SAGEMCOM Bell Manual de usuario

Reference

Guide

Table of contents

The Connection Hub...........................................................................................................3

Setting up a wireless connection...............................................................................4

Connecting a USB device to the Connection Hub...........................................7

Setting an admin password .........................................................................................11

Modifying the Connection Hub settings...............................................................12

Updating Internet user ID and access password...........................................16

Restart the Connection Hub.........................................................................................17

Reset the Connection Hub ............................................................................................17

Frequently asked questions.........................................................................................18

Bell

Mail

My Bell profile

The Connection Hub

LED lights

Buttons

Wireless

WPS

Power

HPNA

WAN

Internet

Wireless

WPS

Setting up a wireless connection

There are two ways that you can set up your wireless Home Network

connection.

Primary wireless network

Connect to the Internet and shared devices connected to your home

network through the Connection Hub. The wireless SSID (Network name)

and WPA2 password on the back of your Connection Hub are used for the

“Primary” wireless network.

Guest wireless network

Enables you to provide Internet access to guests and/or visitors but

prevents access to any of your shared documents on your home network.

An additional benefit is that you can preset the duration that you want the

Guest wireless network to be active before it automatically switches off.

By default, this feature is turned off. See page 14for more details on

configuring this feature.

Follow these instructions to activate your Primary wireless Home

Networking connection.

Using Wi-Fi protected setup (WPS)

If your wireless client is equipped with a WPS push button, you may use it

to connect using the WPS button on the Connection Hub. This will allow

you to securely connect your computer to your wireless network without

having to setup any passwords. Note that this method will work even if

you have changed any passwords on your Connection Hub.

To do this:

•

Ensure both the Connection Hub and your computer are powered on.

Press and hold down the WPS button

on the front of the

Connection Hub until the WPS light starts blinking.

Your Connection Hub will search for a wireless client. Note: If the

Connection Hub does not find a wireless client within 2 minutes, it will

stop searching. Therefore, you will have to complete the next step

within 2 minutes.

On your wireless client, please hold down the WPS button for 5-10

seconds before releasing.

The password for your Primary wireless network will automatically be

loaded onto your wireless client.

•

Note: If you are experiencing difficulties, ensure you use the utilities in

Windows for connecting to wireless networks and not the software that

comes with your wireless client.

Windows 7

•

Click on the wireless bar located to the right of the system bar.

The list of available wireless networks appears with your network

name. Click Refresh network list if it does not appear.

Select your network name, and click Connect.

Either type your 8-digit WPA2 key (see back of Connection Hub) in

the Security key box, and click OK

•

You can hold down the WPS button

on the Connection Hub for

5-10 seconds. The Connection Hub will automatically connect the

computer to the network and apply any wireless security settings.

Windows Vista

•

Click Start, then Connect to.

Your network name will appear. If not, click the two arrows in the top

right corner.

Type your 8-digit WPA2 key in the Security key or Passphrase text

box.

Click Connect.

•

Windows XP

•

Click the wireless networks detected message or double-click the icon

in your system tray.

Your network name will appear. Double click it.

In the wireless network connection box, type in your 8-digit WPA2

key.

Click Connect.

•

Mac 10.4 –10.6

•

Click on the Airport icon.

Your network name will appear. If not, click the Airport icon again.

Click on your network name in the list.

Type your 8-digit WPA2 key in the Password text box.

Click OK.

Connecting a USB device to the

Connection Hub

Storage Devices

Share files within your home network by connecting a USB storage device

(i.e. flash drive, external hard drive, etc.) to the Connection Hub. All users

connected to the home network will be able to see, add, modify and delete

any files on the attached device (except when connected via Guest

wireless).

Once a USB storage device is connected, to access the files follow these

steps:

For Windows Users:

Connect the USB Storage device to the Connection Hub.

Open Windows Explorer. Click on Start, then All Programs, then

Accessories and select Windows Explorer.

Type \\mynetwork into the address bar of Windows Explorer.

You can now view your connected USB storage device.

For Mac Users:

Connect a USB storage device to the Connection Hub.

On your Mac, click Go and then Connect to Server.

Type smb://mynetwork under Server Address.

Click on Connect.

You will be asked for your Mac Password. Enter it and then click on

Connect.

A window will appear with the contents of your USB drive.

Until the USB storage device is ejected from the Connection Hub, you

will be able to locate the device under Computer.

NOTE: To safely disconnect a USB storage device, you must first click the

Eject button in the Connection Hub Graphical user Interface to protect the

data.

Mapping your USB Storage Device:

You can map your USB storage device to your computer which will enable

you to see the USB device listed within your My Computer folder, even after

the computer has been rebooted.

Once you have mapped the device, your Computer folder will show your

USB storage device similar to this:

To Map a Storage Device to the Connection Hub:

Windows 7:

Go into the Computer folder and locate Map network drive on the top

menu.

In the window that pops up, type in the Folder textbox:

\\mynetwork\YOUR_USB_NAME, where YOUR_USB_NAME corresponds

to the name of your USB device. Your USB name can be found in

My Computer if it is plugged into your computer.

Windows Vista:

See instructions for Windows 7.

Windows XP:

Right click on My Computer and select Map network drive.

In the window that pops up, type in the Folder textbox:

\\mynetwork\YOUR_USB_NAME, where YOUR_USB_NAME corresponds

to the name of your USB device. Your USB name can be found under

My Computer if it is plugged into your computer.

Printers

Share a USB printer on the home network by connecting it to the

Connection Hub. All computers connected to the home network will have

access to the printer.
