RTI VHD-8 Instrucciones de funcionamiento
1
It’s Under Control®
VHD-8
Installation and Operation Guide
70-210132-16 V1.2
8x8 HDBT Video Matrix Switch
It’s Under Control®
8x8 HDBT Video Matrix Switch
VHD-8
22
Copyright © 2017
Remote Technologies Incorporated
All rights reserved.
3
It’s Under Control®
3
It’s Under Control®
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. Any changes
or modications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the device.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may
cause undesired operation.
Industry Canada Compliance Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may
cause undesired operation.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). Son
fonctionnement est soumis aux deux conditions suivantes:
1. Ce dispositif ne peut causer des interférences nuisibles.
2. Cet appareil doit accepter toute interférence reçue y compris des interférences qui
peuvent provoquer un fonctionnement indésirable.
FEDERAL COMMUNICATIONS COMMISSION NOTICE
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI website at: www.
rticorp.com/declaration
8x8 HDBT Video Matrix Switch
VHD-8
4
Read Instructions. Read all safety and operating instructions before operating the unit.
Retain Instructions. Keep the safety and operating instructions for future reference.
Heed Warnings. Adhere to all warnings on the unit and in the operating instructions.
Follow Instructions. Install and operate in accordance with the manufacturer’s
instructions.
Accessories. Only use attachments/accessories specied by the manufacturer.
Portable Cart Warning. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or sold with the apparatus. When
a cart is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Heat. Do not block any ventilation openings.
Heat. Keep the unit away from heat sources such as radiators, heat
registers, stoves, etc., including ampliers that produce heat.
Power. Unplug this apparatus during lightning storms or when unused for long periods of
time.
Power Sources. Connect only to the power cord that was included with the unit.
Power Cord Protection. Route power supply cords so that they are not likely to be
walked on or pinched by items placed on or against them, paying particular attention to
the cords at plugs, at convenient receptacles, and at the point at which they exit from the
unit.
Power Cord Grounding Plug. Do not remove the grounding prong of the grounding-type
plug. A grounding type plug has two blades and a third grounding prong. The third prong
is provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
MAINS Outlet. Where MAINS outlets are used, the apparatus shall be connected to a
MAINS socket outlet with a protective earthing connection.
MAINS Plug. Where the MAINS plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
Water and Moisture. Do not use the unit near water—for example, near a sink, in a wet
basement, near a swimming pool, near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled into the
enclosure through openings.
Cleaning. Clean only with dry cloth.
Servicing. Do not attempt any service beyond that described in the operating instructions.
Refer all other service needs to qualied service personnel.
Damage Requiring Service. The unit should be serviced by qualied service personnel
when:
Objects have fallen or liquid has been spilled into the unit.
The power supply cord or the plug has been damaged.
The unit does not appear to operate normally or exhibits a marked change in
performance.
The unit has been dropped or the enclosure has been damaged.
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THE UNIT TO RAIN OR MOISTURE.
SAFETY SUGGESTIONS
5
It’s Under Control®
DISCLAIMER
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated without the prior written notice of Remote
Technologies Incorporated.
The information contained in this document is subject to change without
notice. Remote Technologies Incorporated shall not be liable for errors or
omissions contained herein or for consequential damages in connection with the
furnishing, performance, or use of this guide.
VHD-8, Integration Designer, and the RTI logo are registered trademarks of
Remote Technologies Incorporated.
Other brands and their products are trademarks or registered trademarks of
their respective holders.
8x8 HDBT Video Matrix Switch
VHD-8
6
RTI warrants new products for a period of three (3) years (excluding consumables such as
rechargeable batteries which are warrantied for one (1) year) from the date of purchase
by the original purchaser (end user) directly from RTI / Pro Control (herein referred to as
“RTI”), or an authorized RTI dealer.
Warranty claims may be initiated by an authorized RTI dealer using the original dated sales
receipt or other proof of warranty coverage. In the absence of the receipt of purchase from
the original dealer, RTI will provide warranty coverage extension of six (6) months from the
date code of the product. Note: RTI warranty is limited to the provisions set forth in this
policy and does not preclude any other warranties oered by third parties who are solely
responsible for those other warranties.
Except as specied below, this warranty covers defects in product material and
workmanship. The following are not covered by the warranty:
• Product purchased via unauthorized sellers or internet sites will not be serviced-
regardless of purchase date.
• Damages caused by accident, misuse, abuse, neglect or acts of God.
• Cosmetic damage, including, but not limited to, scratches, dents and normal wear and
tear.
• Failure to follow instructions contained in the Product Installation Guide.
• Damages due to products used in an application or environment other than that for
which it was intended, improper installation procedures or adverse environmental
factors such as incorrect line voltages, improper wiring, or insucient ventilation.
• Repair or attempted repair by anyone other than RTI and Pro Control or authorized
service partners.
• Failure to perform recommended periodic maintenance.
• Causes other than product defects, including lack of skill, competence or experience of
user.
• Damage due to shipment of this product (claims must be made to the carrier).
• Altered unit or altered serial number: defaced, modied or removed.
