Samsung CLX-3305FN Manual de usuario

BASIC

User’s Guide

CLX-330x/330xW Series

CLX-330xFN/330xFW Series

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 5

Features by models 7

Useful to know 12

About this user’s guide 13

Safety information 14

Machine overview 19

Control panel overview 23

Turning on the machine 29

Installing the driver locally 30

Reinstalling the driver 32

2. Menu Overview and Basic Setup

Menu overview 34

Machine’s basic settings 40

Media and tray 42

Basic printing 54

Basic copying 60

Basic scanning 64

Basic faxing 65

Using USB memory device 69

3. Maintenance

Ordering supplies and accessories 75

Available supplies 76

Available maintenance parts 77

Storing the toner cartridge 78

Redistributing toner 80

Replacing the toner cartridge 82

Replacing the waste toner container 84

Replacing the imaging unit 86

Monitoring the supplies life 88

Setting the toner low alert 89

Cleaning the machine 90

Tips for moving & storing your machine 95

4. Troubleshooting

Tips for avoiding paper jams 97

Clearing original document jams 98

Clearing paper jams 103

Understanding the status LED 109

BASIC

Understanding display messages 111

5. Appendix

Specifications 118

Regulatory information 127

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 5

• Features by models 7

• Useful to know 12

• About this user’s guide 13

• Safety information 14

• Machine overview 19

• Control panel overview 23

• Turning on the machine 29

• Installing the driver locally 30

• Reinstalling the driver 32

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature (see "Eco

printing" on page 58).

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 219).

• To save paper, you can print on both sides of the paper (double-sided

printing) (Manual) (see "Using advanced print features" on page 219).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

Fast high resolution printing

• You can print in a full range of colors using cyan, magenta, yellow, and black.

• You can print with a resolution of up to 2,400 x 600 dpi effective output (600

x 600 x 2 bit).

• Fast, on-demand printing.

- For single-side black and white printing, 18 ppm (A4) or 19 ppm (Letter).

- For single-side color printing, 4 ppm (A4 or Letter).

Convenience

• You can print on the go from your smartphone or computer using Google

Cloud Print enabled apps (see "Google Cloud Print" on page 189).

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 249).

• Samsung Easy Printer Manager and Printing Status is a program that

monitors and informs you of the machine’s status and allows you to

customize the machine’s settings (see "Using Samsung Easy Printer

Manager" on page 256 or "Using Samsung Printer Status" on page 264).

• Samsung Easy Document Creator is an application to help users compile

and share large documents or other scanned or faxed information digitally.

(see "Using Samsung Easy Document Creator" on page 259 ).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily, than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 251).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

Key benefits

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 120).

• Print watermark: You can customize your documents with words, such as

“CONFIDENTIAL” (see "Using advanced print features" on page 219).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 219).

• You can print in various operating systems (see "System requirements" on

page 122).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or

Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 164.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Operating System CLX-330x Series

CLX-330xW Series

CLX-330xFN Series

CLX-330xFW Series

Windows ● ●

Macintosh ● ●

Linux ● ●

Features by models

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For windows, select the printer driver and software in the Select Software to Install window.

Software CLX-330x Series

CLX-330xW Series

CLX-330xFN Series

CLX-330xFW Series

SPL printer driver ● ●

PCL printer driver ● ●

PS printer driver ● ●

XPS printer drivera● ●

Samsung Easy Printer

Manager

Scan to PC settings ● ●

Fax to PC settings ●

Device Settings ● ●

Samsung Easy Document Creator ● ●

Samsung Easy Color Managerb● ●

Samsung Printer Status ● ●

AnyWeb Printb● ●

Features by models

(●: Included, Blank: Not available)

SyncThru™ Web Service ●

(CLX-330xW Series only)

●

SyncThru Admin Web Service ●

(CLX-330xW Series only)

●

Easy Eco Driver ● ●

Fax Samsung Network PC Fax ●

Scan Twain scan driver ● ●

WIA scan driver ● ●

Samsung Scan Assistantb● ●

a. For XPS/PS driver, You can install the XPS/PS printer driver in the Custom Installation window (Refer to Software CD that was provided with your machine).

b. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Downloads). Before installing, check whether

your computer’s OS support the software.

Software CLX-330x Series

CLX-330xW Series

CLX-330xFN Series

CLX-330xFW Series

Features by models

Variety feature

(●: Included, Blank: Not available)

Features CLX-330x Series

CLX-330xW Series

CLX-330xFN Series

CLX-330xFW Series

Hi-Speed USB 2.0 ● ●

Network Interface Ethernet 10/100 Base TX wired LAN ●

(CLX-330xW Series only)

●

Network Interface 802.11b/g/n wireless LANa

a. Depending on your country, wireless LAN card may not be available. For some counties, only 802.11 b/g can be applied. Contact your local Samsung dealer or the retailer

where you bought your machine.

●

(CLX-330xW Series only)

●

(CLX-330xFW Series only)

Google Cloud Print™ ● ●

Eco printing (Control panel) ● ●

Duplex (2-sided) printing (Manual)b

b. Windows only.

● ●

USB memory interface ● ●

Automatic Document Feeder (ADF) ●
