Ruijie Networks RG-AP220-E Manual de instalación y funcionamiento

RG-AP220-E(M) Series Access Point

Hardware Installation and Reference Guide V1.3

Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup,

modification, transmission, translation or commercial use of this document or any portion of this document,

in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.

, , , ,

,, ,

, , are registered trademarks of Ruijie

Networks. Counterfeit is strictly prohibited.

Exemption statement

This document is provided “as is”. The contents of this document are subject to change without any notice.

Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to

ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to

content omissions, inaccuracies or errors.

Preface

Thank you for using our products. This manual will guide you through the installation of the access point.

Scope

It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it

is assumed that the users are already familiar with the related terms and concepts.

Obtaining Technical Assistance

Ruijie Networks website: http://www.ruijienetworks.com

Online customer services: http://webchat.ruijie.com.cn

Customer service center: http://www.ruijie.com.cn/service.aspx

Customer services hotline: +86-4008-111-000

BBS:

http://support.ruijie.com.cn

Customer services email: [email protected]

Related Documents

Documents Description

Configuration Guide Describes network protocols and related mechanisms that supported by the

product, with configuration examples.

Command Reference Describes the related configuration commands, including command modes,

parameter descriptions, usage guides, and related examples.

Documentation Conventions

The symbols used in this document are described as below:

This symbol brings your attention to some helpful suggestions and references.

This symbol means that you must be extremely careful not to do some things that may damage the device or

cause data loss.

Chapter 1 Product Overview

The RG-AP220-E(M) series wireless LAN access point is designed by Ruijie Networks for Ruijie i-share wireless solution.

It is ideal for large-sized campuses and hospitals. The AP can serve as a Fit AP and operate in conjunction with a Ruijie

WS series wireless controller; or it can serve as a standalone Fat AP and provide wireless access for mobile clients.

RG-AP220-E(M) V1.XX

Model RG-AP220-E(M) V1.XX

Feature Indoor dual band dual radio access point, supporting i-Share system.

Interfaces One Gigabit combo port (one 10/100/1000M auto-sensing RJ45 port and one SFP port)

One Console port

Antennas

Connectors Six SMA connectors

Power Adapter Input: 90-264 V AC,50-60 Hz

Output: 48 V DC, 0.4 A max.

PoE IEEE 802.af PoE

Power Consumption 12.95 W

Operating

Frequency 802.11b/g/n: 2.4 GHz to 2.4835 GHz

Transmit Power 100 mW, adjustable

Operating: 0 to 50℃(32 to 122 ℉)

Temperature Storage: -40 to 70℃(-40 to 158 ℉)

Operating:10% to 95% noncondensing

Humidity Storage: 5% to 95% noncondensing

Size (W x D x H) 24 cm x 22 cm x 4 cm

9.44 in. x 8.66 in. x 1.57 in.

Weight 1.6 kg (3.53 lbs)

RG-AP220-E(M) V2.XX

Model RG-AP220-E(M) V2.XX

Feature Indoor dual band dual radio access point, supporting i-Share system.

Interfaces One Gigabit combo port (one 10/100/1000M auto-sensing RJ45 port and one SFP port)

One Console port

Antennas

Connectors Six SMA connectors

Power Adapter Input: 90-264 V AC,50-60 Hz

Output: 48 V DC, 0.4 A max.

PoE IEEE 802.af PoE

Power Consumption 12.95 W

Operating

Frequency 802.11b/g/n: 2.4 GHz to 2.4835 GHz

Transmit Power 10 mW per antenna connector, adjustable

Operating: 0 to 50℃(32 to 122 ℉)

Temperature Storage: -40 to 70℃(-40 to 158 ℉)

Operating:10% to 95% noncondensing

Humidity Storage: 5% to 95% noncondensing

Size (W x D x H) 24 cm x 22 cm x 4 cm

9.44 in. x 8.66 in. x 1.57 in.

