Samsung AQV12VB Series Manual de usuario

E-2

Contents

 PREPARATION

Safety Precautions ......................................................................................................... 3

Name of Each Part ......................................................................................................... 8

Remote Control – Buttons and Display ............................................................... 10

Inserting the Remote Control Batteries ............................................................... 10

Getting Started ............................................................................................................... 11

 OPERATION

Selecting Auto Mode ................................................................................................... 12

Selecting Cool Mode .................................................................................................... 13

Selecting Heat Mode ................................................................................................... 14

Selecting Dry Mode ...................................................................................................... 15

Selecting Fan Mode ...................................................................................................... 16

Selecting the Turbo Function ................................................................................... 16

Selecting the Energy Saving Function ................................................................. 17

Selecting Mode ...................................................................................... 18

Adjusting the Airflow Direction .............................................................................. 20

Selecting Auto Cleaning Function ......................................................................... 21

Setting the On Timer .................................................................................................... 22

Setting the Off Timer ................................................................................................... 23

Selecting Silence Function ........................................................................................ 24

Operating Your Air Conditioner Without the Remote Control .................. 24

Selecting Mode ........................................................................................ 25

 RECOMMENDATIONS FOR USE

Cleaning the Air Filter on Your Air Conditioner ................................................ 26

Cleaning Deodorizing and Bio filter (Option) ................................................... 26

Temperature and Humidity Ranges ...................................................................... 27

Operating Recommendations ................................................................................. 28

Solving Common Problems ...................................................................................... 29

Vivace_Inv_IB_31718A_E_1.28.10.indd 2 2010-1-28 13:45:09

E-3

ENGLISH



Do not pull the electric wire

or touch the power plug with

the wet hands.



Install the switch and circuit

breaker only for

air conditioner.



Use the rated current fuse.

REGARDING POWER SOURCE



Do not bend the electric wire

by force or weigh down the

air conditioner not to be out

of order.



Use the power source with

separate wiring only for air

conditioner.



If the power plug is

damaged, replace it by the

manufacturer or qualified

personnel to avoid the risk.



Do not install the unit in a

place where it is exposed to

inflammable gas leakage.



Do not install the outdoor

unit where there’s the risk of

dropping such as on high

outer wall or outside of the

terrace.



Do not connect the ground

to a gas pipe, water pipe,

lightning rod or telephone

earth.

WHEN INSTALLING



Contact the service center

if the air conditioner is

under water.



The installation must be carried out

by a licensed installer or qualified

personnel when installing the unit

for the first time or reinstalling it.

Safety Precautions

The following safety precautions are provided to protect the users’ safety and prevent property damage.

Make sure to read the followings and use the air conditioner properly.

 Keep this user’s manual together with the installation manual in a handy place so that you can find it whenever

you need to see it after reading this manual thoroughly.

WARNING

 This indicates the possibility of serious injury or death.

CAUTION

 This indicates the possibility of serious injury or damage to environments when

operated incorrectly.

Vivace_Inv_IB_31718A_E_1.28.10.indd 3 2010-1-28 13:45:14

E-4

WARNING



Do not attempt to repair,

move, modify or reinstall

the unit on your own. Make

sure that these installations

are carried out by qualified

personnel to avoid electric

shock or fire.



Never spill any kind of liquid

into the unit. Should this

happen, unplug or main

switch off the unit and

contact an authorized

service center.

DURING OPERATION



Do not place any obstacles in

front of the unit.

Make sure that the unit is

correctly ventilated at all

times: Do not place clothing

or other materials over it.



If the wireless remote

control is not used for

a long time, remove the

batteries. (If applicable)



When using a wireless

remote control, the distance

should not be more than

7 meters from the air

conditioner. (If applicable)



Do not place any materials

so that children cannot step

on it.



Do not connect the electric

heater to the air conditioner

or repair it with your

discretion.



The manufacturer declines

any liability for damage

resulting from modifications

or errors in the electrical or

hydraulic connections.



Do not insert anything

between the air outlet

blades because the inner fan

may be damaged and could

cause injury. Keep children

away from the unit.



