INSTRUCTIONS AND WARRANTY

RUSSELL HOBBS ESSE 600W JUG BLENDER

MODEL NO: RHB630

Thank you for purchasing the Russell Hobbs Esse 600W Jug Blender. Each unit

has been manufactured to ensure safety, reliability and ease of use. Before use,

please read these instructions carefully and keep them for further reference.

FEATURES OF THE RUSSELL HOBBS ESSE 600W JUG BLENDER

•Powerful 600W motor

•2 speeds + pulse for ice crushing

•1.5L plastic jug

•Jug lid doubles as a large measuring cup and includes a small mobile measuring

cup

•Dishwasher-safe parts

•Visual safe-to-use indicator

•With cable storage facility

•Removable stainless steel blade unit for easy cleaning

•For domestic use only

IMPORTANT SAFEGUARDS

When using any electrical appliance, basic safety precautions should always be followed

including the following:

1. Read all instructions and save the instructions provided with this appliance.

2. Do not put the motor unit in water or any other liquid; do not use it in a bathroom or

near any source of water.

3. Do not use outdoors.

4. The blender must be used only by a responsible adult.

5. Unplug before dismantling or cleaning.

6. The blender is fitted with a safety switch to prevent the motor operating unless the jug

is in place. Do not use this to switch the blender on and off.

7. Turn the switch to standby “0” / “OFF”before fitting the jug to the motor/ base unit.

8. Turn the switch to standby “0” / “OFF”and wait until the blades come to a complete

stop before removing the lid from the jug, and before removing the jug from the motor/

base unit.

9. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

10. Children should be supervised to ensure that they do not play with the

appliance.

11. Do not use the blender without first locking the lid in place.

12. Do not fill the jug with boiling liquids.

13. Do not put your hand into the jug, even when it has been removed for

cleaning –the blades are very sharp.

14. Do not put any other object (spoon, spatula, etc.) Into the jug while the blender

is plugged in.

15. Do not leave the blender unattended when plugged in.

16. Position the motor unit on a dry, firm, level surface, close to a power socket

and out of reach of children.

17. Route the mains lead so that it cannot be caught accidentally or tripped over.

18. Keep the blender and the mains lead away from hotplates, hobs and burners.

19. Store the blender away from direct sunlight and fluorescent light where

possible.

20. Do not let the jug overflow. If liquid gets under the motor unit, it may be

sucked into the motor, damaging it.

21. Do not fill the jug above the 1.5L / 1500ml mark. If you do, the contents may

force the lid off when you start the motor.

22. The blender is equipped with a powerful 600W motor and therefore processes

very quickly. Due to its efficiency there is no need to run the motor for more

than 2 minutes at a time.

23. Do not run the motor for more than 2 minutes, either continuously, or

using the pulse setting, otherwise it may overheat. After 2 minutes use,

switch it off for at least 3 minutes allowing it to cool to room temperature and

allowing it recover.

24. Do not use the blender for any purpose other than those described in these

instructions.

25. Do not run the blender empty, as it may overheat.

26. Do not operate the blender after it malfunctions. If the mains lead or plug is

damaged, return the blender to the manufacturer in order to avoid any

hazard.

27. Children should be supervised to ensure that they do not play with the appliance.

28. Always turn the power off at the power outlet before you remove the plug.

Remove by grasping the plug. Do not pull on the electrical cord.

29. This appliance is designed for processing household quantities; it is not

suitable for commercial purposes. Use the appliance only for the purpose it

was designed for.

30. Do not use this appliance if it or parts of it show visible damage or if the

appliance has been dropped.

31. Do not attempt to make any modifications to this appliance.

32. To avoid any risk and to remain within warranty, repairs to this appliance

must be carried out by an authorised service agent only.

33. To reduce the risk of injury, never place the blade assembly on the base

without the jar properly attached.

34. If the supply cord is damaged, it must be replaced by the manufacturer, its

authorised service agent or similarly qualified persons in order to avoid any

hazard.

35. Switch off the appliance and disconnect from the power supply before

changing accessories or approaching parts that move when in use.

36. Do not run this appliance with an external timer.

PARTS DIAGRAM

A. Measuring Cup

B. Jug Lid

C. Plastic Jug

D. Blade Assembly Ring

E. Blade Assembly Unit

F. Control Knob

G. Motor Unit

Measuring cup

Allows you to add ingredients to the jug without removing the lid. Turn anti-clockwise to

open.

Plastic Jug

Allows you to see clearly inside the jug to check both the ingredients and the volume of

the food preparation.

