Samsung Techwin SHD-3000F1 Manual de usuario
In-ceiling Housing
Installation Manual SHD-3000F1
_ SHD-3000F1
Overview 3
What’sIncluded 3
InstallationInstructions 4
(indoortype) 4
(outdoortype) 8
12
SHD-3000F1 _3
ENG
This In-CEILING HOUSING is a mounting ADAPTOR that is designed to mount the smart
dome camera in built-in style on a double-layer ceiling.
HOUSING SAFETY BRACKET (
1EA)
SAFETY WIRE (1SET)
WARRANTY
|usvjr
|usvjr
svjr
TEMPLATE (1EA)
outdoortype(3EA)
indoortype(2EA)
Lowerbracket(exclusivelyfor
indoordomecameras)(1EA)
In-ceiling Housing
Installation Manual SHD-3000F1
INSTALLATION MANUAL
_ SHD-3000F1
Select an installation position or place that can endure more than 4 times of the total weight
of the installation structure.
At least 250mm or more of spare height is required above the CEILING BOARD.
CEILING BOARD’s thickness should be less than 40mm.
Be sure to secure the SAFETY WIRE to avoid a product fall.
If you want to attach the camera to the ADAPTOR, use the only provided SCREWS.
(indoor type)
Place the TEMPLATE on the CEILING BOARD and drill a guided hole.
❶ Remove the round lling (“C”) from the TEMPLATE.
2 Place A onto the to which you will attach the ceiling
mount ADAPTOR and drill a hole of Ø198mm in diameter.
See the gure below for the hole shape.
1.
.
3.
.
.
1.
250mm 이상일 것
천장보드 40mm 이하일 것
More than 250mm
CEILING BOARD Less than 40mm
Ø198mm
형판
천장 보드
Ø198mm
TEMPLATE
CEILING BOARD
SHD-3000F1 _
ENG
Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to the
ANCHOR BOLT as below:
❶ Tighten the nut (“N1”) on the ANCHOR BOLT.
2 Insert the provided SAFETY BRACKET into the ANCHOR BOLT.
3 Tighten two nuts (“N2”,”N3”) onto the ANCHOR BOLT.
4 Hook and x one end of the SAFETY WIRE onto the SAFETY BRACKET.
5 Hook and x the other end of SAFETY WIRE onto the HOUSING as shown below.
To connect to the camera, insert the external cable through the side on the
to the inside of the as shown in the gure.
Refer to the installation manual of the camera that you want to install, and prepare necessary
cables for camera connection.
.
3.
M
앙카볼트
천장
너트(N1)
안전브라켓
앙카볼트
너트(N2,N3)
안전와이어
천장
하우징
The ANCHOR BOLTs and nuts are optional and not included in the product package.
ANCHOR BOLT
Nut (N1)
Safety BRACKET
Nut (N2,N3)
SAFETY WIRE
ANCHOR BOLT
HOUSING
CEILING
CEILING
천장
홀하우징
하우징
외부케이블
CEILING
Hole HOUSING
HOUSING
External Cable
_ SHD-3000F1
Push the HOUSING inside the CEILING through the CEILING hole, and tighten the
SCREWs (x2) clockwise to x the HOUSING on the CEILING.
(The BRACKET will be positioned from <A> to <B> as shown.)
Ensure that the HOUSING is rmly secured to the CEILING BOARD.
브라켓
브라켓
<A상태> <B상태>
브라켓
하우징
브라켓
스크류
시계방향으로 회전
Combine the dome camera and the bracket using two screws.
|usvjr
svjr
|usvjr
svjr
FRONT
TOP
DC 12V
1 2 3
1.ALARM OUT
2.ALARM IN
3.GND
VIDEO
RESET
T
F
W
N
AF
+-
|usvjr
|usvjr
svjr
FRONT
TOP
DC 12V
1 2 3
1. ALARM OUT
2. ALARM IN
3. GND
VIDEO
RESE T
T
F
W
N
AF
+-
※ Lower bracket is exclusively for indoor use.
