OPTIMA!ZigBee!Thermostat!

Quick!Start!Guide

LET’S&GET&STARTED.&

Make sure you have the following items:

Thermostat with

Mounting Plate

Trim plate

Screws and Anchors

Wire Labels

2 x AA alkaline

batteries

User’s Manual

Quick Start Guide

Turn&off&the&heating&and/or&cooling&

Turn OFF the breakers or remove the fuses to the heating and/or cooling

systems at the electrical panel.

In some regions, there may be a switch located near the furnace.

Determine&wiring&configuration&

•Remove the old thermostat to expose

the wiring terminals.

•Take a picture of the wiring for future

reference.

•Note the terminals attached to each

wire and attach the matching label to

the ends of the wires. Use the following

table as a reference.

* A jumper connects RC and RH as most combination heat and cooling systems use a

single transformer. For systems where separate transformers are used, remove the

jumper in place across the RC and RH terminals.

Optima Thermostat Wiring Reference

Gas, Electric, or Oil (non-HP)

Heat Pump (HP)

R or RC*

24 VAC for Cooling system

R or RC*

24 VAC for Cooling system

RH*

24 VAC for Heating system

RH*

24 VAC for Heating system

24 VAC common return

Reserved

System monitor

Y or Y1

Single / 1st stage cooling

Y or Y1

Single / 1st stage compressor

2nd stage cooling

2nd stage compressor

W or W1

Single / 1st stage heating

W or W1

Emergency heat

2nd stage heating

O/B

Changeover valve

Fan signal

Reserved

Remove&old&thermostat&terminals&

Remove the old thermostat wiring terminals

from the wall, taking care not to allow the

wiring to fall inside the wall.

Install&Mounting&Plate&

Remove the Mounting Plate from the back of

the Optima thermostat. Use the included wall

anchors and screws to attach the Mounting

Plate to the wall, making sure the wires run

through the center opening. Use the Trim Plate

vertically or horizontally if desired.

Attach&Wiring&

Before attaching the wires, match the wire

(using the labels) to its corresponding

terminal. Refer to the picture of the wiring

taken earlier if necessary.

•Open the terminal by lifting the latch up.

•Push each wire into the hole of the

terminal and push the latch down to

secure the wire.

TIP:!Wrap! the! wire! ends!

around!a!long!stick,!such!as!

a! pencil! to! keep! the! wires!

from!falling!into!the!wall.!

Install&Batteries&

Insert the alkaline batteries into the back of the

thermostat. Make sure the polarity of the

batteries is correct. After inserting the batteries,

the display will flash all the segments, followed by

the version number of the firmware, then display

US / CA with a blinking US.

Initial&Configuration&

When configuring the thermostat, press the + or – button or use the slider

ring to cause the desired value to blink, then press MODE to select the value.

Using the table at right,

select the country, then

the type of system.

After this configuration,

the thermostat will

display the Home

Screen, and be ready

for attachment to the

Mounting Plate.

Value

Description

United States – Configures thermostat for

use in the US.

Canada – Configures thermostat for use

in Canada

Heat Pump

NON-HP

Non Heat Pump – Gas, electric, or oil heat

Heat Pump with O reverse valve

Heat Pump with B reverse valve

FAN HE

Non-HP: Electric or Oil Heat

FAN HG

Non-HP: Gas Heat

Attach&Thermostat&To&Mounting&Plate&

Attach the thermostat to the Mounting Plate

by aligning the connector pins and the plastic

retention posts and pushing the thermostat

onto the Mounting Plate.

Make sure the connector pins are not bent

and that the thermostat is fully seated on

the Mounting Plate.

Turn&Power&Back&On&To&The&

HVAC&System&

Go to the electrical service panel or

furnace switch and turn the HVAC

system back on.

Configure&Thermostat&

The thermostat can now be used as a basic local thermostat. To enable the

enhanced features, additional settings need to be configured, such as pairing

with a connected home system. See the Configuring the Thermostat section in

the User’s Manual for more details.

SALUS&WARRANTY&

Salus Controls Inc. (“Salus”) warrants that for a period of two (2) years

(“Warranty Period”) from the date of purchase by the consumer (“Customer”),

this device, excluding batteries (“Product”), shall be free of defects in

materials and workmanship under normal use and service in accordance

with all supplied instructions. During the warranty period, Salus shall, at its

option, repair or replace any defective Products, at no charge for the device.

Any replacement and/or repaired devices are warranted for the remainder of

the original Warranty Period or ninety (90) days, whichever is longer.

This warranty does not cover removal or reinstallation costs. This warranty

does not apply to any Product (i) which has been modified, repaired, or

altered, except by Salus or an authorized Salus representative, (ii) which has

not been maintained in accordance with any handling or operating

instructions supplied by Salus, or (iii) which has been subjected to unusual

physical or electrical stress, misuses, abuse, negligence or accidents.

This warranty is the only express warranty Salus makes for the Product. Any

implied warranties, including warranties of merchantability or ﬁtness for a

particular purpose, are limited to the Warranty Period or the shortest period

allowed by law.

SALUS SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE OF ANY KIND,

INCLUDING ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING, DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF ANY

WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF THIS

PRODUCT. Some states and provinces do not allow the exclusion or

limitation of incidental or consequential damages, or limitation on the

duration of implied warranties of merchantability or ﬁtness, so these

exclusions or limitations may not apply to you.

No oral or written information or advice given by Salus or a Salus-authorized

representative shall modify or extend this warranty. If any term is held to be

illegal or unenforceable, the legality or enforceability of the remaining terms

shall not be affected or impaired.

Customer’s sole and exclusive remedy under this limited warranty is product

repair or replacement as provided herein. If a Product under warranty is

defective, the Customer may:

•contact the party (“Seller”) from which the Customer purchased the

Product to obtain an equivalent replacement product after the Seller has

determined that the Product is defective and the Customer is eligible for

a replacement, or,

•contact Salus Service at 4700 Duke Drive, Suite 200, Mason, OH 45040,

to determine whether the device qualifies for a replacement. If a

replacement is warranted and is shipped prior to the return of the

device under warranty, a credit card is required and a hold may be

placed on the Customer’s credit card for the value of the replacement

until the returned device is verified as eligible for replacement, in which

case, the Customer’s credit card will not be charged.

This warranty gives you speciﬁc legal rights, and you may also have other

rights that vary from jurisdiction to jurisdiction. If you have any questions

regarding this warranty, please write Salus at:

123 Townsend St. Level LL2

San Francisco, CA 94107

FCC&Statements&

WARNING: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy, and if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.
