Sage Nutri Juicer SJE410 Manual de usuario

the User Guide

B###### / S######

EN USER GUIDE

FR GUIDE UTILISATEUR

IT MANUALE UTENTE

PT MANUAL DO UTILIZADOR

DE HANDBUCH

NL HANDLEIDING

ES GUÍA DEL USUARIO

PL INSTRUKCJA OBSŁUGI

CONTENTS

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage®we are very safety

conscious.We design and

manufacture consumer

products with the safety

of you, our valued customer,

foremost in mind. In addition

we ask that you exercise

a degree of care when using

any electrical appliance

and adhere to the following

precautions.

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE FOR

FUTURE REFERENCE

• A downloadable version of this

document is also available

at sageappliances.com

• Before using for the rst time

ensure your electricity supply

is the same as shown on the

label on the underside of the

appliance.

• Remove and safely discard any

packaging materials before rst

use.

• To eliminate a choking hazard

for young children, safely

discard the protective cover

tted to the power plug.

• This appliance is for household

use only. Do not use the

appliance for anything other

than its intended use. Do not

use in moving vehicles or boats.

Do not use outdoors.Misuse

may cause injury.

• Fully unwind the power cord

before operating.

• Position the appliance on a

stable, heat resistant, level, dry

surface away from the edge and

do not operate on or near a heat

source such as a hot plate, oven

or gas hob.

2Sage®Recommends Safety First

6Components

7Assembly

9Operation

10 Care & cleaning

12 Troubleshooting

14 Guarantee

WE RECOMMEND SAFETY FIRST

• Vibration during operation may

cause the appliance to move.

• Do not let the power cord hang

over the edge of a bench or

table, touch hot surfaces or

become knotted.

• Always ensure the appliance

is turned OFF, unplugged at

the power outlet and has been

allowed to cool before cleaning,

attempting to move or storing.

• Do not use the appliance if the

power cord, plug, or appliance

becomes damaged in any way.

If damaged or maintenance

other than cleaning is

required, please contact Sage

Customer Service or go to

sageappliances.com

• Any maintenance other than

cleaning should be performed

by an authorised Sage®service

centre.

• The installation of a residual

current safety switch is

recommended to provide

additional safety when using all

electrical appliances.

Safety switches with a rated

operating current not more

than 30mA are recommended.

Consult an electrician for

professional advice.

• Always ensure the appliance is

properly assembled before use.

The appliance will not operate

unless properly assembled.

• Do not use the appliance on

a sink drain board.

• Keep hands, ngers, hair,

clothing as well as spatulas

and other utensils away from

moving or rotating parts during

operation.

• Do not use the appliance for

anything other than food and/or

beverage preparation.

• In order to avoid the possible

hazard of the appliance starting

by itself due to inadvertent

resetting of the overload

protection, do not attach an

external switching device (such

as a timer) or connect the

appliance to a circuit that can

regularly switch the appliance

on and o.

• Carefully read all instructions

before operation and save for

future reference.

• This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge

if they have been given

supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

• Children shall not play with the

appliance.

WE RECOMMEND SAFETY FIRST

• Cleaning and user maintenance

shall not be made by children

without supervision.

• Switch o the appliance

and disconnect from the

power outlet before changing

accessories or approaching

parts that move or in use.

• Do not use the appliance if the

rotating sieve or the protective

cover is damaged or has visible

cracks.

• Always turn the appliance to

the OFF position, switch o at

the power outlet and unplug

at the power outlet when the

appliance is not in use.

• Always disconnect the

appliance from the power

outlet when it is left unattended

and before assembling,

disassembling or cleaning.

• The maximum operating time is

15 minutes.The maximum load

is 5kg beetroot at a time.

• This appliance shall not be used

by children. Keep appliance and

its cord out of reach of children.

• Do not leave the appliance

unattended when in use.

• Do not push food into the feed

chute with your ngers or other

utensils. Always use the food

pusher provided. Do not place

hand or ngers into the food

chute when it is attached to the

appliance.

• Do not juice stone fruit unless

seeds and/or stones have been

removed.

• Do not operate the juice

extractor without the pulp and

juice container in place.

• An example of the heaviest

loading anticipated for use with

this juices is 5kg of beetroot,

juiced continuously over

a period of 2 minutes.

• Make sure the stainless steel

lter basket has stopped

rotating and the motor has

completely stopped before

releasing the safety locking

arm and/or attempting to

move the appliance, when the

juicer is not in use, and before

disassembling, cleaning and

storing.

• Any signicant spillage onto

the surface under or around the

appliance, or onto the appliance

itself, should be cleaned and

dried before continuing to use

the appliance.

• Be careful when handling the

stainless steel lter basket as

the small cutting blades at the

base of the lter basket are very

sharp. Mishandling may cause

injury.

• Remove rind from all citrus fruit

before juicing.

• Do not use the appliance if the

rotating sieve (lter basket) or lid

is damaged.

• Always make sure juicer cover

is clamped securely in place

before motor is turned on.

Do not unfasten interlock arm

while juicer is in operation.