Two Speed control

Two speed control gives a maximum (2) and a minimum (1) blade rotating speed to

blend different types and textures of food.

“P” Button (Crushes Ice)

“P” Button is preset to the best speed for crushing ice. Rotating the control to the “P”

position for a short period of time can provide a better performance for crushing ice.

BEFORE FIRST USE

Before using your Blender for the first time wash the jug, lid and cap in warm

soapy water, rinse well and dry. NOTE: The blades are sharp-edged, handle with

care.

OPERATING INSTRUCTIONS

Preparation

1. Position the motor unit on a dry, firm, level surface, close to a power

socket and out of reach of children.

2. Check that the control knob is set to “0” or OFF position.

3. Insert the blade assembly into the base of

the plastic jug, and rotate it anti- clockwise until

it is locked. You can see the “lock”arrow direction

at the bottom of the blade assembly unit.

4. Place the jug on top of the base/motor of the blender.

Ensure that the jug is firmly in place by turning it in a clock-

wise direction to lock it. There are ‘Lock’and ‘Unlock’

markings on the unit. It is recommended that you place

the jug handle away from the controls situated at the

front of the blender. To release the jug, turn it to

anti-clockwise direction.

5. Plug the motor unit into the power socket.

6. Put the ingredients into the jug. Do not fill it past the 1.5L / 1500ml mark. If you

do, the contents may force the lid off when you start the motor.

Fitting the Lid

1. Always fit the lid to the jug before using it.

2. Press the lid well until the flanges are well fixed in the jug.

3. Put the measuring cap into the hole in the lid and press it down to fit properly.

4. It is not a good idea to run the blender without the cap, especially if only solid

ingredients are used. They may be ejected through the hole once they hit the

blades.

The Operating Control

Turn the control knob clockwise to the speed you require:

“0” / “OFF”position

“1”position - slow,

“2”position - Max

To stop operation, turn the switch to “0” / “OFF”

position. Wait until the motor stops completely

then remove the jug from the body.

Unplug the blender after use.

Open indicator

Locked safe-to-use indicator

Don’t remove the lid from the jar

while the blender is on

Stop the blender before adding new

ingredients or use the measuring

cup to add ingredients.

Pulse Function

Pressing the pulse button will give you a short burst at maximum speed,

regardless of the current speed of the blades. The button is spring-loaded.

When you stop pressing, it will return to the speed the switch is pointing at.

Do not run the motor continuously for more than 2 minutes, or it may overheat. After 2

minutes, switch off for at least 3 minutes to cool down. This will help to prolong the

life of your appliance.

Crushing Ice

Before using the blender to crush ice, make sure it is clean and rinse it out thoroughly.

Any remaining trace of detergent may affect the taste of the crushed ice and will

flatten any drink to which it has been added.

Ice cubes come in many shapes and sizes. You will have to experiment with the ice

from your ice cube tray. Insert a maximum of 8 ice cubes and add 15ml

(1 tablespoon) of fresh cold water. Put the lid on the blender and turn the control knob

to “P”. While the unit is blending, hold for 2 seconds and release for 2 seconds. Note

that too much blending will reduce the ice to liquid, too little will merely chip the

edges/corners off the ice. Do not try to crush ice without adding water to the jug.

Do not be tempted simply to increase the amount of ice and blend for longer –

this will not work. Too much ice will never give you satisfactory results.

Adding ingredients

If you need to add ingredients while the blender is working, lift the cap off,

pour the new ingredients through the hole then replace the cap. Make sure

that the added ingredients do not push the volume in the jug past the 1.5L

/ 1500ml mark.

Finished

Turn the switch to “0” / “OFF”, wait until the blades have stopped moving before

removing the lid from the jug –or removing the jug from the motor unit. Hold the

motor unit with one hand, grasp the handle with the other hand, and then lift it off the

motor unit. Now lift the lid off the jug.

Quick Clean

Fit the blender jug onto the base, making sure it is firmly in place.

Pour some lukewarm water and dishwashing

liquid into the jug. Press the pulse button for a

few seconds, repeat this twice and rinse

thoroughly with clean water. Let it dry before

storing away. Clean the motor with a damp

cloth, never immerse it in water or place it under

running water.

Tips For Using Your Blender

Do not blend dry, thick or heavy mixtures for more than 60 seconds continuously. Let

the appliance cool down to room temperature before continue operating the

appliance again.

Do not place the lid into boiling water as it may deform.

Always hold the edge of the lid while operating the blender.

