Russound X5 Manual de usuario

AirPlay works with iPhone,

iPad, and iPod touch with iOS

4.3.3 or later, Mac with OS X

Mountain Lion, and Mac and

PC with iTunes 10.2.2 or later.

X5 installation manual is available at www.russound.com.

Setting up XStream X5

1. Unpack the X5 and all of its contents

1 X5 Controller Streamer Amplier

1 Power cord

2 Wi-Fi antennas

1 IR emitter

2. Screw the two antennas on the antennae posts as shown

Etherne

Line

eaker Ou

Powe

B 2.

eypa

Antenna

Antenn

uetoot

Optica

Coa

Digital Audio I

Subwoofe

Made in

hin

Tri

er Ou

12VD

00-240V~

z 2.5

erne

Line

peaker Ou

ohms mi

Powe

B 2.

eypa

Antenna

ptica

Digital Audio I

ubwoofe

Made in

hina

00-240

z 2.5

1/8”

4. Strip back 1/8” of the insulation on the

speaker wire and twist the end of each

wire to tighten the bundle of copper

strands.

Place the stripped end of the wire into

the appropriate terminal and collapse

the latch. Check to make sure there are

no strands of copper showing and check the security of the

wire in the connector. Between each terminal, make sure

the wire is not frayed or touching another connection.

Connect the other end of the wire to each speaker. Be careful

to maintain polarity.

Re-connect the detachable speaker terminal.

3. Remove the detachable speaker connector from the X5

1. Plug in power cable. (All other cables, including Ethernet should be disconnected.) Locate and turn on power switch near AC

inlet on the back of the X5. The XStream X5 will turn on to Access Point Mode. Wait for yellow and green lights to be solid.

Like other Wi-Fi enabled devices, Access Point Mode will allow you to directly connect to the X5 via Wi-Fi.

Refer to the sticker on bottom of X5 to nd host name.

Connecting XStream X5 to your home network

2. Find hostname in wireless access point list on mobile device and connect.

Sticker example:

Only Minutes to Music….

Congratulations and thank you for purchasing the Russound XStream X5. In just a few minutes, you will be

enjoying listening to your favorite personalized stations; music, sports, news, talk, comedy, concerts and

podcasts. All from Pandora®, TuneIn®, SIRIUS/XM® and vTuner®. Let’s get started.

3. Open browser on mobile device or laptop. For iOS (Safari browser), browse to http://XStrmX5-XXXXXX. local.

Again reference sticker on bottom of unit to nd host name.

Alternatively, for other browsers, browse to http://192.168.253.2

Connecting to a wired network:

To connect to a wired network, de-select “Enable Wi-Fi” and press continue.

Attach Ethernet cable. The X5 will reboot in wired mode.

Connecting to a wireless network:

To connect to a wireless network, pick the desired network from the list of available Wi-Fi networks. If the Wi-Fi network does

not broadcast its SSID, you can also manually setup a wireless network by selecting “Add Wi-Fi” from the list.

Connecting to a wireless network (cont'd)

Enter security information and press connect. On conrmation screen, press continue. The X5 will now connect to the new network,

wait for green LED to turn on solid. If yellow LED begins to blink the X5 could not connect to the specied network.

See instructions on page 7 for the Re-initializing Access Point Mode.

Follow the steps shown in the dialog box below

Setting AirPlay name

Once connected to the home network, you can set the AirPlay name by changing the “Device Name”eld on the

“Stream Settings”page. To view the Stream Settings page, select Administration then Stream Settings.

The XStream X5 can be fully congured using Russound SCS (SCS-C5) conguration software.

SCS software oers zone customization, local source set up, IR management and power management options.

SCS is available to registered dealers only via download on the Russound Dealer Portal.

Reset Butoon

Note:

use non conductive tool

to depress the button

IR Learning

IR Talkback

System On LED

System Status LEDs

Yellow Green Red Blue

Firmware Update During Initialization

Solid yellow, blinking green LED.

Network Error

Blinking yellow LED.

Access Point - Error

Solid green LED with yellow LED blinking

continuously. May require reinitializing

access point mode.

Error Codes

All LEDs can be used to display various

error codes. Error codes are derived from

the number of times each LED blinks.

Booting

Solid yellow LED.

Access Point

Solid green LED and solid yellow LED.

Yellow LED may initially blink for a

short period of time.

Ready

Solid green LED.

Zone On

Solid blue LED.

Firmware Update

Blinking green LED

X5 Bottom Panel

Reinitializing Access Point Mode

Depress the button on the bottom

panel for 2 seconds. Yellow and green

LEDs will blink 6 times then go solid.

If the Ethernet cable is connected,

the Red LED will blink as a warning

that the X5 will reboot in

wired-ethernet mode.

See page 5 “Connecting to a wireless network”

Factory-Init

Depress the button on the bottom

panel for more than 10 seconds.

The red LED will go solid while the

X5 is initialized to factory defaults.

The device will then enter Access Point mode.

XStream X5 LED diagnostic chart

Russound, Inc.

5 Forbes Road, Newmarket, NH 03857

tel 603.659.5170 • fax 603.659.5388

email: [email protected] www.russound.com

28-1385 03/11/14, Rev.2

SiriusXM Internet Radio Service is available in the USA, PR or Canada.

SiriusXM Internet Radio subscriptions are sold separately and are governed by the Sirius Terms and Conditions (see www.sirius.com). Be sure to read this

agreement before you purchase your subscription. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. and its subsidiaries.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Russound is under license. other

trademarks and trade names are those of their respective owners.

AirPlay, iPad, iPhone, and iPod touch are trademarks of Apple Inc.,registered in the U.S. and other countries.

“Made for iPod,”“Made for iPhone,”and“Made for iPad”mean that an electronic accessory has been designed to connect specically to iPod, iPhone, or

iPad, respectively, and has been certied by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or

its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may aect wireless performance.

TheWi-Fi CERTIFIED Logo is a certication mark of theWi-Fi Alliance. The Wi-Fi CERTIFIED Logo is a registered trademark of Wi-Fi Alliance.

AirPlay works with iPhone, iPad,

and iPod touch with iOS 4.3.3 or

later, Mac with OS X Mountain

Lion, and Mac and PC with

iTunes 10.2.2 or later.