The symbol shown

indicates that this

appliance should not be

disposed of in normal

household waste. It should be

taken to a local authority waste

collection centre designated

for this purpose or to a dealer

providing this service.For more

information, please contact your

local council oce.

To protect against electric

shock, do not immerse the

power plug, cord or appliance

in water or any liquid.

SAVE THESE INSTRUCTIONS

WE RECOMMEND SAFETY FIRST

COMPONENTS

A. Food pusher

B. Unique Direct Central Feed System

C. Extra wide 84mm feed chute

D. Stainless steel titanium reinforced

micro mesh lter basket

E. Large capacity pulp container

(dishwasher safe).

F. Heavy duty motor

G. Cord storage

H. Interlocking safety arm

I. Juicer cover

(not dishwasher safe).

J. Filter bowl surround

(dishwasher safe).

K. 1 litre juice jug and lid

(dishwasher safe).

L. 2 speed electronic control ON / OFF

switch

Rating Information

220–240V ~ 50–60Hz 1050–1250W

BEFORE FIRST USE

Before using your juicer for the rst time, remove

and safely discard any packaging materials and

promotional stickers and labels.

Ensure the appliance is switched o at the power

outlet and the power cord is unplugged.

Wash the lter bowl surround, lter basket,

juicer cover, food pusher, pulp container and

juice jug and lid in warm, soapy water with a soft

cloth. Rinse and dry thoroughly.The motor base

can be wiped with a damp cloth. Dry thoroughly.

1. Place motor base on a at, dry surface such

as a bench top. Ensure that the motor base

is switched OFF at the control panel, then

switch the appliance o at the power outlet

and unplug the power cord.

2. Place lter bowl surround on top of the motor

base.

3. Align the arrows at the base of the stainless

steel lter basket with the arrows on the motor

drive coupling and push down until it clicks

into place. Ensure the stainless steel lter

basket is tted securely inside the lter bowl

surround and onto the motor base.

4. Place the juicer cover over the lter bowl

surround, positioning the feed chute over the

stainless steel lter basket and lower into

position.

5. Raise the safety locking arm up and locate

into the two grooves on either side of the

juice cover.

ASSEMBLY

The safety locking arm should now be in

a vertical position and locked into place on

top of the juice cover.

6. Slide the food pusher down the food chute

by aligning the groove in the food pusher,

with the small protrusion on the inside of the

top of the feed tube.

Continue to slide the food pusher down on

the feed chute.

Food

Pusher

Groove

Small

Protrusion

Inside Feed

Tube

7. Place the pulp container into position by

tilting the motor base slightly to the right.

Insert the pulp container under the juicer

cover on the left hand side ensuring it is

supported by the juicer cover and

motor base.

NOTE

To minimise cleaning, line the pulp container

with a plastic freezer bag to collect the pulp.

Pulp can be used in other dishes, or as

a compost for the garden or discarded.

8. Place the juicer jug under the juice spout on

the right hand side of the juicer.The juice jug

lid can be used to avoid any splatter.

OPERATION

1. Wash your selection of fruit and vegetables

to be juiced.

2. Ensure the juicer is correctly assembled.

Refer to Assembling your Sage®juicer.

Ensure the juicer jug is placed under the

juice spout and pulp container is in position

before commencing juicing.

3. Plug the power cord into a 220–240V power

outlet.Turn the power ON at the power outlet.

Adjust the speed to the desired setting.

Push the two speed switch either up for low

speed or down for high speed depending on

the type of fruit or vegetable being juiced.

Use the speed selector as a guide for juicing

dierent fruits and vegetables.

SPEED SELECTOR TABLE

Apples High

Apricots (stone removed) Low

Beetroot (trimmed) High

Blueberries Low

Broccoli Low

Brussels sprouts (trimmed) High

Cabbage Low

Carrots High

Cauliower Low

Celery High

Cucumber (peeled) Low

Cucumber, soft skinned High

Fennel High

Grapes (seedless) Low

Kiwi Fruit (peeled) Low

Mangoes (peeled, stone

removed) Low

Melons (peeled) Low

Nectarines (stone removed) Low

Oranges (peeled) High or Low

Peaches (stone removed) Low

SPEED SELECTOR TABLE

Pears (stalks removed) High for hard or

Low for soft

Pineapple (peeled) High

Plums (stone removed) Low

Raspberries Low

Tomatoes Low

Watermelon (peeled) Low

4. With the motor running, place food into the

feed chute and use the food pusher to gently

guide food down. To extract the maximum

amount of juice, always push the food pusher

down slowly.

NOTE

The motor must be running prior to loading

the feed chute.

WARNING

Never use ngers to push food down

the feed chute or to clear the feed

chute. Always use the food pusher

provided.

WARNING

The stainless steel lter basket contains

small sharp blades to cut and process

fruit and vegetables. Avoid touching the

blades when handling the lter basket.

Filter Basket

Caution:

Sharp Blades

CARE & CLEANING

Ensure the juicer is turned o by switching the

ON / OFF button on the control panel to OFF.

Then switch the appliance o at the power

outlet and unplug the power cord.

Ensure the juicer is correctly disassembled.

Refer to Disassembling your new appliance.