Basic Speed and Processing Guide

Speed

Recommended application

Time

Blending ice/ carrot /water with rough

pieces for sauces in max speed

30s

Blending instant juices, soft fruit and

cocktails with alcohol

40-60s

Making Milkshakes

1min

1 or 2

Blending soup, milkshakes with hard fruit

1.5min

Handle with jug with care.

The blades are very sharp.

Wash with care.

Never touch the blades with

your finger.

Making sauces, baby food, blending hard

fruits or vegetables

1.5min

Making juices with 600g carrot and 900g

water.

1-2min

“P”

(Ice Crush)

Crushing ice cubes. Suggested to crush no

more than 8 ice cubes each time

Short time of

operation

Do not operate on “2” / “MAX” for longer than 2 minutes at a time. Please let the

appliance cool down to room temperature before continuing to operating the

appliance again.

SMOOTHIE RECIPES

Banana Smoothie

Ingredients:

1 Banana Peeled & Sliced

¼ Cup Oats

1Tbsp Honey

1 Tbsp Peanut Butter

100g flax seeds

150ml Yogurt

1 Cup Ice

Method:

1. Add all ingredients into the blender.

2. Pulse it at first to break the ice.

3. Blend for about 2 minutes until smooth.

Tip

This smoothie is great for sustained energy throughout the day. The banana has

high levels of potassium, helping you to quickly replenish electrolytes. (The riper

a banana, the higher the sugar content). The peanut butter is high in protein

and the raw oats is a Low GI filler. Flax seed is a great source of fibre and

Omega 3 fatty acids, and yoghurt contains protein, calcium, riboflavin, vitamin

Tabla de contenidos

Idiomas:

Otros manuales de Licuadora de Russell Hobbs

Russell Hobbs

Russell Hobbs RHBL1300 Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs 28241-56 Manual de usuario

Russell Hobbs

Russell Hobbs 14500 Manual de usuario

Russell Hobbs

Russell Hobbs GRAPHITE RHSM3000 Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs RHJ3000 Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs simply smoothie Manual de usuario

Russell Hobbs

Russell Hobbs 24722 Manual de usuario

Russell Hobbs

Russell Hobbs 23470-56 Manual de usuario

Russell Hobbs

Russell Hobbs 14449 Manual de usuario

Russell Hobbs

Russell Hobbs 24722-56 Manual de usuario

Russell Hobbs

Russell Hobbs STUDIO RHCBL500 Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs 18980-56 Manual de usuario

Russell Hobbs

Russell Hobbs 23820-56 Manual de usuario

Russell Hobbs

Russell Hobbs Desire 24700-56 Manual de usuario

Russell Hobbs

Russell Hobbs Illumina 20220 Manual de usuario

Russell Hobbs

Russell Hobbs 20240-56 Manual de usuario

Russell Hobbs

Russell Hobbs Explore Mix & Go Cool 21350-56 Manual de usuario

Russell Hobbs

Russell Hobbs BROOKLYN RHBL70COP Manual de usuario

Russell Hobbs

Russell Hobbs HB3100RDR Manual de usuario

Russell Hobbs

Russell Hobbs Desire 18508 Manual de usuario

Russell Hobbs

Russell Hobbs MIX & GO STEEL RHBL300 Guía de instalación

Russell Hobbs

Russell Hobbs 22340-56 Manual de usuario

Russell Hobbs

Russell Hobbs Blender Manual de usuario

Russell Hobbs

Russell Hobbs RHBL1 Manual de instrucciones de instalación

Manuales populares de Licuadora de otras marcas

ROTOR

ROTOR 1125.201 Manual de usuario

Braun

Braun Multiquick 5 Vario series Manual de usuario

ARENDO

ARENDO MIRA 305424 Manual de usuario

CHEF-BUILT

CHEF-BUILT CCB-3500 Manual de usuario

Viconte

Viconte VC-4406 Manual de usuario

Oster

Oster BLSTAB-CB0 Manual de usuario

HOFFEN

HOFFEN MC-3005 Manual de usuario

Black & Decker

Black & Decker BLC18750DM Manual de usuario

Sunbeam

Sunbeam 4182 Manual de usuario

Bialetti

Bialetti FMX35 Manual de usuario

Black & Decker

Black & Decker BL8000 Manual de usuario

Duronic

Duronic BL530 Manual de usuario

Exquisit

Exquisit MS 3002 wes Manual de usuario

Lumme

Lumme LU-KP1891A Manual de usuario

Binatone

Binatone HB-735 Manual de usuario

Moulinex

Moulinex LM936E10 Manual de usuario

Oster

Oster VERSA Manual de instalación y operación

Ninja

Ninja NN210Q Manual de usuario