.
M
.
(indoor type)
BRACKET
SCREW
Turn clockwise
HOUSING
BRACKET
BRACKET
BRACKET
<A> <B>
SHD-3000F1 _
ENG
Insert the bracket where the camera is mounted into the and x it by turning it in
the direction.
When the installation is completed, remove both PROTECTIVE TAPE and PRETOECTIVE COVER
from the lens.
하우징
천장
UNLOCK
LOCK
UNLOCK
LOCK
FRONT
TOP
DC 12V
1 2 3
1.ALARM OUT
2.ALARM IN
3.GND
VIDE O
RESET
T
F
W
N
AF
+-
UNLOCK
LOCK
FRONT
DC 12V
1 2 3
1. ALARM OUT
2. ALARM IN
3. GND
VID EO
RESET
N
AF
+-
Attach the to the .
홈
하우징
홈
커버
홈
홈
하우징
커버
FRONT
TOP
DC 12V
1 2 3
1. ALARM OUT
2. ALARM IN
3. GND
VIDEO
RESET
T
F
W
N
AF
+-
TOP
1 ALARMOUT
ARMIN
VIDEO
RES
T
.
M
.
CEILING
HOUSING
HOUSING
Cover
_ SHD-3000F1
(outdoor type)
Place the on the and drill a guided hole.
❶ Remove the round lling (“C”) from the .
2 Place the A onto the to which you will attach the
CEILING mount ADAPTOR and drill a Ø198mm hole.
See the gure below for the hole shape.
Fix the onto the concrete CEILING, and secure the to the
as below:
❶ Tighten the (“N1”) on the .
2 Insert the provided into the .
3 Tighten two s (“N2”,”N3”) onto the .
4 Hook and x one end of the onto the .
5 Hook and x the other end of onto the as shown below:
1.
.
The ANCHOR BOLTs and nuts are optional and not included in the product package.
앙카볼트
천장
너트(N1)
안전브라켓
앙카볼트
너트(N2,N3)
안전와이어
천장
하우징
ANCHOR BOLT
CEILING
Nut (N1)
Safety BRACKET
Nut (N2,N3)
SAFETY WIRE
ANCHOR BOLT
HOUSING
CEILING
Ø198mm
형판
천장 보드
Ø198mm
CEILING BOARD
TEMPLATE
SHD-3000F1 _
ENG
To connect to the camera, insert the external cable through the side on the
to the inside of the as shown in the gure.
Refer to the installation manual of the camera that you want to install, and prepare necessary
cables for camera connection.
Push the inside the CEILING through the CEILING hole, and tighten the
SCREWs (x2) clockwise to x the HOUSING on the CEILING.
(The will be positioned from <A> to <B> as shown.)
Ensure that the HOUSING is rmly secured to the CEILING BOARD.
3.
M
.
M
천장
하우징
어댑터
스냅핏 외부케이블
홀하우징
CEILING
HOLE HOUSING
브라켓
브라켓
<A상태> <B상태>
브라켓
하우징
브라켓
스크류
시계방향으로 회전
BRACKET
SCREW
Turn clockwise
HOUSING
BRACKET
<B><A>
BRACKET
BRACKET
10_ SHD-3000F1
As shown in the gure, pull out the protrusions of the rubber cap in the bottom to make a
small hole and remove the cable through it to connect to the external cable.
ALARM IN ALARM OUT
알람 케이블
오디오
RS-485
전원
전원
LAN
절연튜브
BNC잭
어댑터 프레임
하우징
천장
CAUTION:Be ware o f the
Rated Voltage and Polarity
ofthep owerconnection.
CAUTION:Be wa reo f the
RatedVol tagea ndPolarity
of the powerconnection.
If waterproong in the connected cable jacket is poor, it may cause leaks. Make sure you tape it
tight and thoroughly.
The butyl rubber tape for waterproong can extend at least twice as long as the original length.
.
M
(outdoor type)
Alarm Cable
Audio
Power