FOR EASIER CLEANING:

• Clean as you go and avoid dried on juice

or pulp residue.

• Immediately after each use, rinse removable

parts in hot water to remove wet pulp. Allow

parts to air dry.

NOTE

To minimise cleaning, line the pulp container

with a plastic freezer bag to collect the pulp.

Pulp can then be used for other dishes, or as

compost for the garden or discarded.

CLEANING THE MOTOR BASE

• Wipe the motor base with a soft, damp cloth

then dry thoroughly.

• Wipe any excess food particles from the

power cord.

NOTE

Do not use abrasive scouring pads or

cleaners when cleaning the parts or motor

base as they may scratch the surface.

CLEANING THE FILTER BOWL

SURROUND, JUICER COVER,

FOOD PUSHER, PULP CONTAINER

Wash all parts in warm soapy water with a soft

cloth. Rinse and dry thoroughly.

NOTE

The lter bowl surround, juicing jug and

lid, food pusher and pulp container, are

dishwasher safe (top shelf only).The juice

cover is not dishwasher safe.

CLEANING THE FILTER BASKET

• For consistent juicing results always

ensure that the stainless steel lter basket

is thoroughly cleaned using the supplied

cleaning brush. It is important to do this

immediately after use.

• Soak the stainless steel lter basket in hot

soapy water for approximately 10 minutes

immediately after juicing is completed. If pulp

is left to dry on the lter it may clog the ne

pores of the lter mesh thereby lessening the

eectiveness of the juicer.

• Using the cleaning brush, hold the lter

basket under running water and brush from

the inside of the basket to the outer rim.

Avoid touching the small sharp blades in

the centre of the lter basket. Repeat this

process on the outside of the basket. After

cleaning the lter basket, hold it up towards

a light to ensure the ne mesh holes are not

blocked. If the holes are blocked, soak the

lter basket in hot water with 10% lemon

juice to loosen the blocked holes. Repeat the

cleaning process using the cleaning brush.

Alternatively, wash the lter basket in the

dishwasher.

Otros manuales para Nutri Juicer SJE410

Tabla de contenidos

Idiomas:

Otros manuales de Exprimidor de Sage

Sage

Sage Nutri Juicer BJE410 Manual de usuario

Sage

Sage the Big Squeeze BJS700 Manual de usuario

Sage

Sage Citrus Press BCP600 Manual de usuario

Sage

Sage Nutri Juicer Cold BJE430 Manual de usuario

Sage

Sage Nutri Juicer Pro BJE820UK Manual de usuario

Sage

Sage Nutri Juicer Cold BJE430 Manual de usuario

Sage

Sage Nutri Juicer Cold BJE430 Manual de usuario

Sage

Sage Nutri Juicer SJE410 Manual de usuario

Sage

Sage Nutri Juicer Plus BJE520 Manual de usuario

Sage

Sage the Citrus Press Pro SCP800 Manual de usuario

Sage

Sage Nutri Juicer Classic SJE95 Manual de usuario

Sage

Sage Fresh & Furious SBL620 Manual de usuario

Sage

Sage BJE520UK Manual de usuario

Sage

Sage the 3X Bluicer Pro BJB815 Manual de usuario

Sage

Sage Nutri Juicer Cold Plus Manual de usuario

Sage

Sage the Citrus Press Pro SCP800 Manual de usuario

Sage

Sage Big Squeeze SJS700 Manual de usuario

Sage

Sage the Nutri Juicer Cold XL Manual de usuario

Sage

Sage the Nutri Juicer Cold XL BJE830 Manual de usuario

Sage

Sage BJB615 Manual de usuario

Sage

Sage Citrus Press BCP600 Manual de usuario

Sage

Sage Citrus Press Pro 800CP Manual de usuario

Sage

Sage Nutri Juicer Cold XL SJE830 Manual de usuario

Sage

Sage Citrus Press Pro 800CP Manual de usuario

Manuales populares de Exprimidor de otras marcas

GE 169201 Manual de usuario

Exquisit

Exquisit ZP 3001 WET Manual de usuario

Philips

Philips HR1851 Manual de usuario

Sam Cook

Sam Cook MASTERCHEF EXECUTIVE PSC-50 Manual de usuario

Termozeta

Termozeta spremiagrumi Manual de usuario

ElectrIQ

ElectrIQ WF1000 Manual de usuario

Bella

Bella WHOLE FRUIT JUICER Manual de usuario

HAEGER

HAEGER Little Juice CJ-025 006A Manual de usuario

Havells

Havells Fusion Manual de usuario

Siemens

Siemens MK554 SERIES Manual de usuario

Beper

Beper 90.302B Guía rápida

NATURSAFT

NATURSAFT 015.401.3 Manual de usuario

Moulinex

Moulinex BKB 2 Manual de usuario

Royal Catering

Royal Catering RCJU-01 Manual de usuario

camry

camry CR 4002 Manual de usuario

AIGOSTAR

AIGOSTAR 30HIM Manual de usuario

ZUMEX

ZUMEX MINEX Manual de usuario

Skymsen

Skymsen EX Manual de usuario