Failure to observe the

installation instruction, or use

of the unit under conditions

other than those indicated in

the table 'Operating limit' of

the unit installation manual,

will immediately invalidate

the unit warranty.

Vivace_Inv_IB_31718A_E_1.28.10.indd 4 2010-1-28 13:45:27

E-5

ENGLISH



Before throwing out the

device, it is necessary to pull

back the battery cells and get

rid of them safely for recycling

reasons.



When you need to dispose of

the unit, consult your dealer.

If pipes are removed

incorrectly, refrigerant may

blow out and come into

contact with your skin, causing

injury. Releasing refrigerant

into the atmosphere also

damages the environments.



Please recycle or dispose

of the packaging material for

this product in an

environmentally responsible

manner.

DISPOSING THE UNIT

WARNING



Install the air conditioner

avoiding direct sunlight or

heater, especially water.



Install the outdoor unit so as

to let the discharged air out

properly. Avoid a place that

may disturb your neighbor by

noise.



Install the drain hose to let

the water run safely and

correctly.

WHEN INSTALLING

CAUTION

Vivace_Inv_IB_31718A_E_1.28.10.indd 5 2010-1-28 13:45:35

E-6



Disconnect the circuit breaker

when you don’t use the

air conditioner for a long time

to save energy.



Contact the service center or

manufacturer if you want to

repair the air conditioner.



Contact the service center

after turning off the air

conditioner if strange noise

is heard, burning smell or

smoke blow.

REGARDING POWER SOURCE



Do not open the front grille

during operation.



Avoid cold and hot air

reaching to person, pet or a

plant directly for a long time.



Avoid the water from

getting into the

air conditioner.

DURING OPERATION



Do not use the air conditioner

for a long time in a closed room

or in a place where there’s a

baby or an old person.



Do not step on the air

conditioner or put heavy

object on it.



Do not drink the water from

the air conditioner.

CAUTION

Vivace_Inv_IB_31718A_E_1.28.10.indd 6 2010-1-28 13:45:42

E-7

ENGLISH

CAUTION



Do not touch the pipes

connected to the air

conditioner.



Do not use the air conditioner

to maintain the machine, food,

pet, plant or cosmetics.



Do not give excessive shock

to the air conditioner.

DURING OPERATION



This appliance is not intended

for use by persons (including

children)with reduced physical, sen-

sory or mental capabilities, or lack of

experience and knowledge, unless

they have been given supervision

or instruction concerning use of the

appliance by a person responsible

for their safety: Children should be

supervised to ensure that they do

not play with the appliance.



The maximum input power &

current is measured

according to the IEC standard

and the input power & current

is measured according to the

ISO standard.

OTHERS



Be sure that the air filter not to

be exposed to direct sunlight.



Do not clean the air

conditioner by spraying water

directly or with benzene,

thinner or alcohol.



The surface of the heat

exchanger is sharp, so be

careful of it when cleaning.



Turn off the air conditioner

and if the fan stops to operate,

clean the air conditioner.



Clean the air filter every 2 weeks.



Be sure to insert the air filter.

When opening or closing the

front panel, use a stable stool

and watch your steps care-

fully.



All of the manufacturing and

packaging materials used for your

new appliance are compatible

with the environment and can be

recycled.



Dispose of the packaging

material in accordance with

the local requirements.

Vivace_Inv_IB_31718A_E_1.28.10.indd 7 2010-1-28 13:45:49

E-8

Name of Each Part

The design and shape can be changed according to the model.

Indoor Unit

Air Inlet

Room

Temperature sensor

Power(On/Off)

button

Air filter

(under the panel)

mode indicator

Auto cleaning indicator

Operation indicator

Timer/

mode indicator

Set temperature &

room temperature

Airflow blade

(outlet)

Vivace_Inv_IB_31718A_E_1.28.10.indd 8 2010-1-28 13:45:56

E-9

ENGLISH

Name of Each Part

Outdoor Unit AQV09VBSeries

Air Outlet

Connection Valve

(Inside)

Air Inlet (Rear)

AQV12VBSeries

AQV18VBSeries

Air Outlet

Air Inlet (Rear)

