RTA 460MSBS Manual de usuario

460MSBS Gateway

User Guide

Trademarks

CompactLogix, ControlLogix, & PLC-5 are registered trademarks of Rockwell Automation, Inc.

EtherNet/IP is a trademark of the Open DeviceNet Vendors Association (ODVA).

MicroLogix, RSLogix 500, and SLC are trademarks of Rockwell Automation, Inc.

Microsoft, Windows, and Internet Explorer are registered trademarks of Microsoft Corporation.

All other trademarks and registered trademarks are the property of their holders.

Limited Warranty

Real Time Automation, Inc. warrants that this product is free from defects and functions properly.

EXCEPT AS SPECIFICALLY SET FORTH ABOVE, REAL TIME AUTOMATION, INC. DIS-

CLAIMS ALL OTHER WARRANTIES, BOTH EXPRESSED AND IMPLIED, INCLUDING BUT

NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR APPLICATION. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the

many variables and requirements associated with any particular application, Real Time Automation,

Inc. cannot assume responsibility or liability for actual use based on the examples and diagrams. Ex-

cept as specifically set forth above, Real Time Automation and its distributors and dealers will in no

event be liable for any damages whatsoever, either direct or indirect, including but not limited to loss

of business profits, income, or use of data. Some states do not allow exclusion or limitation of inciden-

tal or consequential damages; therefore, the limitations set forth in this agreement may not apply to

you.

No patent liability is assumed by Real Time Automation with respect to use of information, circuits,

equipment, or software described in this manual.

Government End-Users

If this software is acquired by or on behalf of a unit or agency of the United States Government, this

provision applies: The software (a) was developed at private expense, is existing computer software,

and was not developed with government funds; (b) is a trade secret of Real Time Automation, Inc. for

all purposes of the Freedom of Information Act; (c) is “restricted computer software” submitted with

restricted rights in accordance with subparagraphs (a) through (d) of the Commercial “Computer Soft-

ware-Restricted Rights” clause at 52.227-19 and its successors; (d) in all respects is proprietary data

belonging solely to Real Time Automation, Inc.; (e) is unpublished and all rights are reserved under

licensed only with “Restricted Rights”: as that term is defined in the DoD Supplement of the Federal

Acquisition Regulation 52.227-7013 (c) (1) (ii), rights in Technical Data and Computer Software and

its successors, and: Use, duplication, or disclosures is subject to restrictions as set forth in subdivision

ware was acquired under GSA schedule, the U.S. Government has agreed to refrain from changing or

removing any insignia or lettering from the Software or documentation that is provided or from pro-

ducing copies of the manual or media. Real Time Automation, Inc., 150 S. Sunnyslope Rd. Suite 130,

Brookfield, WI 53005.

Real Time Automation, Inc. 1 1-800-249-1612

460 Gateway Device Line 460MSBS

Overview

The 460MSBS Gateway device seamlessly connects a Modbus TCP Client device to a BACnet/IP enabled automation

system By following this guide, you will be able to configure the 460MSBS Gateway for basic operation You will set

the device’s network settings and parameters to the proper configuration for initial operation and physically place

the device in the network

For further customization and advanced use, feel free to consult the provided user’s manual In addition, Real Time

Automation would be happy to provide support to help you utilize the device

Real Time Automation, Inc. 2 1-800-249-1612

460 Gateway Device Line 460MSBS

Required Tools and Data

You will need the following tools:

♦

The 460MSBS Gateway

♦

The provided CD-ROM

♦

A Working C (Windows based)

♦

The Supplied Ethernet Crossover Cable

♦

A 7-30 VDC power source (T-strip)

Real Time Automation, Inc. 3 1-800-249-1612

460 Gateway Device Line 460MSBS

Port Connections

The factory default port settings on the 460MCBS gateway are for Port 0 (T-strip) to be set for pin 1 to be ground

and pin 5 to be power Port 1 (DB9) is set to RS232 by default

If these default port are not compatible with your equipment they can be configured differently For specific jumper

settings refer to the end of this manual, appendix A For assistance changing port configurations contact our customer

support department

Real Time Automation, Inc. 4 1-800-249-1612

460 Gateway Device Line 460MSBS

Accessing the Main Page

Before you can configure the gateway itself, you must configure the network settings to connect the gateway The

following steps will connect the gateway properly

1) Connect the 7-30 VDC power source (supplied) to the device

2) Using the crossover cable (supplied) connect the device to the PC

3) Insert the provided CD-ROM

4) Run the IPSetup program from the CD-ROM

5) Configure the IP Address of the unit for your subnet Ex: If

your workstation IP address is 192 168 0 1 an acceptable

IP Address for the gateway would be 192 168 0 100

6) Click Set

7) Click Launch Webpage The main page should appear

NOTE

Browser configuration is only Internet

Explorer compatible. The use of

FireFox is not supported.

Default IP address is 192.168.0.100

Real Time Automation, Inc. 5 1-800-249-1612

460 Gateway Device Line 460MSBS

Error: Main Page Does Not Launch

If the Main Page does not launch, the IP Address is most likely incorrect Correct the IP Address and try again If you

do not know the IP address use the following procedure:

1) Open an MS-DOS Command Prompt

2) Type ipconfig and press enter

3) Note the IP Address (The previous example was 192 168 0 1)

4) To test the communication between the PC and the unit, type ping (### ### # ###) in the prompt and press

enter The (### ### # ###) is a placeholder for the IP Address you used in step 5 of network configuration

which, is 192.168.0.100 by default. If the device is connected to the network the ping will show a response If

you get no response check the crossover cable

Real Time Automation, Inc. 6 1-800-249-1612

460 Gateway Device Line 460MSBS

Modbus TCP Device Settings

The Modbus TCP Server has no configurable settings

Real Time Automation, Inc. 7 1-800-249-1612

460 Gateway Device Line 460MSBS

BACnet IP Server Settings

1) Scroll down to the BACnet Server row and click Edit Verify that the Enabled box is checked

2) Enter a unique Device Instance that will represent the 460MSBS on the BACnet/IP network

3) In the Device Name field enter a unique name for the device

4) The Description and Location fields are optional Filling in this information is recommended to identify the device

on a network

5) Beneath # of Objects to Expose, enter in the number of Analog Input (AI) and Analog Output (AO) objects that

you will be accessing from the BACnet/IP Client

NOTE: In the 460MSBS, Binary Input (BI) and Binary Output (BO) objects cannot

be used.

6) Click Save

Real Time Automation, Inc. 8 1-800-249-1612

460 Gateway Device Line 460MSBS

Application Parameters

1) Next to Application Parameters click Edit

2) The 460MSBS has two ways that the data can be reference within Modbus The Modbus data can be

represented as integer (2 bytes) or as a float (4 bytes) The other option, only valid for float data type

selected, is what type of word ordering the Modbus device is expecting
