

Samsung SGH-F268 Manual de usuario

Samsung

Samsung SCH R455C Manual de usuario

Samsung

Samsung GT-S6810L Manual de usuario

Samsung

Samsung SGH-X430 Manual de usuario

Samsung

Samsung SGH-F330 Manual de usuario

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Nokia

Nokia Lumia 620 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LG LM-X420QN Manual de usuario

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

LG LM-K420EMW Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario
