Sage Smart Grinder Pro Manual de usuario

SCG820

the Smart Grinder™Pro

OPERATING YOUR NEW APPLIANCECONTENTS

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage®we are very safety

conscious. We design and

manufacture appliances with

your safety foremost in mind.

In addition, we ask that you

exercise a degree of care

when using any electrical

appliance and adhere to the

following precautions.

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE

FOR FUTURE REFERENCE

• The full information

book is available at

sageappliances.com

• Before using the rst time

ensure your electricity

supply is the same as

shown on the label on the

underside of the appliance.

• Remove and safely discard

any packaging materials

before rst use.

• To eliminate a choking hazard

for young children, safely

discard the protective cover

tted to the power plug.

• This appliance is for household

use only. Do not use the

appliance for anything other

than its intended use. Do not

use in moving vehicles or

boats. Do not use outdoors.

Misuse may cause injury.

• Fully unwind the power cord

before operating.

• Position the appliance on a

stable, heat resistant, level, dry

surface away from the edge

and do not operate on or near

a heat source such as a hot

plate, oven or gas hob.

• Do not let the power cord hang

over the edge of a bench or

table, touch hot surfaces or

become knotted.

2 We recommend safety rst

5 Know your new appliance

6 Operating your new appliance

11 Care & cleaning

12 Troubleshooting

OPERATING YOUR NEW APPLIANCE

• Do not leave the appliance

unattended when in use.

• Always ensure the appliance

is turned OFF, unplugged at

the power outlet and has been

allowed to cool before cleaning,

attempting to move or storing.

• Always turn the appliance to

the o position, switch o at

the power outlet and unplug

at the power outlet when the

appliance is not in use.

• Do not use the appliance if the

power cord, plug, or appliance

becomes damaged in any way.

If damaged and maintenance

other than cleaning is required

please contact Sage

Customer Service or go

to sageappliances.com

• Any maintenance other

than cleaning should be

performed by an authorised

Sage®service centre.

• Children should not play with

the appliance.

• Cleaning of the appliance

should not be carried out by

children unless they are 8 year

or older and supervised.

• The appliance and it’s

cord should be kept out

of reach of children aged

8 years and younger.

• The installation of a residual

current safety switch is

recommended to provide

additional safety when using

all electrical appliances.

Safety switches with a rated

operating current not more than

30mA are recommended.

Consult an electrician for

professional advice.

• Do not use attachments

other than those provided

with the appliances.

• Do not attempt to operate

the appliance by any

method other than those

described in this booklet.

• Do not move the appliance

whilst in operation.

• Do not touch hot surfaces.

Allow the appliance to cool

down before moving or

cleaning any parts.

• This appliance shall not be

used by children. Keep the

appliance and its cord out of

reach of children.

WE RECOMMEND SAFETY FIRST

OPERATING YOUR NEW APPLIANCEWE RECOMMEND SAFETY FIRST

• This appliance can be used by

persons with reduced physical,

sensory or mental capabilities

or a lack of experience and

knowledge, only if they have

been given supervision

or instruction concerning

use of the appliance in a

safe way and understand

the hazards involved.

• Do not operate the grinder

without the hopper lid in position.

Keep ngers, hands, hair,

clothing and utensils away from

the hopper during operation.

The symbol shown

indicates that this appliance

should not be disposed of

in normal household waste.

It should be taken to a local

authority waste collection centre

designated for this purpose or to

a dealer providing this service.

For more information, please

contact your local council oce.

To protect against electric

shock do not immerse the

power plug, cord or appliance in

water or any liquid

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

OPERATING YOUR NEW APPLIANCE

Oii

KNOW YOUR NEW APPLIANCE

A. Bean Hopper Lid

B. Bean Hopper

C. Hardened Stainless Steel Conical Burrs

D. Backlit LCD Screen

E. GRIND AMOUNT/PROGRAM Dial

F. SHOTS/CUPS Button

G. Grind Outlet

H. Grind Tray

I. Grind Size Dial

J. START/PAUSE/CANCEL Button

K. Portalter Activation Switch

ACCESSORIES

L. Portalter Cradle 50–54mm

M. Portalter Cradle 58mm

N. Conical Burr Cleaning Brush

O. Grinds Container.

Oi - Container Cap

Oii - Container Lid

Rating Information

220–240V ~ 50-60Hz 165W

OPERATING YOUR NEW APPLIANCE

BEFORE FIRST USE

Remove and safely discard all promotional

labels and packing materials attached to

your Sage®product.

Wash hopper, cradles, grind container, container

lid and cleaning brush in warm soapy water and

dry thoroughly. Wipe exterior of grinder with a

soft damp cloth and dry thoroughly. Place grinder

on at level surface and plug power cord into

220–240V outlet and switch Power ‘ON’.

ENERGY SAVING FEATURE

The grinder will automatically switch o if not

used after 5 minutes.

ASSEMBLING YOUR SAGE SMART

GRINDER™PRO

Bean Hopper

Align tabs on the base of the bean hopper

and insert hopper into position. Turn the

bean hopper dial 90° to lock into position.

Fill with fresh coee beans and secure lid

on top of bean hopper.

GRINDING FOR ESPRESSO

COFFEE

Use single wall lter baskets when grinding fresh

coee beans. Use the ner 1–30 settings in the

ESPRESSO range.

STEP 1:

Insert the appropriate portalter cradle size. Insert

your portalter into the cradle.

PUSH

50-54mm

58mm

CRADLES

NOTE

Maximum number of shots with the cradle

inserted is 2.

PLUNGER

1 UP TO 12 CUPS

BREW METHOD

GRIND SETTING

GRIND SIZE

AMOUNT

FINE

1-30

1 UP TO 8 SHOTS

ESPRESSO DRIP FILTER

MEDIUM COARSE

46-54

COARSE

55-60

1 UP TO 12 CUPS

PERCOLATOR

31-45

1 UP TO 12 CUPS

MEDIUM

COFFEE CHART

OPERATING YOUR NEW APPLIANCE

STEP 2:

Selecting your SHOTS/CUPS

Select the desired amount of ground coee

required by pressing the SHOTS/CUPS button.

START PAUSE

GRIND AMOUNT SHOTS CUPS

CANCELPROGRAM

Rotate the Grind Amount Dial to adjust the grinding

time to achieve the correct amount of coee.

START PAUSE

GRIND AMOUNT SHOTS CUPS

CANCELPROGRAM

STEP 3:

Select your grind size

For espresso, we recommend selecting Grind Size

setting 12 as a starting point and moving the Grind

Size dial Coarser or Finer to adjust the ow of

espresso as required.

START PAUSE

GRIND AMOUNT SHOTS CUPS

CANCELPROGRAM

NOTE

If the Grind Size Dial is tight, run the grinder

by pressing the START/PAUSE/CANCEL

button while turning the Grind Size Dial.This

will release coee grounds caught between

the burrs.

GRINDING INTO GRINDS

CONTAINER OR COFFEE FILTER

STEP 1:

Remove cradle by sliding out from under the

grind outlet.

PULL

Slide in grinds container with cap open or coee

lter directly under grind outlet.

INSERT UNDER

GRIND OUTLET

OPEN CONTAINER

CAP

OPERATING YOUR NEW APPLIANCE

NOTE

Programming a custom grind amount/time

only sets it for that particular brew method.

This will not change the other Shots or

Cups settings.

Pause Function

You can pause the grinder during operation

allowing you to collapse or settle the coee

in the portalter.

• Press and release the

START/PAUSE/CANCEL button to start the

grinding operation.

• During grinding, press the

START/PAUSE/CANCEL button again

to pause the operation for 10 seconds.

• Press again within this time to resume grinding

the remaining dose.

START PAUSE

GRIND AMOUNT SHOTS CUPS

CANCELPROGRAM

PRESS & RELEASE

OPERATING YOUR NEW APPLIANCE

• Select the required amount of ground coee

by pressing the SHOTS/CUPS button.

• Press the START/PAUSE/CANCEL button to

start grinding operation.

START PAUSE

SHOTS CUPS

CANCEL

START PAUSE

SHOTS CUPS

CANCEL

FEATURES OF YOUR SAGE

SMART GRINDER™ PRO

Automatic Grinding

Grinding automatically allows you to grind

hands-free.

• Press and release either the

START/PAUSE/CANCEL button or push

the handle of your portalter once. This will

activate the PORTAFILTER SWITCH.

• Grinding will automatically stop when the

preset amount is dispensed.

START PAUSE PORTAFILTER SWITCH

PRESS & RELEASE

PUSH

OPERATING YOUR NEW APPLIANCE

ADJUSTING YOUR GRIND AMOUNT

Increasing the Grind Amount

To increase the grind amount selected, turn the

GRIND AMOUNT dial to the right.

START PAUSE

GRIND AMOUNT SHOTS CUPS

CANCELPROGRAM

Decreasing the Grind Amount

To decrease grind amount selected, turn the

Grind Amount Dial to the left.

NOTE

To RESET the grind amount/time to the default

settings, press and hold the SHOTS/CUPS

button until a long beep sounds.

Program Function

Once you have set your required dose,

you can program this time into the number

of shot(s) currently displayed on the LCD.

Press and hold the PROGRAM button,

grinder will beep twice to conrm. Only

the shot displayed will be programmed,

all other shots will remain unchanged.

START PAUSE

GRIND AMOUNT SHOTS CUPS

CANCELPROGRAM

PRESS & HOLD

Manual Grinding

Grinding manually allows you to have complete

control over how much coee is dispensed.

• Press and hold either the

START/PAUSE/CANCEL button or push

the handle of your portalter to activate the

PORTAFILTER SWITCH for as long as you

require.

• Release START/PAUSE/CANCEL button or

PORTAFILTER SWITCH and grinding will stop.

START PAUSE PORTAFILTER SWITCH

PRESS, HOLD & RELEASE

PUSH

OPERATING YOUR NEW APPLIANCE

ADJUSTING CONICAL BURRS

Some types of coee may require a wider grind range to achieve an ideal extraction or brew.

A feature of your Smart Grinder™ Pro is the ability to extend this range with an adjustable upper burr.

We recommend making only one adjustment at a time.

Hold hopper over container & turn

dial to release beans into container

Align hopper

into position

Run grinder

until empty

Remove hopperUnlock hopper

1 2 3 4 5

Move adjustable

top burr, 1 number,

coarser or finer

Remove wire

handle from both

sides of the burr

Align the number

with the handle

opening

Remove upper

burr

8877 9

Insert wire

handle from both

sides of the burr

Push upper burr

firmly into

position

Lock upper burr

Align hopper

into position

AIR TIGHT

CONTAINER

Lock hopper

Check your

extraction

Otros manuales para Smart Grinder Pro

Este manual sirve para los siguientes modelos

Otros manuales de Molinillo de café de Sage

Sage

Sage Smart Grinder Pro BCG820 Manual de usuario

Sage

Sage Smart Grinder Pro BCG820 Manual de usuario

Sage

Sage Smart Grinder Pro Manual de usuario

Sage

Sage Smart Grinder Pro SCG820 Manual de usuario

Sage

Sage Dose Control Pro SCG600 Manual de usuario

Sage

Sage SCG820 Manual de usuario

Sage

Sage Dose Control Pro BCG600 Manual de usuario

Sage

Sage Smart Grinder Pro SCG820 Manual de usuario

Sage

Sage the Dose Control Pro Manual de usuario

Sage

Sage BCG600 Manual de usuario

Sage

Sage the Smart Grinder Pro BCG820BSS Manual de usuario

Sage

Sage Smart Grinder Pro BCG820BSSUK Manual de usuario

Sage

Sage Dose Control Pro BCG600 Manual de usuario

Sage

Sage Smart Grinder Pro SCG820 Manual de usuario

Sage

Sage Dose Control Pro SCG600 Manual de usuario

Sage

Sage the Dose Control Pro Manual de usuario

Manuales populares de Molinillo de café de otras marcas

SOLAC

SOLAC All4Coffee MC6253 Manual de usuario

Teesa

Teesa TSA4011 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home HG KD 40 Manual de usuario

tomado

tomado TM-1287 Manual de usuario

Aicok

Aicok CG9220 Manual de usuario

Zelmer

Zelmer ZCG7925 Manual de usuario

Baratza

Baratza Vario Manual de usuario

Baratza

Baratza Forté Manual de usuario

Isomac

Isomac ROBY Manual de usuario

Eldom

Eldom Dott MK60 Manual de usuario

Bunn

Bunn SAFETY-FRESH 1 GPR Manual de usuario

Baratza

Baratza Forté AP Manual de usuario

FAMITEC

FAMITEC BOLD Manual de usuario

Santos

Santos SC55 Instrucciones de funcionamiento

Lumme

Lumme LU-2601 Manual de usuario

TREVIDEA

TREVIDEA Girmi MC02 Manual de usuario

Eureka

Eureka Zenith E Manual de instrucciones

Baratza

Baratza Maestro Manual de usuario