Connection Valve

(Inside)

Outdoor Unit

Power(On/Off)

button

mode indicator

Auto cleaning indicator

AQV24VBSeries

Outdoor Unit

Air Outlet

Connection Valve

Air Inlet (Rear)

Vivace_Inv_IB_31718A_E_2.24.10.indd 9 2010-2-24 16:58:03

E-10

Remote Control-Buttons and Display

Temperature setting

Mode selection button

(Auto, Cool, Dry, Fan, Heat)

Battery life indicator

Fan speed indicator

Off Timer button

On Timer button

Power (On/Off) button

mode indicator

Turbo button

Energy saving button

mode indicator

Swing button

Digital On/Off button

Time adjustment button

Note

Digital On/Off button

If you want to turn on or off the

Display of the indoor unit during

operation, press the button

on the remote control.

Airflow direction indicator

Off Timer indicator

Silence indicator

Turbo function indicator

Temperature adjustment

buttons

Operating mode indicator

(Auto, Cool, Dry, Fan, Heat)

Energy saving indicator

Remote control

transmission indicator

On Timer indicator

Fan speed adjustment button

Auto Cleaning button

Silence button

button

mode

adjustment button

On/Off button

Timer Set/Cancel button

You must insert or replace the remote control batteries when:



You purchase the air conditioner



The remote control does not work correctly

Note



Use two AAA, LR03 1.5V batteries.



Do not use old and new batteries or different kinds of batteries

together.



Insert two batteries correctly as indicated by the + and – symbols.

1Remove the battery cover in the rear of the remote control by pushing

it with your thumb.

2Insert two batteries, respecting the polarities as indicated by

the + and - symbols.

3Close the cover by sliding it back in place.

Inserting the Remote Control Batteries

Vivace_Inv_IB_31718A_E_1.28.10.indd 10 2010-1-28 13:46:01

E-11

ENGLISH

Getting Started

The User’s Manual provides you with valuable information about your air conditioner.

In order to take full advantage of the air conditioner’s features, please read this manual

carefully before using.

You have already seen the basic description of the unit on pages from 8 to 10.

Starting with the next page, you will find a series of step-by-step procedures

for each function available.

The illustrations in the step-by-step procedures use three different symbols:

PRESS PUSH HOLD DOWN

Vivace_Inv_IB_31718A_E_1.28.10.indd 11 2010-1-28 13:46:08

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de Samsung

Samsung

Samsung AC FB4DEH Series Manual de usuario

Samsung

Samsung AW0560A Manual de usuario

Samsung

Samsung CH18CAX Manual de usuario

Samsung

Samsung AQ07A1VE Manual de usuario

Samsung

Samsung AR NXPD Series Manual de usuario

Samsung

Samsung AEX160EDEHA Manual de usuario

Samsung

Samsung AC RNNDKG Series Manual de usuario

Samsung

Samsung AC BNJDCH Series Manual de usuario

Samsung

Samsung AQ07A1AE Manual de usuario

Samsung

Samsung ASK09D2VE Manual de usuario

Samsung

Samsung AM TNVD Series Manual de usuario

Samsung

Samsung AQ09FBX Manual de usuario

Samsung

Samsung US12PGGB Manual de usuario

Samsung

Samsung AW05N0 Series Manual de usuario

Samsung

Samsung AS07A5(A6)MA Manual de usuario

Samsung

Samsung SH07ZP2 Series Manual de usuario

Samsung

Samsung AM080*XV Series Manual de usuario

Samsung

Samsung AC BXAP G Series Manual de usuario

Samsung

Samsung AS09P8GB Manual de usuario

Samsung

Samsung AC180JXA NH Series Manual de usuario

Samsung

Samsung AS12A1VC Manual de usuario

Samsung

Samsung SH18BP6 series Manual de usuario

Samsung

Samsung MH24ZA1-12 Manual de usuario

Samsung

Samsung AR18NSWXCWKNCV Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario

Webasto

Webasto Frigo Top 25 DS Manual de usuario

Frigidaire

Frigidaire FAZ12ES2A Manual de usuario