Weight 1.6 kg (3.53 lbs)

RG-AP220-E(M)-V2

Model RG-AP220-E(M) V2

Feature Indoor dual band dual radio access point, supporting i-Share system

Interfaces One 10/100/1000BASE-T Ethernet port

One RJ45 port

Antennas

Connectors Eight SMA connectors

Network Standards 802.11a/b/g/n

Operating

Frequency

802.11b/g/n: 2.4 GHz to 2.4835 GHz

802.11a/n: 5.15 GHz to 5.85 GHz

Power Adapter Input: 100-240 V AC

Output: 48 V DC

PoE IEEE 802.af PoE

Power Consumption 12.95 W

Operating: -10 to 55℃(14 to 131 ℉)

Temperature Storage: -40 to 70℃(-40 to 158 ℉)

Operating: 5% to 95% noncondensing

Humidity Storage: 5% to 95% noncondensing

Transmit Power 20 mW per antenna connector, adjustable

Power Save Mode Supported

Operating Channels 5.0 GHz: 12 channels (USA), 5 channels(China)

2.4 GHz: 11 channels (USA), 13 channels (China and Europe)

Data Rates

802.11b: 11, 5.5, 2, and 1 Mbps

802.11a/g: 54, 48, 36, 24, 18, 12, 9, and 6 Mbps

802.11n: MCS0 through MCS15, maximum data rate 300 Mbps

Size (W x D x H) 20 cm x 19 cm x 3.5 cm

7.87 in. x 7.48 in. x 1.38 in.

Weight 0.8 kg (1.76 lbs)

EMC Standards GB9254-2008 CLASS B

Safety Standards GB4943-2011

Product Image

The RG-AP220-E(M)-V2 provides one Console port, one 10/100/1000Base-T auto-sensing Ethernet port with PoE

capability, one 48V DC power port on the front and eight antenna connectors on the three sides.

Figure 1-1 Product Image of RG-AP220-E(M)-V2

Front View

Figure 1-3 Front View of RG-AP220-V2

Note 1. Console port

2. 10/100/1000 Base-T auto-sensing Ethernet port

3. Console port

4. Antenna

Top View

Figure 1-3 Top view of RG-AP220-E(M)

Note 1. Status LED

2. Ethernet LED

3. Radio 1 LED

4. Radio 2 LED

Power Sources

The AP can be powered either with a 48V DC power adaptor or through Power over Ethernet (PoE).

Rated voltage: 48V DC

Rated current: 0.25A

It is recommended that you use Ruijie PoE-capable switches, such as RG-S5750P-24GT/12SFP and

RG-S3760E-24P, to power the AP. When you use PoE devices made by other companies as power sources, the

devices may cause exceptions or damages to the AP.

Cooling Solution

The AP adopts fanless design. To ensure good heat dissipation, leave a minimum space of 10 cm from both sides and the

rear of the AP, and avoid blocking the air vents on the AP.

LED Indicators

LED State Meaning

Off The AP is NOT receiving power.Status

Blinking green Initialization in progress.

Continuous blinking indicates errors.

Solid green The AP is operational.

Solid red The AP is faulty.

Off Radio1 is NOT operational.

Solid green Radio1 is operational.

Radio 1

Blinking green Radio1 is transceiving data.

Off Radio 2 is NOT operational.

Solid organge Radio 2 is operational.

Radio 2

Blinking orange Radio 2 is transceiving data.

Off The Ethernet port is NOT connected.

Solid green The Ethernet port is connected.

Ethernet

Blinking green The Ethernet port is transceiving data.

Chapter 2 Preparing the Installation

To prevent device damage and bodily injury, please read carefully the safety recommendations described in

this chapter. The recommendations do not cover all possible hazardous situations.

Preparing Installation Site

Do not expose the AP to high temperature, dusts, or harmful gases.

Do not install the AP in an inflammable or explosive environment.

Keep the AP away from EMI sources such as large radar stations, radio stations, and substations.

Do not subject the AP to unstable voltage, vibration, and noises.

Keep the AP at least 500 meters away from the seaside and do not face it toward the wind from the sea.

The installation site should be free from water flooding, seepage, dripping, or condensation.

The installation site should be selected according to network planning and features of communications equipment,

and considerations such as climate, hydrology, geology, earthquake, electric power, and transportation.

EMI

All interference sources, either from outside or inside of the device or application system, affect the device by capacitive

coupling, inductive coupling, or electromagnetic waves.

Electromagnetic interference (EMI) occurs due to electromagnetic radiation or conduction, depending on the transmission

path.

Radiation interference occurs when energy, usually radio frequency energy, is emitted from a device and propagated

through space that disturbs other victims. The interference source can be part of disturbed system or a fully electrically

isolated unit. Conduction interference occurs when interference is transferred from one unit to another unit through cables,

which are usually electromagnetic wires or signal cables connected between the source and the victim. Conduction

interference often affects the power supply of the device, and can be eliminated by using filters. Radiation interference can

influence the path of any signal from the device, which is hard to be shielded.

