MANUAL
GPS-TRACKER 11 WITH ONLINE LOCATING
Thank you very much for purchasing our
GPS Tracker 11.
Before starting you should read the manual.
Please keep the manual for reference
purposes.
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
2
Inhaltsverzeichnis
1. Scope of supply.............................3
2. Product Graphics...........................4
2.1. Activation.........................................5
2.2. Switch on.........................................6
2.3. Use..................................................7
2.4. Meaning of the LED lights...............8
3. Technical Details.......................... 10
5. Note to the disposal of used
batteries........................................ 19
6. Note for the disposal of electronic
devices..........................................21
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
3
1. SCOPE OF SUPPLY
The scope of supply is:
GPS-Tracker 11 from Salind
M2M-SIM card
USB charger
Note: You can download the recent manual
here:
www.salind-
gps.de/bedienungsanleitung
We wish you fun with your GPS tracker!
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
4
2. PRODUCT GRAPHICS
LED signals
Battery connection
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
5
2.1. Activation
To use the tracker you have to activate it
online. You have to use the software of PAJ
GPS for this.
Go to the following link
start.finder-portal.com
and follow the instructions
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
6
2.2. Switch on
As soon as you have activated your tracker,
you can start it.
To switch it on you have to press the on/off-
button for at least three seconds. Please
charge the GPS tracker before the first use.
It is recommended that you start your GPS
tracker for the first time on locations which
are not covered.
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
8
2.4. Meaning of the LED lights
Orange LED - GSM Status
SIGNAL
MEANING
The orange
LED is on
GSM signal is available
The orange
LED sparkles.
GSM signal is not
available. The tracker is
searching for signal.
Blue LED - GPS Status
SIGNAL
MEANING
The blue LED
sparkles
No GPS access. The
tracker searches for signal.
The blue LED is
constantly
sparkling.
GPS access is available.
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
9
Red LED - Batteriestatus
SIGNAL
MEANING
The red LED is
constantly
sparkling
Device is loading.
The red LED
sparkles
Device is on.
GPS-Tracker 11 with online locating EN
© PAJ UG (haftungsbeschränkt)
10
3. TECHNICAL DETAILS
Measures
109mm x 76mm x 26mm
GPS accuracy
Up to 5 Meter
Battery
3,7V 10.000mAh Li-ion
Time till start
Cold start: 45s
Standby: 35 s
In use:10 s
Weight
315g
Network
GSM/GPRS
Band
GSM 850 MHz (max. 2W)
GSM 900 MHz (max. 2W)
DCS 1800 MHz(max. 1W)
PCS 1900 MHz(max. 1W)
GPS-Chip
UBLOX 7020
GSM-/GPRS-
Modul
MTK6261
GPS access
-159 dBm
Storage
temperature
from -40 °C to +75 °C
Operating
environment
From -10 °C to +55 °C
