Samsung SL-M2875FD Manual de usuario

BASIC

User’s Guide

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 4

Features by models 6

Useful to know 11

About this user’s guide 12

Safety information 13

Machine overview 18

Control panel overview 21

Turning on the machine 24

Installing the driver locally 25

Reinstalling the driver 28

2. Menu Overview and Basic Setup

Menu overview 30

Machine’s basic settings 34

Media and tray 36

Basic printing 51

Basic copying 57

Basic scanning 62

Basic faxing 63

3. Maintenance

Ordering supplies and accessories 68

Available supplies 69

Available maintenance parts 70

Storing the toner cartridge 71

Redistributing toner 73

Replacing the toner cartridge 76

Replacing the imaging unit 79

Monitoring the supplies life 81

Setting the toner low alert 82

Cleaning the machine 83

Tips for moving & storing your machine 90

4. Troubleshooting

Tips for avoiding paper jams 92

Clearing original document jams 93

Clearing paper jams 96

Understanding the status LED 104

Understanding display messages 107

BASIC

5. Appendix

Specifications 113

Regulatory information 123

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 4

• Features by models 6

• Useful to know 11

• About this user’s guide 12

• Safety information 13

• Machine overview 18

• Control panel overview 21

• Turning on the machine 24

• Installing the driver locally 25

• Reinstalling the driver 28

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature.

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 88).

• To save paper, you can print on both sides of the paper (double-sided

printing) (see "Using advanced print features" on page 88).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print with a resolution of up to 4,800 x 600 dpi effective (600 x 600

x 3 bit) output.

• Fast, on-demand printing.

M267x series:

- For single-side printing, 26 ppm (A4) or 27 ppm (Letter).

M287x series:

- For single-side printing, 28 ppm (A4) or 29 ppm (Letter).

Convenience

• You can print on the go from your smartphone or computer using Google

Cloud Print™ enabled apps (see "Google Cloud Print™" on page 60).

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 120).

Key benefits

• Samsung Easy Printer Manager and Printing Status is a program that

monitors and informs you of the machine’s status and allows you to

customize the machine’s settings (see "Using Samsung Printer Status" on

page 130or "Using Samsung Easy Printer Manager" on page 127).

• Samsung Easy Document Creator is an application to help users scan,

compile, and save documents in multiple formats, including .epub format.

These documents can be shared via social networking sites or fax (see

"Using Samsung Easy Document Creator" on page 126).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 121).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 115).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 88).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 88).

• You can print in various operating systems (see "System requirements" on

page 118).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on the

machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or Wi-

Fi Direct feature.

See "Introducing wireless set up methods" on page 26.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For Windows, select the printer driver and software in the Select Software to Install window.

Operating System M267x series M287x series

Windows ● ●

Mac ● ●

Linux ● ●

Unix ●

Software M267x series M287x series

SPL printer drivera● ●

PCL printer driver ●

PS printer drivera

XPS printer driverb● ●

Features by models

Direct Printing Utilityb

Samsung Easy

Printer Manager

Scan to PC settings ● ●

Fax to PC settings ●

(M267xF/M267xFN/M267xFH/M267xHN

only)

●

(M287xFD/M287xFW/M287xHN only)

Device settings ● ●

Samsung Printer Status ● ●

Samsung AnyWeb Printb● ●

Samsung Easy Document Creator ● ●

Easy Capture Manager ● ●

SyncThru™ Web Service ●

(M267xN/M267xFN/M267xHN only)

●

SyncThru Admin Web Service ●

(M267xN/M267xFN/M267xHN only)

●

Easy Eco Driver ● ●

Easy Capture Manager ● ●

Fax Samsung Network PC

Fax

●

(M267xF/M267xFN/ M267xFH/

M267xHN only)

●

(M287xFD/M287xFW/M287xHN only)

Software M267x series M287x series

Features by models

(●: Included, Blank: Not available)

Scan Twain scan driver ● ●

WIA scan driver ● ●

a. Depending on the operating system you use, the installed printer driver may differ.

b. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Download). Before installing, check

whether your computer’s OS support the software.

Software M267x series M287x series

Features by models

Variety feature

Features M267x series M287x series

Hi-Speed USB 2.0 ● ●

Network Interface Ethernet 10/100 Base TX

wired LAN

●

(M267xN/M267xFN/M267xHN only)

●

Network Interface 802.11b/g/n wireless LANa●

(M287xFW only)

Google Cloud Print™ ●

(M267xN/M267xFN/M267xHN only)

●

AirPrint ●

(M267xN/M267xFN/M267xHN only)

●

Eco printing ● ●

Duplex (2-sided) printing ●

Duplex (2-sided) printing (manual)bc ●

Document Feeder Automatic Document

Feeder (ADF)

● ●

Handset ●

(M267xFH/M267x HN only)

●

(M287x HN only)