Take effective measures against interferences from the power grid.

Keep the AP far away from the grounding or lightning protection devices of power equipment.

Keep the AP away from high-power radio stations, radar stations, and high-frequency high-current devices.

Take electrostatic shielding measures.

Ventilation

For proper ventilation, leave a minimum clearance of 10 cm (3.9 in.) from the rear and both sides of the AP. And bind your

loose cables together or place them on a cable tray to avoid blocking the air inlets.

Temperature and Humidity

To ensure normal operation and service life of the device, maintain appropriate temperature and humidity levels in your

equipment room. See Table-1 . Improper room temperature and humidity can cause damages to the device.

High relative humidity may affect insulation materials, resulting in poor insulation and even electrical leakage, and

sometimes may lead to change of mechanical properties of materials and corrosion of metal parts.

Low relative humidity may dry and shrink insulation sheets and cause static electricity that can damage the circuitry

inside the device.

High temperature greatly reduces reliability of the device and shortens its service life.

Table 2-1: Required Temperature and Humidity for the RG-AP220-E(C)

Temperature Relative Humidity

Long-term Short-term Long-term Short-term

10ºC to 45ºC -10ºC to 50ºC 40% to 65% 10% to 90%

The ambient temperature and humidity are measured at a point 1.5 meters (4.9 feet) above the ground and

0.4 meters (1.3 feet) before the device when there is no protective board in the front or back of the rack.

The “short-term” means at most 48 hours of continuous operation in less than 15 days each year.

Cleanness

Dust poses a serious threat to device operation. Dust that falls onto the surface of the device can be absorbed onto metal

contact points by static electricity, resulting in poor contact. Electrostatic absorption of dust occurs more easily when the

relative humidity is low, which may shorten the service life of the device and cause communication failures. Table 2-2

shows the maximum concentration and diameter of dust allowed in the equipment room.

Table 2-2 Maximum Concentration and Diameter of Dust Allowed

Maximum diameter (μm) 0.5 1 3 5

Maximum concentration

(Particles/m3) 1.4 x 10 7 x 10 2.4 x 10 1.3 x 10

Besides, the contents of salts, acids and sulfides in the air are also strictly limited for the equipment room. These

substances can accelerate metal corrosion and the aging of some parts. Table 2-3 describes the limit of some hazardous

gases such as SO2, H2S, NO2and Cl2 in the equipment room.

Table 2-3 Limits of Hazardous Gases

Otros manuales para RG-AP220-E

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Punto de acceso inalámbrico de Ruijie Networks

Ruijie Networks

Ruijie Networks Reyee RG-RAP2266 Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AM5528 Series Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP220-E Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks i-Share+ Series Dimensiones

Ruijie Networks

Ruijie Networks RG-AP820-I Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP320-I Series Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP810-L Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP630 CD Manual de usuario

Ruijie Networks

Ruijie Networks RG-SAP815-SP Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP3220 Series Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP820-L Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP220-I Series Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-MAP552(SR) series Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks Reyee RG-RAP1261 Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP520(DA) Series Manual de instalación y funcionamiento

Ruijie Networks

Ruijie Networks RG-AP130-W Manual de usuario

Manuales populares de Punto de acceso inalámbrico de otras marcas

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manual de usuario

Ubiquiti

Ubiquiti NanoStation NSM2 Manual de usuario

Cisco

Cisco Aironet 1550 Series Manual de usuario

Aruba

Aruba IAP-335 Manual de usuario

Advantek Networks

Advantek Networks AWN-AP-54MR Manual de usuario

IP-COM

IP-COM AP355 Manual de usuario

Buffalo

Buffalo AirStation WLA-L11G Manual de usuario

EnGenius

EnGenius EnStationACv2 Manual de usuario

D-Link

D-Link DAP-3662 Manual de usuario

xG Technology

xG Technology xMax CN1300 Manual de usuario

Widelink

Widelink ezWave WAP-1100 Series Manual de usuario

Edimax

Edimax CAP1200 Manual de usuario

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manual de usuario

Aruba

Aruba AP-203R Manual de usuario

LuXout Shades

LuXout Shades LUXSHADE MOTION Manual de usuario

CreatComm

CreatComm TB5F Manual de usuario

SineDigital

SineDigital MW-1500AP(H) Manual de usuario

TP-Link

TP-Link AP9650 V1 Manual de usuario