RTI is also not liable for:
• Damages caused by its products or for failure of its products to perform, including any
labor costs, lost prots, lost savings, incidental damages, or consequential damages.
• Damages based upon inconvenience, loss of use of the product, loss of time,
interrupted operation, commercial loss, any claim made by a third party or made on
behalf of a third party.
• Loss of, or damage to, data, computer systems or computer programs.
RTI’s liability for any defective product is limited to repair or replacement of the product, at
the sole discretion of RTI.
In cases where the warranty policy conicts with local laws, the local laws will be adopted.
If any component of your VHD HDBT Video Matrix needs service, please contact Remote
Technologies Incorporated by telephone, fax or E-mail for return information. Please
do not return products to Remote Technologies Incorporated without return
authorization.
LIMITED WARRANTY
7
It’s Under Control®
Federal Communications Commission Notice................................................... 3
Safety Suggestions.......................................................................................... 4
Disclaimer ....................................................................................................... 5
Limited Warranty ............................................................................................ 6
Table of Contents ............................................................................................ 7
Chapter 1 - Welcome ....................................................................................... 9
- Important Notes ................................................................................... 9
- Product Contents ................................................................................. 10
Chapter 2 - Features and Description ............................................................. 11
- Front Panel .......................................................................................... 11
- Rear Panel ........................................................................................... 12
Chapter 3 - Installation and Operation ........................................................... 14
- Precautions ......................................................................................... 14
- Mounting ............................................................................................. 14
- Connections ......................................................................................... 15
- Front Panel Control.............................................................................. 16
- EDID Management ............................................................................... 16
- Control (IR/RS232/IP)........................................................................ 19
- Web Interface...................................................................................... 20
- Connection Diagram ............................................................................ 24
Chapter 4 - Specications............................................................................... 26
Chapter 5 - Troubleshooting........................................................................... 28
Chapter 6 - Service and Support..................................................................... 31
TABLE OF CONTENTS
8x8 HDBT Video Matrix Switch
VHD-8
8
9
It’s Under Control®
Thank you for using the VHD-8 Video Matrix Switch.
The VHD-8 8x8 HDMI professional matrix switch is used for convenient viewing of up to
eight video sources distributed to eight displays. The switch is complete with eight HDMI
inputs, eight HDBaseT outputs and four local HDMI outputs. In addition, the VHD-8 also
includes eight de-embedded stereo audio outputs.
The VHD-8 enables cross-point switching from any input to any output, and supports
high resolution video output at 4K, 1080P and HD3D. In addition, the HDBaseT outputs
deliver video, IR and RS232 communication, and PoC over a Cat5e/Cat6 cable to a VHR-1
HDBaseT receiver up to to 230 feet (70 meters) away.
The VHD-8 provides superior quality and reliability as well as these specic
features:
• Supports video output at 4K, 1080P and 3D.
• HDCP 2.2 Compliant and DVI compatible, supporting HDMI 1.4a & DVI1.0.
• Powerful EDID & HDCP management.
• HDBaseT outputs transmit HDMI@1080p, IR & RS232 up to 230 feet (70m) over a
Cat5E/6 cable (115ft/35m at 4Kx2K).
• HDBaseT outputs supports PoC (Power over Cable) to power VHR receivers.
• Supports multiple control methods, including front panel, RS232, IR and TCP/IP.
• LCD indicator shows connection status, switching status, HDCP status, and output
resolution.
• Built-in GUI for TCP/IP management.
• Supports rmware upgrades through Micro USB port.
• Easy installation with rack-mount design.
IMPORTANT NOTES
Please read these important notes about the VHD-8:
• The VHD-8 should be placed in an area where it is around normal room temperature
(between 60°F to 90°F).
• Avoid installing the VHD-8 in a location with little or no air circulation.
• Avoid installing the VHD-8 in a location where it can come in contact with direct
sunlight.
• Do not let the VHD-8 get wet. It should not be handled with wet hands or placed in
an area where it could get wet.
• Do not subject the VHD-8 to smoke, dust, or vibrations.
• Only use the power cord that is supplied with the VHD-8. Using the wrong type of
power cord may result in damage.
• Do not disassemble the unit. Service of the VHD-8 should be performed by authorized
personnel only.
CHAPTER 1 | INTRODUCTION
8x8 HDBT Video Matrix Switch
VHD-8
10
Contents within the box include the following items:
One (1) VHD-8 Video Matrix Switch
Two (2) Rack Mounting Ears with Screws
Four (4) Feet with Screws
One (1) Power Cord
Eight (8) 3.5mm mono-to-mono IR cables
One (1) Installation Guide
UNPACKING AND INSPECTION
After unpacking the VHD-8 HDBT Matrix Switch, save all of the packing materials in case
you ever have to ship the unit.
Thoroughly inspect the VHD-8 and packing materials for signs of damage. Report any
damage to the carrier immediately. Report any equipment malfunctions to RTI or an
authorized RTI distributor.
CHAPTER 1 | PRODUCT CONTENTS
Tabla de contenidos
Otros manuales de Cambiar de RTI
